ATEN CE-700 Manuel utilisateur

User Manual

CE-700

Read this guide thoroughly and follow the installation and

operation procedures carefully in order to prevent any damage to

the units and/or any devices that connect to them.

This package contains:

1 CE-700L KVM Extender (Local Unit)

1 CE-700R KVM Extender (Remote Unit)

1 CS Custom KVM Cable

2 Power Adapters

1 User Manual

If anything is damaged or missing, contact your dealer.

Manual Part No. PAPE-1208-100

Printing Date: 11/2006

ATEN and the ATEN logo are trademarks of ATEN International Co., Ltd. All rights

reserved. All other trademarks are the property of their respective owners.

REMOTE I/O

AC 9V

REMOTE I/O

AC 9V

CE700.fm Page 1 Friday, November 10, 2006 1:52 PM

Note: This equipment has been tested and found to

complywiththelimitsforaClassBdigitaldevice,pursuant

to Part 15 of the FCC Rules. These limits are designed to

provide reasonable protection against harmful

interference in a residential installation. This equipment

generates, uses and can radiate radio frequency energy,

and if not installed and used in accordance with the

instruction manual, may cause interference to radio

communications. However, there is no guarantee that

interference will not occur in a particular installation. If this

equipment does cause harmful interference to radio or

television reception, which can be determined by turning

the equipment off and on, the user is encouraged to try to

correct the interference by one or more of the following

measures:

Reorient or relocate the receiving antenna;

Increase the separation between the equipment and

receiver;

Connect the equipment into an outlet on a circuit

different from that which the receiver is connected;

Consult the dealer or an experienced radio/television

technician for help.

CE700.fm Page 2 Friday, November 10, 2006 1:52 PM

- 3 -

Overview

The CE-700 is a USB (Universal Serial Bus) based KVM

Extender that allows access to a computer system from a remote

USB console (USB keyboard, monitor, and USB mouse).

Because it allows access to a computer system from a remote

console, the CE-700 is perfect for use in any type of installation

where you need to place the console where it is conveniently

accessible,but you wantthesystemequipmenttoreside in asafe

location - away from the dust and dirt of the factory floor, or the

harsh environmental influence of a constructionsite, for example.

The CE-700 is also useful for control and security purposes,

where you can have the system unit in a secure area at the same

time that you put the console in the most convenient location for

user access.

The CE-700 improves on previous designs by: 1) using

inexpensive Cat 5 cable (the kind commonly used in Ethernet

networks), instead of bulkier, more expensive, standard cables,

for a much neater, more convenient, more reliable data transfer

connection; 2) it is able to sense the distance to the system and

automatically adjusts the gain accordingly; and 3) it features a

custom ASIC to ensure the utmost in reliability and compatibility.

Setup is as easy as can be - simply connect the computer system

box and local console to the Local CE-700 Module; run the Cat 5

cable to the Remote CE-700 Module (up to 150 meters away);

and plug the remote console into the Remote Module.

Note: You can control numerous remote systems from a single

console by combining the CE-700 with a KVM switch.

CE700.fm Page 3 Friday, November 10, 2006 1:52 PM

- 4 -

Features

Cat 5 cable to connect the local and remote units – up to 150

meters apart

Auto Signal Compensaton (ASC)

USB Keyboard and USB Mouse Ports

Dual console operation – control your system from both the

local and remote USB keyboard, monitor, and mouse

consoles

USB overcurrent detection and prevention

Push button selection of the active console

High resolution video – up to 1280 x 1024

Supports VGA, SVGA, and multisync monitors

Local monitor supports DDC; DDC2; DDC2B

Hot Pluggable

Easy to install – no software required – connecting cables to

the devices is all it takes

CE700.fm Page 4 Friday, November 10, 2006 1:52 PM

- 5 -

System Requirements

Consoles

A VGA, SVGA, or Multisync monitor capable of the highest

resolution that you will be using on any computer in the

installation

A USB keyboard

A USB mouse

Note: 1. If you connect a DDC type monitor to the Local Unit, the

monitor that connects to the Remote Unit must be able

to support the highest video resolution that the DDC

monitor can provide.

2. You must use the same brand and model of mouse on

both the local and remote units.

Computers

Thefollowing equipmentmust be installedon each computerthat

is to be connected to the system:

A VGA, SVGA, or Multisync card

USB Host Controller and Type A USB Port

Cables

For optimal signal integrity, and to simplify the layout, we

strongly recommend that you use the high quality CS Custom

KVM Cable that is provided with this package.

Cat 5 cable is the minimum required to connect the local and

remote CE-700 units. Cable of a lesser standard will result in

degrading the video signal. For best performance, we strongly

recommend Cat 5 cable.

CE700.fm Page 5 Friday, November 10, 2006 1:52 PM

- 6 -

Components

The Local Unit (CE-700L)

Front View:

#Description Function

1 Operating Mode

Selection Switch Pressing this button toggles between the operating

mode choices:

Local: only the local console can control the

system(s)

Auto: both consoles can control the system(s).

2 LEDs The Local Unit has two LEDs to indicate the operating

status of the Local and Remote units (see CE-700L

(Local Unit), p. 11).

3 USB Keyboard

and Mouse Ports The local USB keyboard and mouse plug into these

connectors.

4 Monitor Port The local monitor plugs into this connector.

5 Remote I/O The Cat 5 twisted pair cable that connects to the

Remote Unit plugs into this connector.

6 Power Jack The cable from the AC Power Adapter plugs into this

jack.

REMOTE I /O

AC 9V

CE700.fm Page 6 Friday, November 10, 2006 1:52 PM

- 7 -

The Local Unit (CE-700L)

Rear View:

Note: If you are combining the CE-700 with a KVM switch, the

KVM cable connects back to the respective ports on the

Console section of the switch.

#Description Function

1 USB Port The B Connector of the USB KVM Custom Cable

supplied with this package plugs in here.

2 Monitor Port The HDB-15 video connector of the USB KVM Custom

Cable supplied with this package plugs in here.

CPU

CE700.fm Page 7 Friday, November 10, 2006 1:52 PM

- 8 -

The Remote Unit (CE-700R)

Front View:

#Description Function

1 LEDs The Remote Unit has two LEDs (Power and On Line) to

indicate the operating status of the Local and Remote

units (see CE-700R (Remote Unit), p. 11).

2 USB Keyboard

and Mouse Ports The remote USB keyboard and USB mouse plug into

these connectors.

3 Monitor Port The remote monitor plugs into this connector.

4 Remote I/O The Cat 5 cable that connects back to the Local Unit

plugs into this connector.

5 Power Jack The cable from the AC Power Adapter plugs into this

jack.

REMOTE I /O

AC 9V

CE700.fm Page 8 Friday, November 10, 2006 1:52 PM

- 9 -

Installation

Setting up the CE-700 KVM Extender system is simply a matter

of plugging in the cables. Refer to the installation diagram on the

following page and do the following:

1. Make sure that all the equipment to be connected up is

powered Off.

2. Plug the cables from the local console devices (mouse,

keyboard, monitor), into their ports on the Console side of the

Local Unit (CE-700L).

3. Plug the appropriate connectors on the USB KVM cable

supplied with this unit into the CPU side of the CE-700L. Each

connector is marked with an appropriate icon to indicate

which it is.

Note: The female monitor connector is the one that plugs into

the CE-700L.

4. Plug the connectors on the other end of the cable into the

appropriate ports on the computer (or Console section of the

KVM switch - if you are using one). Each connector is marked

with an appropriate icon to indicate which it is.

5. Plug either end of the Cat 5 cable into the CE-700L's Remote

I/O port.

6. Plug one of the power adapters (supplied with this package)

into an AC source; plug the adapter's power cable into the

CE-700L's Power Jack

7. Plug the other end of the Cat 5 cable into the I/O port of the

Remote Unit (CE-700R).

8. Plug the cables from the remote console devices (mouse,

keyboard, monitor), into their ports on the Console side of the

CE-700R.

9. Plug the second power adapter (supplied with this package)

into an AC source; plug the adapter's power cable into the

CE-700R's Power Jack.

CE700.fm Page 9 Friday, November 10, 2006 1:52 PM

- 10 -

REMOTEI/O

AC 9V

CE-700L

Rear View

CE-700L

FrontView

CE-700R

CE700.fm Page 10 Friday, November 10, 2006 1:52 PM
