CAUTION:
TO PREVENT ELECTRIC SHOCK, MATCH
WIDE BLADE OF PLUG TO WIDE SLOT,
FULLY INSERT.
ATTENTION:
POUR ÉVITER LES CHOC ÉLECTRIQUES,
INTRODUIRE LA LAME LA PLUS LARGE DE
LA FICHE DANS LA BORNE
CORRESPONDANTE DE LA PRISES ET
POUSSER JUSQUAU FOND.
GROUND
CLAMP
ELECTRIC
SERVICE
EQUIPMENT
ANTENNA
LEAD IN
WIRE
ANTENNA
DISCHARGE UNIT
(NEC SECTION 810-20)
GROUND CLAMPS
GROUND CONDUCTORS
(NEC SECTION 810-21)
POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250, PART H)
NEC - NATIONAL ELECTRICAL CODE
WARNING:
To reduce the risk of fire or electric shock, do not
expose this appliance to rain or moisture.
CAUTION:
Use of controls or adjustments or performance of
procedures other than those specified may result
in hazardous radiation exposure.
CAUTION - TO REDUCE THE RISK OF
ELECTRIC SHOCK, DO NOT REMOVE COVER
(OR BACK). NO USER-SERVICING TO
QUALIFIED SERVICE PERSONNEL.
The lightning flash with arrowhead
symbol, within an equilateral triangle, is
intended to alert the user to presence
of uninsulated dangerous oltage
within the products enclosure that may
be of sufficient magnitude to constitute
a risk of electric shock to persons.
The exclamation point within an
equilateral triangle is intended to alert
the user to the presence of important
operating and maintenance (ser icing)
instructions in the literature
accompanying the appliance.
IMPORTANT SAFETY INSTRUCTIONS
1. Read Instructions - All the safety and operating
instruction should be read before the product is
operated.
2. Retain Instructions - The safety and operating
instruction should be retained for future reference.
3. Heed Warnings - All warning on the product and
in the operating instructions should be adhered to.
4. Follow instructions - All operating and use
instructions should be followed.
5. Cleaning - Unplug this product from the wall outlet
before cleaning. Do not use liquid cleaners or
aerosol cleaners. Use a damp cloth for cleaning.
6. Attachments - Do not use attachments not
recommended by the product manufacturer as they
may cause hazards.
7. Water and Moisture - Do not use this product near
water - for example, near a bath tub, wash bowl,
kitchen sink, or laundry tub; in a wet basement, or
near a swimming pool, and the like.
8. Accessories - Do not place this product on an
unstable cart, stand tripod, bracket, or table. The
product may fall, causing serious injury to a child
or adult, and serious damage to the product. Use
only with a cart, stand, tripod, bracket, or table
recommended by the manufacturer, or sold with
the product. Any mounting of the product should
follow the manufacturer? instructions, and should
use a mounting accessory recommended by the
manufacturer.
9. A product and cart combination should be mo ed
with care. Quick stops, excessi e force, and une en
surfaces may cause the appliance and cart
combination to o erturn.
12. Grounding or Polarization - This product may be
equipped with a polarized alternating-current line
plug (a plug ha ing one blade wider than the other).
This plug will fit into the power outlet only one way.
This is a safety feature. If you are unable to insert
the plug fully into the outlet, try re ersing the plug.
If the plug should still fail to fit, contact your
electrician to replace your obsolete outlet. Do not
defeat the safety purpose of the polarizes plug.
Alternate Warnings - This product is equipped with
a three-wire grounding-type plug, a plug ha ing a
third (grounding) pin. This plug will only fit into a
grounding-type power outlet. This is a safety feature.
If you are unable to insert the plug into the outlet,
contact your electrician to replace your obsolete
outlet. Do not defeat the safety purpose of the
grounding-type plug.
13. Power-Cord Protection - Power supply cords should
be routed so that they are not likely to be walked
on or pinched by items placed upon or against
them, paying particular attention to cords at plugs,
con enience receptacles, and point where they
exit from the product.
14. Protecti e Attachment Plug - The product is
equipped with an attachment plug ha ing o erload
protection. This is a safety feature. See Instruction
Manual for replacement or resetting of protecti e
de ice. If replacement of the plug is required, be
sure the ser ice technician has used a replacement
plug specified by the manufacturer that has the
same o erload protection as the original plug.
15. Outdoor Antenna Grounding - If an outside antenna
is connected to the recei er, be sure the antenna
system is grounded so as to pro ide some
protection against oltage surges and built-up static
charges. Article 810 of the National Electrical Code,
ANSI/NFPA 70, pro ides information with regard
to proper grounding of the mast and supporting
structure, grounding of the mast and supporting
structure, grounding of the lead-in wire to an
antenna-discharge unit, size of grounding
conductors, location of antenna-discharge unit,
connection to grounding electrodes, and
requirements for the grounding electrode.
17. Power Lines - An outside antenna system should
not be located in the icinity of o erhead power
lines or other electric light or power circuits, or
where it can fall into such power lines or circuits.
When installing an outside antenna system, extreme
care should be taken to keep from touching such
power lines or circuits as contact with them might
be fatal.
18. O erloading - Do not o erload wall outlets,
extension cords, or integral con enience
receptacles as this can result in a risk of fire or
electric shock.
19. Object and Liquid Entry - Ne er push objects of
any kind into this product through openings as they
may touch dangerous oltage points or short-out
parts that could result in a fire or electric shock.
Ne er spill liquid of any kind on the product.
20. Ser icing - Do not attempt to ser ice this product
yourself as opening or remo ing co ers may expose
you to dangerous oltage or other hazards. Refer
all ser icing to qualified ser ice personnel.
21. Damage Requiring Ser ice - Unplug this product
from the wall outlet and refer ser icing to qualified
ser ice personnel under the following conditions:
a) When the power-supply cord or plug is damaged,
b) If liquid has been spilled, or objects ha e fallen
into the product,
c) If the product has been exposed to rain or water,
d) If the product does not operate normally by following
the operating instructions. Adjust only those controls
that are co ered by the operating instructions as
an improper adjustment of other controls may result
in damage and will often require extensi e work
by a qualified technician to restore the product to
its normal operation.
e) If the product has been dropped or damaged in
any way, and
f) When the product exhibits a distinct change in
performance - this indicates a need for ser ice.
22. Replacement Parts - When replacement parts are
required, be sure the ser ice technician has used
replacement parts specified by the manufacturer
or ha e the same characteristics as the original
part. Unauthorized substitutions may result in fire,
electric shock, or other hazards.
23. Safety Check - Upon completion of any ser ice or
repairs to this product, ask the ser ice technician
to perform safety checks to determine that the
product is in proper operating condition.
24. Wall or Ceiling Mounting - The product should be
mounted to a wall or ceiling only as recommended
by the manufacturer.
25. Heat - The product should be situated away from
heat sources such as radiators, heat registers,
sto es, or other products (including amplifiers) that
produce heat.
10. Ventilation - Slots and openings in the cabinet are
pro ided for entilation and to ensure reliable
operation of the product and to protect it from
o erheating, and these openings must not be
blocked or co ered. The openings should ne er
be blocked by placing the product on a bed, sofa,
rug, or other similar surface. This product should
not be placed in a built-in installation such as a
bookcase or rack unless proper entilation is
pro ided or the manufacturer? instruction ha e
been adhered to.
11. Power Sources - This product should be operated
only from the type of power source indicated on
the marking label. If you are not sure of the type
of power supply to your home, consult your product
dealer or local power company. For products
intended to operate from battery power, or other
sources, refer to the operating instruction.
16. Lightning - For added protection for this product
during a lightning storm, or when it is left unattended
and unused for long periods of time, unplug it from
the wall outlet and disconnect the antenna or cable
system. This will pre ent damage to the product
due to lightning and power-line surges.
See figure:
