Atid AT388 Manuel utilisateur
AT388 User guide
AT388 Product User guide
Moon-Cheol Song
2017-09-04
ATID CO., LTD
UHF Reader
AT388 User guide Page 2
AT388 User guide
AT388 Product User guide
Company
Atid Co., Ltd.
Doc
Name
User guide
Writer
Moon-Cheol
Song
Date
2017-09-04
Ver.
v0.1
Revision History
Version
Revised Date
Revised
Reason
Revised Contents
Writer
V0.1
2017-09-04
Draft
Issue Draft
MoonCheol Song
AT388 User guide Page 3
AT388 User guide
AT388 Product User guide
Company
Atid Co., Ltd.
Doc
Name
User guide
Writer
Moon-Cheol
Song
Date
2017-09-04
Ver.
v0.1
Contents
Contents ..........................................................................................................................................................................................3
1Before Beginning, ..............................................................................................................................................................5
2Product Overview ..............................................................................................................................................................5
3Strength of Product..........................................................................................................................................................6
4H/W Specification..............................................................................................................................................................7
5Product Composition.......................................................................................................................................................9
5.1 Product Composition .......................................................................................................................................9
5.2 Composition of Each Product`s Part...................................................................................................... 10
5.3 Function of Each Button .............................................................................................................................. 14
5.4 Configuration and operation of the Lamp ......................................................................................... 15
5.5 Screen Composition....................................................................................................................................... 16
5.5.1 State Display Section..................................................................................................................................... 16
5.5.2 Message Output Section............................................................................................................................. 17
6Basic Function of Device............................................................................................................................................. 17
6.1 Basic Function of Device ............................................................................................................................. 17
6.1.1 Scan Mode......................................................................................................................................................... 17
6.1.2 Scan configuration Menu............................................................................................................................ 17
6.1.3 System Configuration.................................................................................................................................... 18
6.2 Power ON and OFF........................................................................................................................................ 18
6.2.1 Power ON ........................................................................................................................................................... 18
6.2.2 Power OFF .......................................................................................................................................................... 19
6.3 Barcode Data Reading(Barcode Scan)................................................................................................... 19
6.4 RFID Tag Data Reading(RFID Scan) ........................................................................................................ 20
6.5 Scan Configuration......................................................................................................................................... 20
6.6 System Configuration.................................................................................................................................... 21
7Settings & Changes....................................................................................................................................................... 22
7.1 Scan Configuration......................................................................................................................................... 22
7.1.1 “1. View data” ................................................................................................................................................... 22
7.1.2 “2. Upload data” .............................................................................................................................................. 22
7.1.3 “3. Erase data” .................................................................................................................................................. 22
AT388 User guide Page 4
AT388 User guide
AT388 Product User guide
Company
Atid Co., Ltd.
Doc
Name
User guide
Writer
Moon-Cheol
Song
Date
2017-09-04
Ver.
v0.1
7.1.4 “4. Data space”................................................................................................................................................. 22
7.1.5 “5. Comm & Mode”....................................................................................................................................... 23
7.1.6 “6. Poweroff Time” .......................................................................................................................................... 23
7.1.7 “7.Network Setup”........................................................................................................................................... 24
7.1.7.1 “1. Show Info” ................................................................................................................................................. 24
7.1.7.2 “2. Host Pairing”............................................................................................................................................. 24
7.1.7.3 “3. DHCP Mode” ............................................................................................................................................ 25
7.1.7.4 “4. Paired Mode”............................................................................................................................................ 25
7.1.7.5 “5. Manual Setup” ......................................................................................................................................... 26
7.2 System Configuration.................................................................................................................................... 26
7.2.1 “1. Symbol Setup” ........................................................................................................................................... 26
7.2.2 “2. OP Mode”.................................................................................................................................................... 26
7.2.3 “3. Comm & Mode”....................................................................................................................................... 28
7.2.4 “4. Data Format”.............................................................................................................................................. 29
7.2.5 “5. System Setup”............................................................................................................................................ 31
7.2.6 “6. Factory Reset”............................................................................................................................................ 33
7.2.7 “7. Exit”................................................................................................................................................................. 33
8Bluetooth Connection setting ............................................................................................................................... 34
9.1 Windows 7 Environment ............................................................................................................................. 34
9.2 Windows 8 or Windows 10 Environment............................................................................................ 39
9Firmware Update....................................................................................................................................................... 42
10.1 Preparation for Firmware............................................................................................................................. 42
10.2 Firmware Update Start ................................................................................................................................. 42
10 Warranty and Technical Supports........................................................................................................................... 46
AT388 User guide Page 5
AT388 User guide
AT388 Product User guide
Company
Atid Co., Ltd.
Doc
Name
User guide
Writer
Moon-Cheol
Song
Date
2017-09-04
Ver.
v0.1
1Before Beginning,
The objective of user guide is to pass the basic contents related with AT388`s maintenance and
smooth uses.
User guide inclusive of text, images, logos, product name may not be distributed, modified,
displayed, reproduced (in whole or in part) without the prior written permission of ATID CO.LTD
Furthermore, the described contents in this document are subject to change without notice for
improving or maintaining the product and we inform the user that some material can be different
with the described contents due to the firmware changes of product.
Ownership of text, images, logos, product name in user guide is included in writer and some parts
of text, images, logos, product name in the user guide were borrowed for user`s understanding at
random. if there is a legal restriction such as a copyright law, it will be re-distributed after adjustment
2Product Overview
AT388 is both subminiature barcode and RFID reader which can grasp with just one hand. As the
device that meets the basic function for industrial product such as IP65 in water & dust test and
1.2 m drop specification, it can take an active as data collector in the various kinds of part in
medicine, stock and product management and logistics shipping/tracking, access control. 1D
Barcode, UHF/HF RFID Tag information can be collected by just one AT388 and collected data can
transfer to the HOST PC or Smart Phone by using Bluetooth or Wireless LAN through Remote
process / real time process / batch process mode. This device is designed to handle the data by
the equipment which has the Windows, Android as an operating system.
AT388 User guide Page 6
AT388 User guide
AT388 Product User guide Company Atid Co., Ltd.
Doc
Name User guide Writer Moon-Cheol
Song Date 2017-09-04 Ver. v0.1
3Strength of Product
AT388 is the smallest product among the existing RFID Barcode Scanner-Reader product
Its device as durable industrial PDA meets IP65 standard for the dust & water
proof and 1.2m drop to concrete.
Apply Honeywell N3680 Barcode module, fast and accurate support for
Barcode data collection.
UHF RFID Tag can be read and written quickly since Impinj R2000 module is
installed in the product
In case of that HF RFID module is installed, Various HF RFID tag can be read
and written.
Mode of Remote Process and Batch Process and Real Time Process can work
for device
It device can be connected with PC and charged up itself through USB Cable.
It can be charged up without exclusive adapter through normal smartphone
charger
Read data through LCD Display can be directly checked.
Battery changes is easily available and its device can change the battery in
case of battery shortage while using it.
Exclusive charging package for only battery charging will be offered
(Option: To be Offered in the near future)
AT388 User guide Page 7
AT388 User guide
AT388 Product User guide Company Atid Co., Ltd.
Doc
Name User guide Writer Moon-Cheol
Song Date 2017-09-04 Ver. v0.1
4H/W Specification
Performance Characteristics
Processor ARM7 Core
Support Operating System Windows(WLAN/BT), Android(BT)
Memory 1Mbit (512Kbyte able to use)
Display 1.3inch LCD & LED Indicator
Weight 270g(without Battery 210g)
Operation Temperature -20~40℃
Storage Temperature -30~70℃
Humidity 95% non-condensing
Drop specification 1.2M Drop to concrete
Dust & Water Proof IP65
Physical Characteristics
Audio Buzzer
Standard I/O Port Bluetooth 4.0
Notification LED, Buzzer, LCD, vibrator
Dimensions(L x W x H) 164 x 50 x 35(54)mm
Battery Supply
Main Battery 3,200mAH Li-Ion Rechargeable Battery
Power Adapter Battery Charger(Option) & DC5V, 2000mA
Network Characteristics
Wireless LAN 802.11 b/g/n Wireless LAN, Key Emulator
Bluetooth Bluetooth 4.1 HID/SPP
Barcode Data Processing Device
Barcode Engine 1D Laser Scanner
AT388 User guide Page 8
AT388 User guide
AT388 Product User guide Company Atid Co., Ltd.
Doc
Name User guide Writer Moon-Cheol
Song Date 2017-09-04 Ver. v0.1
UHF 900MHz RFID Reader/Writer (Option)
Chips set Impinj R2000
Frequency refer to the test report (Support Global Frequency)
Reading Range 0M~3M(According to Tag & Environment)
Writing Range 0M~1.5M(According to Tag & Environment)
Max. RF output
Protocol EPC Gen2, ISO/IEC 18000-6C
Special Function Anti-Collision
AT388 User guide Page 9
AT388 User guide
AT388 Product User guide Company Atid Co., Ltd.
Doc
Name User guide Writer Moon-Cheol
Song Date 2017-09-04 Ver. v0.1
5Product Composition
5.1 Product Composition
The basic package for AT388 is shown as below
< Device Body > <Battery>
< User Guide >
AT388 User guide Page 10
AT388 User guide
AT388 Product User guide Company Atid Co., Ltd.
Doc
Name User guide Writer Moon-Cheol
Song Date 2017-09-04 Ver. v0.1
5.2 Composition of Each Product`s Part
i. Front Side
SCAN Lamp: blue lamp will be lit in case of reading the barcode and RFID Tag
information
Communication State Display Lamp: Show the connection state of Bluetooth,
Wireless LAN
Power Lamp: Show the state-of-charge (Charging : Red, Full Charge : Green)
LCD Display: Show the collected data and current state of device
Arrow Button(Left/Right): Movement of Operation Menu or Setting Menu
Scan Button: Use its button in case of selecting the barcode and RFID Tag
RFID ANT
Scan Button
(Barcode/RFID)
Arrow Button (Right)
Communication port
Change Button
Power/Selection
Button
Arrow Button (Left)
LCD Display
Communication
Status Lamp
SCAN Lamp
Power Lamp
LAMP 충전 램
Reset Button
<Front Side>
Cancel Button
