ExpressPCI UL4D

Host Adapter

Dual-channel Ultra320

SCSI Host Adapter

With PCI-X Support

The UL4D dual-channel Ultra320 host adapter is

the perfect complement to ATTO’s ExpressPCI

family of high-performance SCSI host adapters for

data-intensive environments. Boasting data-

transfer rates of up to 640 MB/sec. and offering

support for advanced PCI-X busses, the UL4D is

an ideal fit for Enterprise servers and high-end

workstations running high-volume, mission-critical

applications such as messaging and databases.

ATTO host adapters offer ATTO’s exclusive

Advanced Data Streaming (ADSTM) technology,

and the ExpressPCI UL4D is no exception. By

effectively managing latency and allowing for fast

and efficient data movement, utilization of the CPU

is reduced, freeing it up to perform other mission

critical tasks.

Installation of the ExpressPCI UL4D host adapter is

a fast and easy. Thanks to ATTO’s factory-preset

configurations, the UL4D is ready out-of-the-box for

plug and play operation. The included

Configuration Utility, featuring an easy-to-use GUI,

simplifies the effort associated with installation,

management and monitoring of the host adapter.

The ExpressPCI UL4D is the first choice for users

working in environments with demanding server

and professional workstation environments. By

offering support for Ultra320 SCSI and PCI-X, in

addition to ATTO-designed performance-enhancing

technologies including ADS, the ExpressPCI UL4D

offers both the performance and feature set neces-

sary for today’s data-intensive applications.

Technical Highlights

• Ultra320 SCSI

• Up to 320 MB/sec. per

channel data-transfer

rates

• Dual independent SCSI

channels (2 internal and

2 external connector

availability)

• 64-bit/133 MHz PCI-X

with backward

compatibility

• Exclusive ADSTM

technology

• Supports up to 30 SCSI

bus IDs

• Up to 12 meter cable

lengths

• RoHS Compliant

• 3-year standard

product warranty

Blazing Fast Performance

• Maximize data throughput

with dual channel connectivity

aggregating performance

across multiple SCSI ports

• Leveraging the latest in SCSI

storage connectivity, the

UL4D delivers up to 640 MB/

sec. data throughput, making

it twice as fast as Ultra160

SCSI.

Smooth Data Streaming

• Maintain accessibility to

mission-critical data by

transparently redirecting data

requests through alternate

channels.

• Alleviate data transfer

bottlenecks and move data

more efficiently while

managing latency with

ATTO’s exclusive ADS™

technology.

One Click Installation

• Save time with factory preset

configuration for plug and play

operation.

• Simplify installation,

management and monitoring

with multi-platform

Configuration Utility featuring

an intuitive GUI.

ExpressPCI UL4D

Rev 4/08

Technical Specification Power Behind the Storage

For More Information:

www.ATTOTech.com

or to Purchase:

www.ATTOStore.com

(716) 691-1999

Hardware Specifications

SCSI Interface • 320 MB/sec. per channel data-transfer rates

• Two (2) external VHDCI and two (2) internal high-density connectors per channel

• Low Voltage Differential (LVD) signaling

• Support for tagged command queuing

• Backward compatible with Ultra160, Ultra2, Ultra/WIDE, Fast/WIDE & Narrow SCSI devices

Advanced SCSI • Supports dynamic bus rescan (OS X) •Quick Arbitration Select (QAS)

• Double transition clocking •ASPI compliant (for PC users)

• Domain validation •Bootable from attached disks

• Cyclical Redundancy Checking (CRC) •Support for disconnect/reconnect

• Packetization •Support for multiple block sizes

Accelerated PCI Bus Management • PCI-X bus master rate of 1 GB/sec.

• PCI-X 1.0a compliant

• PCI 2.2 and PCI 99 compliant

• 64-bit/133 MHz PCI-X (backward compatible with standard PCI)

General Characteristics • Automatic termination

• Upper-byte termination for Narrow devices

• Flash ROM for easy field upgrades

• Plug and play compatible

• Includes ATTO ExpressPro-ToolsTM & ATTO Configuration Tool formatting & utility software

Software Specifications

Driver Support • Windows®Server 2003, 2008, XP, Vista

• Mac®OS X (v10.4.x & v10.5.x)

• Linux (Fedora, Red Hat and SuSE)

• Novell Netware®v6.5

Agency Approvals

Safety and Environmental • FCC Rules, Part 15 Sub-Part B, Class A

• CE Mark: CISPR 22 / EN 55022, Class A

Environmental & Physical Specifications

Dimensions • Length 6.521”

• Height 4.450”

Operating Environment • Temperature: 0-45° C

• Humidity: 10-90% non-condensing

• Airflow: 100 LFM (min)

Reliability • MTBF = 150,000 hours

• MTTR < 15 Minutes

Power • 0.75 typical/2.0 max. Amps @ + 5.0 VDC

• 0.05 Amps @ + 12.0 VDC

PCI Signal Compatibility • 3.3 Volts/5 Volts universal

RoHS Compliant • Yes

Ordering Information

Model Number • EPCI-UL4D-0R0 (RoHS)

Advanced Data Streaming (ADSTM) • Improved PCI system bandwidth use

• Optimized SCSI-3 algorithms

• Tagged command queuing

• Embedded RISC I/O processor

RAID Options • RAID 0 support with ATTO Express Power Center or ExpressStripe RAID software utilities

ExpressPCI UL4D

Host Adapter

ExpressPCI UL4D
