Quick start guide

5.8 GHz Cordless

Telephone/Answering

System E5945B

with Caller ID & CallWaiting

Installation & setup

Place handset in

charger for at least

16 hours before

first use.

Plug power adapter

into jack on under-

side of charger as

shown, then plug

into an electrical

outlet not controlled

by a wall switch.

Plug the larger

power adapter

into an

electrical outlet

not controlled

by a wall switch,

and plug the

other end into the

bottom of the tel-

ephone base.

Plug one end of

the telephone line

cord into a modu-

lar telephone jack,

and the other end

into the telephone

jack at the bottom

of the telephone

base.

Place the battery and

wires neatly inside

the compartment.

Press in and downward

on the tab to open the

battery compartment

cover.

Slide battery

compartment cover

towards the center

until it clicks closed.

Plug the battery connec-

tor into handset battery

compartment, matching the

color coded label.

NOTES:

1. Use only the power cord supplied with this product. If you need a replacement, call 1 (800) 222-3111.

In Canada, call 1 (866) 288-4268.

2. Be sure to use an electrical outlet not controlled by a wall switch.

Caution: Use only the

supplied rechargeable

battery pack or AT&T

replacement battery

model 3301 (SKU

91076. Part number 80-

5071-00-00).

After battery installation, place the cordless handset in the telephone base or charger and

allow to charge for at least 16 hours before use. Keep the battery charged by returning

the cordless handset to the telephone base or charger after each use. When the battery

is fully depleted, a recharge takes about 16 hours. The talk time on a fully charged battery is

about five hours depending on environmental conditions, and the standby time is approxi-

mately five days. Actual battery life depends on usage conditions, and age of battery.

Quick reference guide

Cordless handset

CHAN

When the telephone is off the hook, for

example, when on a call, pressing the

CHAN or DELETE button causes

the telephone to scan for a clearer chan-

nel when there is static or interference

on the line.

PHONE/FLASH

Press to make or answer a call.

During a call, press to receive an incoming

call if call waiting is activated.

SELECT/TRANSFER

Press to store a programming option.

During a call, press to transfer a call

between cordless handsets.

OFF/CLEAR

During a call, press to hang up.

While using menus, press to cancel an

operation, back up to the previous

menu, or exit the menu display.

DELETE

When the telpehone is in CID mode, press

either the CHAN or DELETE button to

delete the displayed caller ID entry, or press

and hold the CHAN or DELETE button to

delete all caller ID entries.

REDIAL/PAUSE

While the telephone is idle, press to

display the last number called.

While dialing or entering numbers into

the directory, press to insert a four- sec-

ond dialing pause.

CID

While in menus, press to scroll down.

When the telephone is not in use, press to

display call log entries.

While entering names or numbers, press to

delete last character entered.

During a call, press CIDVto lower

listening volume.

^ DIR

While in menus, press to scroll up.

When the telephone is not in use, press to

display directory entries.

While entering names, press to advance the

cursor to the next space.

During a call, press ^DIR to increase

listening volume.

Press to display menu.

NOTE: For more information, please refer to the user’s manual.

Quick reference guide

Telephone base

HANDSET LOCATOR

Press to page the cordless handsets, if none of the

handsets is in the telephone base. Press again to cancel

the page. Press OFF/CLEAR on cordless handset, or

place cordless handset in the telephone base or charger to

cancel the page on that handset only; all other handsets

are still being paged.

CHARGE/IN USE

Flashes when one of the cordless handsets is in use.

On steady when the cordless handset is properly

positioned to be charged in the telephone base.

Flashes when there is an incoming call.

Answering system controls

ANSWER ON ....Press to turn answering system on or off.

CLOCK ..............Press to review or set the answering system clock.

SETUP................Press repeatedly to listen to the setup options.

ANNC ................Press to review or record announcement. Press again to quit.

RECORD ...........Press to record a memo, or after pressing ANNC to record an

outgoing announcement.

DELETE..............Press to delete a message during playback. Press and hold to

delete all old messages when idle.

REPEAT..............Press to repeat message. Press twice to play previous message.

SKIP ...................Press to skip message.

Press to play or stop playing messages.

AT&T and the Globe Design are trademarks of AT&T Corp.,

licensed to Advanced American Telephones. Issue 2 AT&T 07/06

96-006143-020-000
