Quick start guide

CL4939

Big button big display

telephone/answering

system with caller ID/

call waiting

Introduction

This quick start guide provides you basic installation and use instructions. A

limited set of features are described in abbreviated form.

Table of contents

Telephone installation ......................................................................................................................1

Quick reference guide ......................................................................................................................3

Set date and time ...............................................................................................................................5

Line power mode (no AC power)................................................................................................6

Making and answering a call

........................................................................................................6

Answering system...............................................................................................................................8

If you subscribe to high-speed Internet service (DSL - digital subscriber

line) through your telephone line, you must install a DSL filter between the

telephone line cord and the telephone wall jack. The filter prevents noise and

caller ID problems caused by DSL interference. Please contact your DSL service

provider for more information about DSL filters.

Follow the steps below to install the telephone:

Telephone installation

Plug one end of the coiled handset cord into the handset jack on the left

side of the telephone base. Plug the other end into the handset and hang up.

Plug one end of the telephone line cord into the TEL LINE jack on the back

of the telephone base. Plug the other end of the telephone line cord into a

telephone wall jack.

Plug the small end of the power adapter into the POWER jack on the back

of the telephone base. Plug the large end into a standard electrical outlet

not controlled by a wall switch.

Handset

Coiled handset cord

Telephone line

cord

DSL filter (not included) is

required if you have DSL

high-speed Internet service.

Telephone wall jackElectrical outlet

not controlled by

a wall switch

NOTES:

Use only the power adapter provided with this product. To obtain a

replacement, visit our website at www.telephones.att.com or call

1 (800) 222-3111. In Canada, dial 1 (866) 288-4268.

The power adapter is intended to be correctly oriented in a vertical or floor

mount position. The prongs are not designed to hold the plug in place if it

is plugged into a ceiling, under-the-table or cabinet outlet.

You can use this telephone without the power adapter installed. In this

case, you can only make or answer calls with the handset, or adjust the

ringer volume or handset listening volume. For optimal performance, power

your telephone with the supplied power adapter.

•

Telephone installation

Lift the handset or press SPEAKER to check for a dial tone.

Rotate the top of the display up or down to adjust the angle of the screen

for maximum visibility.

Quick reference guide

REMOVE

While reviewing the call

history entries,

press and hold to clear

the call history.

While reviewing an

entry stored in the

directory or call history,

press to delete.

While entering names

(or numbers), press to

backspace and erase a

character (or digit).

DISPLAY DIAL

Press to dial the

number currently

displayed.

MEM

Press to access the

speed dial memory.

FLASH

During a call, press to

answer an incoming call

if you subscribe to call

waiting service provided

by your telephone

service provider.

Press to cancel an

operation and return to

idle mode.

CID/

Press to display the call

history.

While using the menu,

press to scroll through

the settings.

While reviewing the

directory or call history,

press to scroll down.

DIR/

Press to enter the

directory.

While using the menu,

press to scroll through

the settings.

While reviewing the

directory or call history,

press to scroll up.

SELECT

While using the menu,

press to save the

setting and move to the

next menu option.

While reviewing the call

history, press repeatedly

to show different dialing

formats.

REDIAL/PAUSE

While using the handset

or speakerphone, press

to dial the last number

dialed.

While editing numbers

in the speed dial

memory or directory,

press to copy the last

number dialed.

While entering numbers,

press to insert a four-

second dialing pause.

Quick reference guide

Press to enter the

menu.

While reviewing the call

history, press to store

the displayed name and

number in the directory.

MUTE

During a call, press

to mute the handset

or speakerphone

microphone. Press

again to resume your

conversation.

AUDIO ASSIST™

Some voices will sound

louder and clearer

if you press AUDIO

ASSIST while you are

on a call using the

handset.

RINGER VOL switch

Slide to adjust the

ringer volume.

VOL switch

Slide to adjust the

listening volume on the

handset.

VOL switch

Slide to adjust the

listening volume on the

speakerphone.

While playing

messages, slide to

adjust the playback

volume.

SPEAKER

Press to turn on the

base speakerphone.

Press again to end the

call.

Audio assistTM is a trademark of Advanced American Telephones.

REPEAT/MEMO

While the telephone

is playing the day

and time the current

message was received,

press to go back to the

previous message.

After the telephone

plays the day and time

the current message

was received, press

to repeat the current

message.

When the telephone is

idle, press to record a

memo.

ANS ON/OFF

Press to turn the

answering system on

or off.

DELETE

Press to delete the

message currently

playing.

Press twice to delete all

old messages when the

telephone is not in use.

SKIP/ANNC

Press to skip to the

next message.

Press to record or

review the outgoing

announcement.

PLAY/STOP

Press to start or stop

message playback.

Press to stop recording.

Set date and time

Follow the steps below to set the date and time.

Press MENU repeatedly until the screen shows SET TIME/DATE.

Press SELECT to show MM/DD/YYYY.

Use the dial pad keys (0through 9) to set the blinking digits. To enter a

number that is less than 10, you must enter a zero (0) before the number.

Use DIR/ or CID/ to move to the next or previous digit.

Press SELECT. The screen shows hh:mm AM/PM.

Use the dial pad keys (0through 9) to set the blinking digits. To enter a

number that is less than 10, you must enter a zero (0) before the number.

For example: To enter two o’clock, you must enter 02. To enter the month

of March, you must enter 03.

Press DIR/ to select A(for AM) or CID/ to select P(for PM).

Press SELECT or MENU to save the new setting and move to the next

option.

NOTES:

If the date and time are not set and the telephone is powered up, SET CLOCK

flashes on the screen.

The month, date and time will be set automatically by incoming caller

ID information only if you subscribe to caller ID service provided by your

telephone service provider (see About caller ID on page 34 of the user’s

manual).

Setting the date and time in this menu also sets the time for the answering

system. Before playing each message, the answering system announces the

day and time the message was received (see Information about messages

on page 46 of the user’s manual). Before using the answering system, use this

menu to set the year so that the system can determine the correct day of the

week. If you do not subscribe to caller ID service provided by your telephone

service provider, you also have to set the day and time, so that messages are

dated correctly.

•

Line power mode (no AC power)

This telephone provides minimal functionality during a power failure. When AC

power is not available, the screen is blank and many telephone features do

not function. Only touch-tone dialing and volume adjustment (ringer volume

and handset volume) are supported. The telephone uses power from the

telephone line to enable you to make and answer calls using only the handset

and dial pad keys.

To make a call during a power failure

Lift the handset and wait for the dial tone. The screen shows NO AC

POWER.

Slowly dial a telephone number using the dial pad keys. Wait to hear each

key tone and make sure the digit appears on the screen before pressing

the next dial pad key.

NOTE: If the telephone is not powered by the supplied power adapter,

there is a delay when dialing digits.

To answer a call during a power failure

Lift the handset.

NOTE: The screen does not show incoming caller ID information during a

power failure.

To adjust the handset volume during a power failure

Use the VOL switch on the right side of the telephone base to adjust the

listening volume from the handset.

To adjust the ringer volume during a power failure

Adjust the RINGER VOL switch on the right side of the telephone base to set

the ringer volume to off, low, middle or high.

•

Using handset

To make a call:

Lift the handset, wait for the dial tone, and then dial a number.

To answer a call:

Lift the handset.

To end a call while using the handset:

Place the handset in the telephone base.

Using speakerphone

To make a call:

Press SPEAKER then dial a number.

To answer a call:

Press SPEAKER.

To end a call while using the speakerphone:

Press SPEAKER.

On hook dialing (predialing)

Use the dial pad keys to enter a telephone number.

Press REDIAL/PAUSE to insert a four-second

dialing pause.

Press REMOVE to make corrections.

Press FLASH to return to idle mode.

Lift the handset to call.

-OR-

Press DISPLAY DIAL or SPEAKER to call using the speakerphone.

Switching between handset and speakerphone

To switch from handset to speakerphone during a call:

Press SPEAKER then place the handset in the telephone base.

To switch from speakerphone to handset during a call:

Lift the handset.

•

Making and answering a call

12:00AM11-20 15

8887227702_

Answering system

Turn the answering system on or off

Press ANS ON/OFF repeatedly to turn the

answering system on or off. When the answering

system is on, it announces, “Answering machine is on.“

The ANS ON/OFF light is on. When the answering

system is off, it announces, “Answering machine is

off.“ The ANS ON/OFF light is off.

Record your outgoing announcement

The outgoing announcement is the message callers hear

when calls are answered by the answering system.

If the answering system is on, the telephone

automatically answers calls with “Hello, please leave a

message after the tone.“ You can use this announcement,

or replace it with a recording of your own.

Use the following steps to record an outgoing

announcement with a recording of your own.

Press SKIP/ANNC. The screen shows RECORD

and the message window displays A.

Press SELECT. The screen shows USE STOP TO

END with a long beep.

Speak towards the microphone (MIC) on the

telephone and maintain a distance of about nine

inches. You can record an announcement of up

to two minutes. Announcements shorter than one

second are not recorded.

Press PLAY/STOP to end the recording. The

recorded announcement automatically plays back

and the message window displays AP. Then the

telephone returns to idle mode with a beep.

•

12:00AM11-20 A

USE STOP TO END

12:00AM11-20

USE STOP TO END

12:00AM11-20 A

RECORD

Autres manuels pour CL4939

Table des matières

Autres manuels AT&T Téléphone

AT&T

AT&T CN5345 Manuel utilisateur

AT&T

AT&T E2555 Manuel utilisateur

AT&T

AT&T 636CA Instructions de montage

AT&T

AT&T TL96273 Manuel utilisateur

AT&T

AT&T MERLIN LEGEND Release 3.1 Calling Group Manuel utilisateur

AT&T

AT&T E2520 Manuel utilisateur

AT&T

AT&T ML17928 Manuel utilisateur

AT&T

AT&T Synapse SB67020 Manuel utilisateur

AT&T

AT&T 993 Manuel utilisateur

AT&T

AT&T SynJ SB67118 Manuel utilisateur

AT&T

AT&T 874 Manuel utilisateur

AT&T

AT&T SPIRIT 1224 Controller Manuel utilisateur

AT&T

AT&T CL83215 Manuel utilisateur

AT&T

AT&T 500E Manuel utilisateur

AT&T

AT&T CL82115 Manuel utilisateur

AT&T

AT&T Voice Terminal 6434 Manuel utilisateur

AT&T

AT&T SB67108 - AT&T Manuel utilisateur

AT&T

AT&T CL80119 Manuel utilisateur

AT&T

AT&T CL82115 Manuel utilisateur

AT&T

AT&T SynJ SB67158 Manuel utilisateur

AT&T

AT&T CL83203 Manuel utilisateur

AT&T

AT&T CL84100 Manuel utilisateur

AT&T

AT&T Trimline TR1909B Manuel utilisateur

AT&T

AT&T 1187 Manuel utilisateur

Manuels Téléphone populaires d'autres marques

GE 2-9480 Manuel utilisateur

Geemarc

Geemarc PHOTOPHONE 155 Manuel utilisateur

D-Link

D-Link DWR-720/PW Manuel utilisateur

Interquartz

Interquartz Gemini IQ333 Manuel utilisateur

SSS Siedle

SSS Siedle HT 840-0 Manuel utilisateur

Motorola

Motorola TITANIUM Manuel utilisateur

Panasonic

Panasonic ICX Manuel utilisateur

LG H870DS Manuel utilisateur

Samsung

Samsung GT-I9500 Manuel utilisateur

Selta

Selta zenyth 600 Manuel utilisateur

Doro

Doro AFTI 20 Manuel utilisateur

UNIQCELL

UNIQCELL A1 Manuel utilisateur

Panasonic

Panasonic KX Series Manuel utilisateur

Jabra

Jabra SP5050 - Bluetooth hands-free Speakerphone Manuel utilisateur

BT Decor 425 Manuel utilisateur

NEC

NEC SV8500 Manuel utilisateur

Teledex

Teledex PEARL Manuel utilisateur

Ericsson

Ericsson Dialog 3213 Manuel utilisateur
