Quick start guide

(Canada version)

ML17929

Two-line corded telephone

with caller ID/call waiting

Installation preparation

You must install the power

adapter before using the

telephone.

If you subscribe to high speed Internet service (DSL - digital subscriber line)

through your telephone line, you must install a DSL filter between each

telephone line cord and telephone wall jack (pages 3 and 4). The filter

prevents noise and caller ID problems caused by DSL interference. Please

contact your DSL service provider for more information about DSL filters.

Your product may be shipped with a protective sticker covering the telephone

base display - remove it before use.

For customer service or product information, visit our website at

www.telephones.att.com or call 1 (866) 288-4268.

Avoid placing the telephone base too close to:

Communication devices such as television sets, VCRs, or cordless telephones.

Excessive heat sources.

Noise sources such as a window with traffic outside, motors, microwave

ovens, refrigerators, or fluorescent lighting.

Excessive dust sources such as a workshop or garage.

Excessive moisture.

Extremely low temperature.

Mechanical vibration or shock such as on top of a washing machine or

work bench.

•

See pages 3-4 for easy

instructions.

Telephone installation

Telephone base installation

Install the mounting bracket for tabletop use.

Option 1: To install your telephone in a low tabletop position, insert the

fixed tabs of the mounting bracket into the slots labeled a. Press the

flexible tabs into the slots labeled buntil they click into place.

9V AC POWER

Option 1: Low tabletop position

Option 2: To install your telephone in a high tabletop position, insert the

fixed tabs of the mounting bracket into the slots labeled b. Press the

flexible tabs into the slots labeled auntil they click into place.

Option 2: High tabletop position

Mounting bracket

This quick start guide provides basic instructions. For additional installation

options and complete instructions that enable you to use all features of this

telephone, refer to your AT&T ML17929 Two-line corded telephone with

caller ID/call waiting user’s manual.

9V AC POWER

Telephone installation

Connect the telephone line cord(s) and the power cord to the telephone base.

If you subscribe to high speed Internet service (DSL - digital subscriber line)

through your telephone line, you must install a DSL filter between each

telephone line cord and telephone wall jack. The filter prevents noise and

caller ID problems caused by DSL interference. Please contact your DSL service

provider for more information about DSL filters.

Option 1: If you have a two-line wall jack, install your telephone base as

shown below.

Plug the other end of the

coiled handset cord into the

jack at the left side of the

telephone base.

Plug the small end

of the power adapter

into the power jack

on the back of the

telephone base.

Plug one end of the

black telephone line

cord (4-conductor)

into the jack labeled

LINE 1/L1+L2 on

the back of the

telephone base.

Plug the other end of the black

telephone line cord (4-conductor)

into the wall jack.

Plug the large

end of the power

adapter into an

electrical outlet

not controlled by

a wall switch.

If you have DSL high

speed Internet service, a

DSL filter (not included)

is required. The DSL filter

must be plugged into the

telephone wall jack.

NOTES:

Use only the power adapter supplied with this product. To order a replacement power

adapter, visit our website at www.telephones.att.com,or call

1 (866) 288-4268.

The power adapter is intended to be correctly oriented in a vertical or floor mount position.

The prongs are not designed to hold the plug in place if it is plugged into a ceiling,

under-the-table or cabinet outlet.

•

L1+L2

One end of

the coiled

telephone

line cord has

already been

plugged into

the handset.

Make sure it

is plugged in

firmly.

Telephone installation

Option 2: If you have two one-line wall jacks, install your telephone base as

shown below.

Plug one end of the

clear telephone line

cord (2-conductor)

into the jack labeled

LINE 1/L1+L2 on

the back of the

telephone base.

Plug the other end of

the clear telephone line

cord (2-conductor) into

the wall jack.

Plug one end of the

black telephone line

cord (4-conductor)

into the jack labeled

LINE 2 on the back of

the telephone base.

Plug the other end of

the black telephone

line cord (4-conductor)

into the wall jack.

NOTES:

Use only the power adapter supplied with this product. To order a replacement power

adapter, visit our website at www.telephones.att.com,or call

1 (866) 288-4268.

The power adapter is intended to be correctly oriented in a vertical or floor mount position.

The prongs are not designed to hold the plug in place if it is plugged into a ceiling,

under-the-table or cabinet outlet.

•

9V AC POWER

Plug the large

end of the power

adapter into an

electrical outlet

not controlled by

a wall switch.

If you have DSL high

speed Internet service, a

DSL filter (not included)

is required. The DSL filter

must be plugged into the

telephone wall jack.

Plug the small

end of the power

adapter into the

power jack on

the back of the

telephone base.

L1 L2

Plug the other end

of the coiled handset

cord into the jack at

the left side of the

telephone base.

One end of the coiled

telephone line cord

has already been

plugged into the

handset. Make sure it

is plugged in firmly.

Quick reference guide

CANCEL

Press to cancel an operation

and go back to the previous

menu.

Press and hold to return to

idle mode.

CID/

Press to display call history information when the

telephone is idle.

When entering numbers or names, press to move the

cursor to the left.

MENU/ENTER

Press to enter the

main menu.

While in a menu,

press to choose an

item, or save an entry

or setting.

/DIRDIR

Press to enter

the directory

when the

telephone is

idle.

When entering

numbers or

names, press to

move the cursor

to the right.

CONF

Press to initiate a

three-way conference

call.

LINE 1, LINE 2

Press to make or

answer a call on

the selected line.

HOLD

Press to place a call

on hold.

REDIAL

Press to dial the last number

dialed when the telephone is

off hook.

When the telephone is idle,

press to display the last five

numbers dialed. You can choose

to dial a displayed number.

FLASH

During a call, press to answer an

incoming call when you receive a

call waiting alert.

PAUSE

Press to insert a two-second dialing pause in

a number stored in the speed dial memory

or directory.

REMOVE

Press to delete the displayed

directory, or call history entry.

While entering numbers or names,

press to backspace and erase a digit

or character.

While in a menu,

press to scroll up

or down.

Quick reference guide

VOL-

While the telephone is not in

use, press to decrease the ringer

volume for both lines.

During a call, press to decrease

the listening volume.

When a line is ringing, press to

decrease the ringer volume of that

line temporarily.

HEADSET

Press to activate the headset

when a corded headset is

connected.

SPEAKER

Press to turn the

base speakerphone

on or off.

LOWER

Press to enter the lower

locations of the speed dial

keys.

MUTE

During a call, press to mute the

microphone.

VOL+

When the telephone is idle, press

to increase the ringer volume for

both lines.

During a call, press to increase the

listening volume.

When a line is ringing, press to

increase the ringer volume of that

line temporarily.

Speed dial keys

Press to dial or review a stored

speed dial number when the

telephone is idle.

By default, the telephone is set to use line 1 for making calls. When you

answer a call, the telephone automatically selects the ringing line.

Making, answering or ending a call

To make a call with the speakerphone:

Press SPEAKER to use the primary line.

-OR-

To override automatic line selection, press

SPEAKER , then press LINE 1 or LINE 2.

-OR-

If you choose SPEAKERPHONE in Choose

the preferred mode (see user’s manual),

press LINE 1 or LINE 2 directly to activate

the speakerphone.

Wait for a dial tone, then dial the telephone

number. The screen displays the elapsed

time as you talk (in hours, minutes and

seconds).

Press SPEAKER to hang up.

To make a call with the handset:

Lift the handset to use the primary line.

-OR-

Lift the handset, then press LINE 1 or LINE 2 to override automatic

line selection.

Wait for a dial tone, then dial the number.

Place the handset on the telephone base to hang up.

To make a call with the corded headset:

Make sure the corded headset is connected to the telephone base.

Press HEADSET on the telephone base to use the primary line.

-OR-

Press HEADSET, then press LINE 1 or LINE 2 to override automatic

line selection.

-OR-

If you chose HEADSET in Choose the preferred mode (see user’s manual),

press LINE 1 or LINE 2 directly to activate the headset.

Wait for a dial tone, then dial the number.

Press HEADSET to hang up.

8:00 AM 1/11

8887227702

L1 0:00:08

Elapsed time

8:00 AM 1/11

8887227702

L1 0:00:08

Elapsed time

Basic operation

LINE buttons

To answer a call:

Lift the handset, or press SPEAKER or HEADSET.

-OR-

Press the LINE button of the ringing line to answer the call with the

preferred mode.

On hook dialing (predialing)

Use the dialing keys to enter a telephone number. Press REMOVE to make

corrections when entering the telephone number.

Lift the handset, or press SPEAKER or HEADSET.

-OR-

Press LINE 1 or LINE 2 to override automatic line selection and dial the

number using your preferred mode.

Clearspeak®dial-in-base speakerphone

During a call using the handset, press SPEAKER , then hang up the

handset. This allows you to use the telephone hands free and lets more

people participate in the conversation.

Switching between the handset, headset and speakerphone

To switch from the handset to speakerphone:

While on a call using the handset, press SPEAKER , then hang up the handset.

To switch from the handset to headset:

While on a call using the handset, press HEADSET (make sure a headset is

firmly plugged in), then hang up the handset.then hang up the handset.

To switch from the speakerphone to handset:

While on a call using the speakerphone, lift the handset.

To switch from the speakerphone to headset:

While on a call using the speakerphone, press HEADSET (make sure a

headset is firmly plugged in).

To switch from the headset to speakerphone:

While on a call using the headset, press SPEAKER .

To switch from the headset to handset:

While on a call using the headset, lift the handset.

•

Basic operation

Clearspeak®is a registered trademark of Advanced American Telephones.

AT&T and the AT&T logo are trademarks of AT&T Intellectual Property licensed to

Advanced American Telephones, San Antonio, TX 78219.

Printed in China. Issue 2 AT&T 01/12.

www.telephones.att.com

Clearspeak®is a registered trademark of Advanced American Telephones.

Autres manuels pour ML17929

Table des matières

Autres manuels AT&T Téléphone

AT&T

AT&T Legend Setup For Merlin Mail Manuel utilisateur

AT&T

AT&T 1545 Manuel utilisateur

AT&T

AT&T TL88102 Mode d’emploi

AT&T

AT&T TL92151 Manuel utilisateur

AT&T

AT&T Merlin Manuel utilisateur

AT&T

AT&T 983 Manuel utilisateur

AT&T

AT&T Partner MLS 34D Manuel utilisateur

AT&T

AT&T Trimline 260 Manuel utilisateur

AT&T

AT&T CL81211 Manuel utilisateur

AT&T

AT&T MERLIN LEGEND Release 3.1 Calling Group Manuel utilisateur

AT&T

AT&T 984 Manuel utilisateur

AT&T

AT&T Four-Line Intercom Speakerphone 974 Manuel utilisateur

AT&T

AT&T SB67108 - AT&T Manuel utilisateur

AT&T

AT&T SL82118 Manuel utilisateur

AT&T

AT&T CRL32302 Manuel utilisateur

AT&T

AT&T 7401 Plus Manuel utilisateur

AT&T

AT&T CL83101 Manuel utilisateur

AT&T

AT&T E5865 Manuel utilisateur

AT&T

AT&T 636CA Instructions de montage

AT&T

AT&T CL4940 Manuel utilisateur

AT&T

AT&T CL4940 Manuel utilisateur

AT&T

AT&T CL2909 Manuel utilisateur

AT&T

AT&T 17939 Manuel utilisateur

AT&T

AT&T 4939 - AT&T - Corded Digital Answering... Manuel utilisateur

Manuels Téléphone populaires d'autres marques

GE 2-9480 Manuel utilisateur

Geemarc

Geemarc PHOTOPHONE 155 Manuel utilisateur

D-Link

D-Link DWR-720/PW Manuel utilisateur

Interquartz

Interquartz Gemini IQ333 Manuel utilisateur

SSS Siedle

SSS Siedle HT 840-0 Manuel utilisateur

Motorola

Motorola TITANIUM Manuel utilisateur

Panasonic

Panasonic ICX Manuel utilisateur

LG H870DS Manuel utilisateur

Samsung

Samsung GT-I9500 Manuel utilisateur

Selta

Selta zenyth 600 Manuel utilisateur

Doro

Doro AFTI 20 Manuel utilisateur

UNIQCELL

UNIQCELL A1 Manuel utilisateur

Panasonic

Panasonic KX Series Manuel utilisateur

Jabra

Jabra SP5050 - Bluetooth hands-free Speakerphone Manuel utilisateur

BT Decor 425 Manuel utilisateur

NEC

NEC SV8500 Manuel utilisateur

Teledex

Teledex PEARL Manuel utilisateur

Ericsson

Ericsson Dialog 3213 Manuel utilisateur
