User Manual
AtlonA
VGA with Stereo Audio Extender
Kit over single CAT5/6/7
with DDC Support
AT-RGB45SR
2
TABLE OF CONTENTS
1. Introduction .................................................. 3
2. Applications .................................................. 3
3. Package Contents .................................................. 3
4. Features .................................................. 3
5. Specication .................................................. 4
6. Hardware Description .................................................. 4
6.1. Front Panel .................................................. 4
6.2. Rear Panel .................................................. 5
7. Pin Assignment .................................................. 5
8. Connection and Installation .................................................. 6
9. Atlona Product Registration .................................................. 6
10. Safety Information .................................................. 7
11. Warranty .................................................. 8
3
INTRODUCTION
PACKAGE CONTENTS
APPLICATIONS
The Atlona AT-RGB45SR (transmitter and Receiver) Extender units with stereo Audio allow users to
extend Video signal with resolutions VGA~WUXGA (640x480~1920x1200) up to 150ft (45m). The RG-
B45SR is designed to extender both audio and video on a single low cost CAT5, 6 or 7 Cable. The
extenders are featured with DDC (EDID) support, which is needed for video cards to know what the
display capabilities are.
The AT-RGB45SR extenders transfer signal in real time with less than 2ms of delay.
Note: The AT-RGB45SR is capable of sending Component Video signal via VGA/Component adapters.
• Ofce Workstation: PC to Monitor Extension allows extending video and audio up to 150ft away from
the workstation.
• Conference Room or Boardroom: PC to Projector Extension allows extending video signal over long
distance utilizing existing CAT5, 6 or 7 cables. This solution is perfect for Schools and Universities.
• Computer/Monitor Testing: Since the AT-RGB45SR are capable of supporting DDC (EDID), it would
make it easy for QA department to test Displays/computers which are further away from the testing
area.
• Airport/Train Station: The RGB45SR’s are based on low power chip-set which is designed to work for
many years without a need to reboot/reset.
• AT-RGB45SR (transmitter and Receiver are included)
• 5V DC power supply x 2
• Operation Manual
FEATURES
• Transmits real time Video and Audio up to 150ft
• Supports extremely high resolutions up to WUXGA (1920x1200)
• Supports DDC (EDID), allows video card to know what the display capabilities are.
• Based on the low power chip-set, therefore can last many years without reboot/reset
• Designed to transmit both Video and Audio on low cost CAT5/6/7 Cable
• Support Hot Plug Detect
4
SPECIFICATIONS
HARDWARE DESCRIPTION
Input Port Transmitter 1 x VGA, 1 x 1/8-inch (3.5mm) jack
Receiver 1 x RJ45
Output Port Transmitter 1 x RJ45
Receiver 1 x VGA, 1 x 1/8-inch (3.5mm) jack
CAT6 Cable* 150ft (45m)
Support resolution 640x480@60/72/75/85, 720x400@70,
800x600@56/60/72/75/85, 1024x768@60/70/75,1280x720@60,
1280x768@60, 1280x800@60RB/60, 1280x960@60,
1280x1024@60/75, 1366x768@60RB/60,
1440x900@60RB/60/75, 1680x1050@60, 1600x1200@60,
1920x1080@60p,1920x1200@60RB
ESD Protection Human body model: ± 8kV (air-gap discharge)
± 4kV (contact discharge)
Dimensions (inch) 3.1(W) x 3.58(D) x 1.18(H)
Power Supply 2x5V DC / 2.6A (100~240V)
Weight (lb) 0.5 each unit
Chassis Material Aluminum
Power Consumption Transmitter: 1W, Receiver: 1W
Operating Temperature 0˚C~40˚C / 32˚F ~ 104˚F
Storage Temperature -20˚C~60˚C / -4˚F ~ 140˚F
Relative Humidity 20~90% RH (non-condensing)
6.1. Front Panel
Transmitter Receiver
1 2 3 4
1. AUDIO INPUT: This input is for connecting audio output from the sound card of the computer. For
audio to be transferred, video signal in the VGA INPUT is required.
2. VGA INPUT: This input is for connecting VGA (HD15) output of the computer.
3. AUDIO OUTPUT: This output is for connecting audio output from receiver module to a set of
powered speakers or monitor with speakers.
* Atlona recommends using CAT6 UTP (solid) cables; however the RGB45SR unit can work with
standard Cat5, Cat5e, Cat6, and Cat7 cables.
5
6.2. Rear Panel
Transmitter Receiver
1 12 2
1. RJ-45 OUTPUT / INPUT: Connect CAT5, 6 or 7 cable up to 150ft
2. DC 5V: Connect with supplied power supplies
4. VGA OUTPUT: This output is for connecting video output from receiver module to VGA (HD15)
input on the computers monitor/projector.
6
CONNECTION AND INSTALLATION
ATLONA PRODUCT REGISTRATION
Thank you for purchasing this Atlona product — we hope you’ll enjoy it.
We also hope that you’ll take a few moments to register your new purchase. Registration creates an ownership
record if your product is lost or stolen and helps ensure you’ll receive notication of performance issues and rmware
updates.
At Atlona, we respect and protect your privacy and assure you that your registration information is completely
secure. Of course, Atlona product registration is totally voluntary and failure to register will not diminish your limited war-
ranty rights.
3.5 phone jack
3.5 phone
jack
VGA Cable
VGA Cable
1xCAT6 Cable
PC
or
Notebook
Display
Projector
or
AT-RGB45SR
Transmitter
AT-RGB45SR
Receiver
7
SAFETY INFORMATION
Safeguards
To reduce the risk of electric shock, do not
expose this product to rain or moisture.
If the wall plug does not t into your local
power socket, hire an electrician to replace
your obsolete socket.
Do not modify the wall plug.
Doing so will void the warranty and safety
features.
This equipment should be installed near
the socket outlet and the device should
be easily accessible in case it requires
disconnection.
Precautions
FCC Regulations state that any
unauthorized changes or modications to
this equipment not expressly approved by
the manufacturer could void the
user’s authority to operate this
equipment.
Operate this product using only the
included external power supply. Use of
other power supplies could impair
performance, damage the product or cause
res.
In the event of an electrostatic discharge,
this device may automatically turn off. If this
occurs, unplug the device, and plug it back
in.
Protect and route power cords so they will
not be stepped on or pinched by anything
placed on or against them. Be especially
careful of plug-ins, or cord exit points from
this product.
Avoid excessive humidity, sudden
temperature changes or temperature
extremes.
Keep this product away from wet locations
such as bathtubs, sinks, laundries, wet
basements and swimming pools.
Use only accessories recommended by
ATLONA to avoid re, shock or other
hazards.
Unplug the product before cleaning. Use
a damp cloth for cleaning. Do not use
cleaning uid or aerosols, which could
enter the unit and cause damage, re or
electrical shock. Some substances may
also mar the nish of the product.
Never open or remove unit panels or make
any adjustments not described in this
manual. Attempting to do so could expose
you to dangerous electrical shock or other
hazards. It may also cause damage to your
AT-RGB45SR. Opening the product will void
the warranty.
Do not attempt to service the unit. Instead
disconnect it and contact your Authorized
ATLONA reseller or contact ATLONA
directly.
8
1. LIMITED WARRANTY
Atlona Technologies warrants that (a) its products (the “Product”) will perform substantially in accordance with the ac-
companying written materials for a period of 3 YEARS from the date of receipt and (b) that the Product will be free from
defects in materials and workmanship under normal use and service for a period of 3 years. In the event applicable law
imposes any implied warranties, the implied warranty period is limited to 3 years from the date of receipt. Some jurisdic-
tions do not allow such limitations on duration of an implied warranty, so the above limitation may not apply to Customer.
2. CUSTOMER REMEDIES
Atlona Technologies and its suppliers’ entire liability and Customer’s exclusive remedy shall be, at Atlona Technologies’
option, either return of the price paid for the Product, or repair or replacement of the Product that does not meet this
Limited Warranty and which is returned to Atlona Technologies with a copy of Customer’s receipt. This Limited Warranty
is void if failure of the Product has resulted from accident, abuse, or misapplication. Any replacement Product will be war-
ranted for the remainder of the original warranty period or 3 year, whichever is longer.
3. NO OTHER WARRANTIES
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, ATLONA TECHNOLOGIES AND ITS SUPPLIERS
DISCLAIM ALL OTHER WARRANTIES, EITHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO IM-
PLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, WITH REGARD TO
THE PRODUCT AND ANY RELATED WRITTEN MATERIALS. THIS LIMITED WARRANTY GIVES CUSTOMER SPE-
CIFIC LEGAL RIGHTS. CUSTOMER MAY HAVE OTHER RIGHTS DEPENDING ON THE JURISDICTION.
4. NO LIABILITY FOR DAMAGES
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO EVENT SHALL ATLONA TECHNOLOGIES OR
ITS SUPPLIERS BE LIABLE FOR ANY DAMAGES WHATSOEVER (INCLUDING WITHOUT LIMITATION, SPECIAL, IN-
CIDENTAL, CONSEQUENTIAL, OR INDIRECT DAMAGES FOR PERSONAL INJURY, LOSS OF BUSINESS PROFITS,
BUSINESS INTERRUPTION, LOSS OF BUSINESS INFORMATION, OR ANY OTHER PECUNIARY LOSS) ARISING
OUT OF THE USE OF OR INABILITY TO USE THIS PRODUCT, EVEN IF ATLONA TECHNOLOGIES HAS BEEN AD-
VISED OF THE POSSIBILITY OF SUCH DAMAGES. IN ANY CASE, ATLONA TECHNOLOGIES’ AND ITS SUPPLIERS’
ENTIRE LIABILITY UNDER ANY PROVISION OF THIS AGREEMENT SHALL BE LIMITED TO THE AMOUNT ACTU-
ALLY PAID BY YOU FOR THE PRODUCT. BECAUSE SOME JURISDICTIONS DO NOT ALLOW THE EXCLUSION OR
LIMITATION OF LIABILITY FOR CONSEQUENTIAL OR INCIDENTAL DAMAGES, THE ABOVE LIMITATION MAY NOT
APPLY TO YOU.
