AT&T MicroCell Manuel utilisateur
Quick Start
AT&T MicroCell
™
Getting To Know Your Device
Package Contents
AT&T MicroCell™ | AC power adapter | Yellow Ethernet cable | Quick Start | User Guide
Ethernet
Power
Power
Ethernet
GPS
Network
Status Indicators
(Front of the Device) Device Connections
(Back of the Device)
Before You Begin
To view an activation tutorial, visit att.com/MicroCell-Help.
Serial Number (S/N)
Write down your MicroCell’s serial number; you’ll
need it for online activation and future reference.
It can be found on the bottom of the device or
on the box label.
Serial # (S/N)
• Plan your installation location – your device should be:
– Within three feet of a window to receive a GPS signal for 911 purposes.
– At least one foot from other wireless broadcasting devices to avoid possible interference.
– Where you can connect your MicroCell to your Internet equipment.
• Plan on 10-15 minutes for equipment setup and online activation. Your device will then need
up to an additional 90 minutes for final device activation, which requires no effort on your part.
• You will need your AT&T wireless phone number/user name or AT&T Access ID, as well as your
password for online activation. If you haven’t set up an AT&T online wireless account, you can
do so while activating your MicroCell online.
Connect your device to the Internet
Connect the yellow Ethernet cable from the
“Ethernet” port on your MicroCell to your router.
Quick Setup
1
Power on your device
Connect your MicroCell to a power outlet
with the AC power adapter.
The Power light on the front of the device will come on immediately. Within a few
minutes, other lights will flash as a GPS signal is located and software is updated.
2
Visit att.com/MicroCell-Activate
and follow the instructions on the screen.
You’ll need the following:
• Serial number (S/N)—it’s on the bottom of the device and the box label.
• Your AT&T wireless phone number/user name or AT&T Access ID, as well as your
password. If you haven’t set up an AT&T online wireless account, you’ll need to do so.
Activate your device online
www
3
If you completed online activation in store, proceed to Step 4. NOTE:
Hold on to this guide;
you’ll come back to
it after you activate
your device.
Take a break!
You will receive a text message and email once activation
is complete.
Visit att.com/MicroCell to learn more on how to get the
most out of your MicroCell.
Wait while your device connects
NOTE:
It can take up to 90 minutes
from step 1 to complete
activation. Your device may
update and restart during
this time.
4
90
MIN
Confirm Network Connection
Power
Solid Green
Ethernet
Solid Green
GPS
Solid Green
Network
Solid Green
NOTE: Some mobile devices may display network provider information differently.
Confirm your success
Your device is configured and working properly when:
• You receive a text message and an email confirmation.
• The Network light on your MicroCell is solid and GREEN.
• Your cell phone shows “AT&T MicroCell” or “AT&T M-Cell”instead
of “AT&T” as the network provider (as shown below).
5
AT&T AT&T MicroCell AT&T M-Cell
or
NOTE:
You may need to restart
your cell phone for
“AT&T MicroCell” or
“AT&T M-Cell” to appear.
The GPS and Network lights
will start flashing GREEN after
connecting power to your device.
A solid GREEN Network light
indicates activation is complete!
Cisco and the Cisco logo are trademarks or registered trademarks of Cisco and/or its affiliates in the U.S. and other countries. To
view a list of Ciscotrademarks, go to www.cisco.com/go/trademarks. Third-party trademarks mentioned are the property of their
respective owners. The use of the word partner does not imply a partnership relationship between Cisco and any other company.
© 2013 AT&T Intellectual Property. All rights reserved. AT&T, the AT&T logo and all other AT&T marks contained herein are
trademarks of AT&T Intellectual Property and/or AT&T affiliated companies.
© 2013 Cisco Systems, Inc. All rights reserved.
October 2013 Part Number 4038348 Rev C
Having Trouble? Make sure:
1. You have waited at least 90 minutes for activation to complete.
2. You have activated your MicroCell online and received the Online Activation
Complete email.
3. Your MicroCell GPS indicator light is solid and not flashing.
4. Your Internet connection and home network are up and running and connected.
NOTE: If you still have trouble, try restarting your device by unplugging the power adapter,
waiting 10 seconds, then plugging the adapter back in.
Need More Help?
Refer to the Troubleshooting section in the User Guide,
visit att.com/MicroCell-Help,or call AT&T Support at 1-800-331-0500.
