ATN 10x42RF

user’s manual

Important Export Restrictions! Commodities,

products, technologies and services contained in

this manual are subject to one or more of the export

control laws and regulations of the U.S. Government

and they fall under the control jurisdiction of either the

US Department of State or the US BIS-Department

of Commerce. It is unlawful and strictly prohibited

to export, or attempt to export or otherwise transfer

or sell any hardware or technical data or furnish

any service to any foreign person, whether abroad

or in the United States, for which a license or written

approval of the U.S. Government is required, without

first obtaining the required license or written approval

from the Department of the U.S. Government having

jurisdiction. Diversion contrary to U.S. law is prohibited.

OMEGA CLASS BINOCULAR

USER’S GUIDE (ATN 10X42RF) REVISION 2 - SEPTEMBER 2009

The information in this manual furnished for information use only, is subject to

change without notice, is not to be construed as a commitment by ATN Corp.

ATN Corp. assumes no responsibility or liability for any errors or inaccuracies

that may appear in this book.

This producT conTains naTural rubber

laTex which may cause allergic reacTions.

CAUTION:

neVer looK aT The sun!

iT may cause loss oF sighT.

ATTENTION!

Durable rubber armor body

Diopter

adjustment

Neck strap loops

Lenses

Rubber lens cap

Cap of threaded hole for tripod adapter

FEATURES

• Meets standards and requirements of MIL-STD810

• Built for professional use

• Multi-Coated Optics

• Built-in Rangefinder

• Full rubber armouring

• Waterproof & shockproof

• O-ring sealed & Nitrogen purged

• Two year warranty

SPECIFICATIONS

Magnification ............................................. 10X

Objective Lens Diameter ........................... 42 mm

Eye Relief .................................................. 10 mm

Minimum Focusing Distance ...................... 6 m

Field of View ............................................... 6°

Field of View at 1000 m .............................. 105 m

Exit Pupil Diameter .................................... 4.2 mm

Interpupillary Adjustments ......................... 56.5-75 mm

Max. Width ................................................. 5.2”/ 132 mm

Length ........................................................ 6.1”/ 155 mm

Weight ........................................................ 26.9 oz/ 0.76 kg

APPLICATION

ATN is proud to introduce its professional brand of daytime binoculars:

the Omega line. Years of manufacturing German quality glass for our

Night Vision equipment have allowed us to produce a binocular line

with exceptional quality at a reasonable price.

The Omega binoculars are technologically advanced with special

coated optics, nitrogen filled, durable rubber armour, and either a built-

in range finder or a built-in compass. These binoculars are tough, pro-

vide a crystal clear image, and are of the highest quality.

Each model is durable enough to withstand the harshest conditions

and is designed to perform under the most stressful situations. This is

* ATN reserves the right to change the above specifications at any time without notice

guaranteed by the lifetime manufacturer’s defect warranty on all of the

models in the Omega line.

ATN’s 10x42RF daytime Omega class binoculars are the quintessential

professional binoculars. They provide a sharp stable image with excel-

lent low-light performance.

Features multi-coated optics for superior light transmission, individual

diopter focus for clearer images, built-in range finder reticle and full

rubber armouring for increased shock resistance.

The combination of waterproof and high quality optics make it the per-

fect binocular for military, law enforcement, boating as well as for most

hunting uses.

Meets standards and requirements of MIL-STD810 for a lifetime of high

performance.

PREPARING THE BINOCULAR

Your ATN OMEGA Series binocular comes with a neck strap. We rec-

ommend that you install the neck strap and use it whenever you are

using the binocular.

NOTE: Many accidents can be avoided by using the neck strap.

ATTACHING THE NECK STRAP

Thread the neck strap through the neck strap loop on the body of the

binocular.

Bring the end of the strap back to the neck strap buckle. Thread the

neck strap end from the back, through the buckle, as shown in the illus-

tration. This will secure the neck strap. Using the same procedure on

the other side, adjust the length of the neck strap for the comfort of the

user.

OCULAR LENS COVER

The ocular lens cover or “rain guard” has a loop for the neck strap to

thread through one side. This cover protects the ocular lenses from

debris and rain while the binocular is being carried by use of the neck

strap. The rain guard hangs down out of the way when the binocular is

being used.

ADJUSTING THE BINOCULAR FOR USE

All binoculars must be adjusted to the individual using the binocular.

The following procedures will assure maximum enjoyment and proper

use.

INTERPUPILLARY DISTANCE ADJUSTMENT

This adjustment uses the binoculars’ hinge pin to adjust to the distance

between the user’s eyes. With the proper adjustment, the user sees a

round full circle, not two circles. Move the barrels in or out until a round

full circle is seen through the unit. With this adjustment made, you are

now ready to focus the binocular.

INDIVIDUAL EYE FOCUS SYSTEM

The OMEGA Series binoculars are equipped with the individual eye

focus system. This is the focus system preferred by military units around

the world. Once you adjust the binocular to your vision at approximately

100 yards, the unit will be in focus without additional adjustment to an

infinite distance.

To focus the binocular, close your right eye and look through the left

barrel. Turn the left ocular eyepiece to the right or left until you see a

sharp, clear image. Use the same procedure for the right eye. Now your

binocular is focused.

Both right and lef t ocular eyepieces have + / - diopter markings. Remem-

bering the setting or marking the diopter setting with a permanent

marker makes refocusing the unit easy if another person has used the

binocular and changed the settings.

TRIPOD ADAPTER

Your OMEGA Series binocular is designed to be used with a tripod

adapter for mounting the unit on a tripod or window mount. To use this

feature requires the use of a ATN tripod adapter. To install the tripod

adapter, unscrew the knurled cap that is centered on the hinge pin.

Under the cap is a 1/4x20 N.C. threaded hole. Follow the instructions

included with the tripod adapter for proper installation. Tripod adapters

are available from ATN or your sport optic dealer.

NOTE: Severe damage to the binocular can occur if the tripod collapses

or is knocked over. It is recommended that the binocular be removed if

the user is not within arm’s reach of the tripod.

RANGEFINDER RETICLE

ATN 10x42RF Binocular Reticle displays the reticle on the right view

side. Reticle focus can be adjusted via an left side eyepiece diopter.

The 10x42RF reticle is universal for different distance. The Reticle has

the 5 to 10 mil increments in the center for long distance, large target

ranging ability and single mil, half mil spacing on the outer reticle quad-

rants for smaller targets or greater distances. An open Un-Obstructed

field of view is critical for Observation.

36 inch Target measured with

Mil-Reticle as: 5.25 mils tall.

Distance to target: 191 Yards

36 inch Target measured with

Mil-Reticle as: 6.5 mils tall.

Distance to target: 154 Yards

5 mils

1 mil

.5 mil

5 mils

.5 mil

RETICLE USE EXAMPLES

10 mils

5 mils

1 mil

.5 mil

36 inch Target measured with

Mil-Reticle as: 3.5 mils tall.

Distance to target: 286 Yards

36 inch Target measured with

Mil-Reticle as: 2.25 mils tall.

Distance to target: 450 Yards

1 mil

.5 mil

1 mil

.5 mil

MAINTENANCE

Your binocular is designed for years of trouble free use. Following a few

service recommendations will ensure years of service.

OCULAR LENS COVERS

Ocular lens covers are provided to protect the objective lenses of your

binocular. Keeping the lenses protected when not in use reduces the

amount of dust or debris that settles on the lenses.

BINOCULAR CASE

A rugged binocular case is provided to protect your unit when travelling

and not in use.

CLEANING YOUR BINOCULAR

Keeping your binocular clean and dry will allow you maximum enjoy-

ment and trouble-free service. Remove dust and debris with a soft

brush or compressed air.

If your binocular is used at sea, or near a salt-water environment, it is

strongly recommended that you rinse the binocular in fresh water. This

removes salt that may damage your unit.

LENS CLEANING

Dust, salt and the oil left from fingerprint smudges should never be

allowed to remain on the lenses because they can harm the sensitive

multi-coatings applied to the lens surfaces.

Loose dust and debris should be removed by blowing the debris off,

using an optical lens cleaning brush or compressed air.

If fingerprints or smudges remain on the lens, use an optical lens tissue

and lens cleaner solution to clean the lenses. Follow the instructions on

the lens cleaning tissue and cleaner. Lens cleaning supplies are avail-

able from ATN or all camera or optical stores.

NOTE: Do not “over clean” lenses. Excessive cleaning can damage

lens coatings. Do not use household cleaners on the lenses of the bin-

ocular.

HELPFUL TIPS FOR BINOCULAR USERS

• Never leave your binocular exposed to direct sunlight for extended

periods. This can cause damage to the armour coatings or eyepieces.

Th e dashb oard of a n auto mo b il e is n ot a pr oper s tor age lo c atio n for your

binocular, the sunlight is greatly magnified through the windshield.

• Use the neck strap as your “insurance policy” against dropping the

binocular.

• Never walk away from a binocular on a tripod; remove it if you are not

within arm’s length of the tripod.

• Store your binocular in its case and in a cool, dry location.

• Avoid severe temperature fluctuations. For example, bringing it from

an extremely cold condition into a heated environment could cause

condensation build up.

WARRANTY

2 YEAR PRODUCT WARRANTY

This product is guaranteed to be free from manufacturing defects

in material and workmanship under normal use for a period of 2

(two) years from the date of purchase. In the event a defect that is

covered by the foregoing warranty occurs during the applicable pe-

riod stated above, ATN, at its option, will either repair or replace the

product, and such action on the part of ATN shall be the full extent

of ATN’s liability, and the Customer’s sole and exclusive remedy.

This warranty does not cover a product (a) used in other than its

normal and customary manner; (b) subjected to misuse; (c) sub-

jected to alterations, modifications or repairs by the Customer of

by any party other than ATN without prior written consent of ATN;

(d) special order or “close-out” merchandise or merchandise sold

“as-is” by either ATN or the ATN dealer; or (e) merchandise that has

been discontinued by the manufacturer and either parts or replace-

ment units are not available due to reasons beyond the control of

ATN. ATN shall not be responsible for any defects or damage that in

ATN’s opinion is a result from the mishandling, abuse, misuse, im-

proper storage or improper operation, including use in conjunction

with equipment which is electrically or mechanically incompatible

with or of inferior quality to the product, as well as failure to main-

tain the environmental conditions specified by the manufacturer.

CUSTOMER IS HEREBY NOTIFIED THAT OPERATION OF THE

EQUIPMENT DURING DAYLIGHT HOURS OR UNDER ANY EX-

CESSIVE LIGHT CONDITIONS MAY PERMANENTLY DAMAGE

THE INTERNAL COMPONENTS OF THE UNIT AND SAID DAM-

AGE WILL NOT BE COVERED UNDER THIS WARRANTY. This

warranty is extended only to the original purchaser. Any breach of

this warranty shall be waived unless the customer notifies ATN at

the address noted below within the applicable warranty period.

The customer understands and agrees that except for the foregoing

warranty, no other warranties written or oral, statutory, expressed or

implied, including any implied warranty of merchantability or fitness

for a particular purpose, shall apply to the product. All such implied

warranties are hereby and expressly disclaimed.

LIMITATION OF LIABILITY

ATN will not be liable for any claims, actions, suits, proceedings,

costs, expenses, damages or liabilities arising out of the use of this

product. Operation and use of the product are the sole responsibil-

ity of the Customer. ATN’s sole undertaking is limited to providing

the products and services outlined herein in accordance with the

terms and conditions of this Agreement. The provision of products

sold and services performed by ATN to the Customer shall not be

interpreted, construed, or regarded, either expressly or implied, as

being for the benefit of or creating any obligation toward any third

party of legal entity outside ATN and the Customer; ATN’s obliga-

tions under this Agreement extend solely to the Customer. ATN’s

liability hereunder for damages, regardless of the form or ac-

tion, shall not exceed the fees or other charges paid to ATN by

the customer or customer’s dealer. ATN shall not, in any event,

be liable for special, indirect, incidental, or consequential

damages, including, but not limited to, lost income, lost rev-

enue, or lost profit, whether such damages were foreseeable

or not at the time of purchase, and whether or not such dam-

ages arise out of a breach of warranty, a breach of agreement,

negligence, strict liability or any other theory of liability.

PRODUCT WARRANTY REGISTRATION

In order to validate the warranty on your product, ATN must receive

a completed Product Warranty Registration Card for each unit or

complete warranty registration on our website at www.atncorp.

com. Please complete the included form and immediately mail it

to our Service Center: ATN Corporation, 1341 San Mateo Avenue,

South San Francisco, CA 94080.

OBTAINING WARRANTY SERVICE

To obtain warranty service on your unit, End-user must notify ATN

service department by calling 800-910-2862 or 650-989-5100 or

via e-mail service@atncorp.com to receive a Return Merchandise

Authorization number (RMA). When returning please take or send

the product, postage paid, with a copy of your sales receipt to our

service center, ATN Corporation at the address noted above. All

Table des matières

Manuels Jumelles populaires d'autres marques

Celestron

Celestron VistaPix 72218 Manuel utilisateur

Levenhuk

Levenhuk Atom Digital DNM200 Manuel utilisateur

Bresser

Bresser TOPAS 7x50 Manuel utilisateur

Berger & Schroter

Berger & Schroter LN-G3-B50 Manuel utilisateur

Leica

Leica geovid 8x42 HD-R Manuel utilisateur

Noblex

Noblex NF 8 x 42 inception Manuel utilisateur

Newcon Optik

Newcon Optik AN Series Manuel utilisateur

PHOTONIS

PHOTONIS VYPER Manuel utilisateur

Famous Trails

Famous Trails ViewCatcher DCB 822 Manuel utilisateur

AGM

AGM EXPLORATOR FSB50-640 Manuel utilisateur

Opticron

Opticron Marine-3 7x50 BIF.GA Guide d'installation

Kayoba

Kayoba 009129 Manuel utilisateur

Vixen

Vixen ARENA Series Manuel utilisateur

MAGINON

MAGINON NVB 60 Manuel utilisateur

Leica

Leica Geovid 56 Manuel utilisateur

Leica

Leica GEOVID PRO Manuel utilisateur

Celestron

Celestron LandScout Manuel utilisateur

APM

APM ED Apo Series Manuel utilisateur
