ATN PS22-2

ATN PS22-2 is a state of the art Night Vision

System, which mounts in the front of any daytime

weapon sight and gives ultimate Day/Night solution.

The PS22-2 mounts in front of your daytime scope in

a matter of minutes for night time operation. It does

not require any zeroing when mounted; the day sight

provides the aiming point. The PS22-2 allows the

use of all the features of your daytime scope during

the night. The system is one of the most compact

and light weight NV systems in its class, only 650

grams. The ATN PS22-2 brings a whole new imen-

sion to the world of Night Vision Weapon Sights!

HIGH QUALITY 2 GEN IMAGE INTENSIFIER TUBE

DESCRIPTION...............................

STANDARD

GENERATION................................

PHOTOCATHODE TYPE.................

MULTI - ALKALI

RESOLUTION, LP/MM * ................

40 - 45

SIGNAL-TO-NOISE RATIO*............

12 - 20

EXPORT.........................................

N/A FOR EXPORT

FIGURE OF MERIT ........................

LESS THEN 1250

* Specifications are provided for informational purposes only. Actual values may vary

MAGNIFICATION .............. 1X

FOV ................................... 13 DEG.

LENS SYSTEM ................. MIRROR LENS

FOCAL LENGHT ............... 80 MM

F-STOP ............................. 1:1,44

INTEROCULAR

DISTANCE ........................ 65 MM

EXIT PUPIL ....................... 21 MM

FOCUS .............................. 10 M TO INFINITY

POWER SUPPLY .............. ONE 3 VOLT LITHIUM

CR123A

BATTERY LIFE, MIN ......... 60 HOURS

OPERATING TEMP, C ...... - 40 ... +50

STORAGE TEMP, C ......... - 50 ... +70

WATER PROOF ................ 10 M

DIMENSIONS .................... 137 X 79 X 79 MM

WEIGHT ............................ 650 G

Export Warning: These products are subject to one or more of the export control laws and regulations of the U.S. Government. Pending the model these products are under the control

jurisdiction of either the US Department of State or the US Bureau of Industry and Security US Department of Commerce. Export without proper licensing or consent is strictly prohibited.
