Quick Start Guide

2.4 GHz Cordless

Telephone/Answering

System E2728B/E1128B

with Caller ID & Call Waiting

Plug the large power

adapter into an electrical

outlet not controlled by a

wall switch.

Plug the telephone

line cord into tele-

phone jack.

Place handset in base or

charger to charge for at least

16 hours before first use.

Installation and setup

After battery installation, place the cordless handset in the base or charger and allow

to charge for at least 16 hours before use. You can keep the battery charged by return-

ing the cordless handset to the base or charger after each use. When the battery is fully

depleted, a recharge takes about 16 hours. The talk time on a fully charged battery is about

four hours depending on environmental conditions, and the standby time is approximately

five days. Actual battery life will depend on usage conditions, and age of battery.

Plug the battery pack

connector securely

into the plug inside

the cordless handset

battery compartment,

matching the color-

coded label. Then

place battery pack

into compartment.

Low battery indicator.

Return cordless handset to

base or charger to recharge

when this symbol flashes.

(When in use the cordless

handset will beep when battery

is low).

Caution: Use only the supplied

rechargeable battery or AT&T replace-

ment battery model 3301 (SKU 91076,

Part Number 80-5071-00-00).

Press down on tab to

open the battery door.

Slide the battery door up

to close.

BATTERY LOW

--1--

0 8/12 10:06 AM

CHAN

MUTE

REDIAL

TRANSFER

MENU /SEL

MUTE

During a call, press to mute microphone.

PHONE/FLASH

Press to make or answer a call.

During a call, press to receive an incoming

call if Call Waiting is activated.

MENU/SEL/TRANSFER

Press to display menu, or to store a

programming option.

During a call, press to transfer a call.

Quick reference guide

OFF

During a call, press to hang up.

During programming, press to exit

without making changes.

SPEAKER

Press to activate cordless

handset speakerphone.

Press again to resume

normal cordless handset use.

CHAN/DEL

During a call, press to switch to another

channel if the call is noisy or unclear.

Press to delete displayed Caller ID entry.

While phone is not in use, press and hold to

delete all Caller ID entries.

REDIAL/PAUSE

Press to display last number called.

While dialing or entering numbers into

your directory, press to insert a 4-second

dialing pause.

Time

02 MISSED CALLS

--1--

8/12 10:06 AM

Cordless Handset

CID V

While in menus, press to scoll down.

When phone is not in use, press to display

call log entries.

While entering names or numbers, press to

delete last character entered.

^DIR

While in menus, press to scoll up.

When phone is not in use, press to display

directory entries.

While entering names, press to advance the

cursor to the next space.

Date Handset number

NOTE: For more information, please refer to the user’s manual.

Quick start guide

Telephone Base

Answering System Controls

ANSWER ON/OFF......Press to turn answering system on or off.

DELETE......................Press to delete a message during playback. Press

and hold to delete all old messages when idle.

TIME/SET...................Press to review or set the answering system clock.

SETUP........................Press to review or change an outgoing announcement.

Press again to review or change answering system options.

CHANGE ....................Press to change a setup option.

REC/MEMO................Press to record a memo.

Press to play or stop playing messages.

HANDSET LOCATOR

Press to page the cordless handsets. Press again,

press OFF on cordless handset, or place cordless

handset in the base or charger to cancel the page

(see the user’s manual page 13 for details).

CHARGE/IN USE

Flashes when one of the cordless handsets is in use.

On steady when the cordless handset is properly positioned to

charge in the base.

Flashes during an incoming call’s ringing.

NOTE: For more information, please refer to the user’s manual.

Choose a locaton for your telephone

Choose a central location close to a telephone jack and a power outlet not connected

to a wall switch. The telephone base can be placed on a ﬂat surface or mounted on a

standard wall plate. For optimum range and better reception, place the telephone base

in a high and open location.

Avoid heat sources, such

as radiators, air ducts, and

sunlight

Avoid placing the telephone base too close to:

• Communication devices such as: personal computers, computer routers, television

sets,VCRs, wireless routers (wireless broadband, wi-fi, or 802.11), other cordless

telephones, etc.

• Excessive heat sources such as radiators, ventilation ducts, and direct sunlight.

• Noise sources such as a window with traffic outside, motors, microwave ovens,

refrigerators, and fluorescent lighting.

• Excessive dust sources such as: a workshop, garage, etc.

• Excessive moisture such as the bathroom, kitchen, sauna, or greenhouse.

• Extremely low temperatures such as the garage.

• Mechanical vibration or shock such as on top of the washing machine or on a work

bench.

Avoid television sets and

other electronic equipment

Avoid noise source such as

a window with heavy

traffic outside

Avoid microwave ovens

Avoid other cordless

telephones

Avoid personal computers

Avoid excessive moisture,

extremely low temperatures,

dust, mechanical vibration,

or shock

Choose a central location

AT&T and the Globe Design are trademarks of AT&T Corp.,

licensed to Advanced American Telephones. Printed in China. Issue 3 AT&T 05/06.

96-006096-030-000.
