AT&T PagePac Plus AmpliCenter Guide de démarrage rapide
463-248-202
Issue 1
3/16/93
PagePacPlus AmpliCenter
Installation and Use
Copyright 1993 Harris Dracon
All Rights Reserved
Written/Printed in U.S.A.
AT&T 463-248-202
0II722051-300
Issue 1, March 1993
Notice
Every effort was made to ensure that the information in this guide was complete and accurate at the time of printing.
However, information is subject to change.
Federal Communications Commission (FCC) Interference Notice and Canadian Dept. of Communications
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15
of the FCC rules and D.O.C. regulations. These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the instruction guide, may cause
harmful interference to radio communications. Operation of this equipment in a residential area is likely to clause
harmful interference, in which case the user will have to correct the interference at his or her own expense. For
repair information, see section 4, Maintenance and Customer Support, and for additional FCC interference and
registration information, see appendix A, FCC Statement and Warranty Information, in this manual.
Trademarks
PAGEPAC, PAGEPAC PLUS and AMPLICENTER are trademarks of Harris Corporation. Centrex is a registered
trademark of AT&T.
Warranty
AT&T provides a limited warranty for this product. Refer to ''AT&T Limited Warranty and Limitation of
Liability" in appendix A.
Ordering Information
The order number for this book is 463-248-202. To order copies of this book, call 1-800-432-6600 in the U.S. and
1-800 255-1242 in Canada. For more information on how to order this and other system reference materials, see
"Reference Materials," in "About This Guide." For information on ordering replacement parts, accessories, and
other compatible equipment refer to "Ordering Information," in section 1.
Support Telephone Numbers
AT&T provides a toll-free customer Helpline 24 hours a day,
In the U.S., call the AT&T Helpline at 1-800-628-2888 if you need assistance when installing, programming, or
using your system. For service or technical assistance in Canada call one of the following Technical Assistance
Centers:
Eastern Canada and Ottawa: 1-800-363-1882
Ontario:
1-800-387-4268
Central and Western Canada 1-800-663-9817
VG—3193-2.2M
Contents
1.
Overview
1-1
■
■
■
■
■
■
■
■
■
■
■
■
■
About This Guide
How to Use This Guide
Before You Start
Installation Steps
Connectivity Chart
Product Safety Labels
Terminology
Reference Materials
How to Comment on This Guide
Shipping Container Contents
Ordering Information
Features and Capabilities
Specifications
1-2
1-2
1-2
1-3
1-4
1-6
1-6
1-6
1-6
1-7
1-8
1-9
1-10
2. Hardware Configuration 2-1
■
■
■
■
■
■
Power
2-2
Circuit Protection
2-2
Mounting
2-2
Universal Approvals
2-3
Controls and Indicators, Terminals and Connectors 2-3
Auxiliary Equipment
2-5
iii
3. Installing the Hardware 3-1
■
■
■
■
■
■
■
Important Safety Information
Example System Setup
Mounting PagePac Plus AmpliCenter
Connecting Speakers
Telephone System Interface
Music Source Interface
System Testing
3-2
3-3
3-6
3-8
3-9
3-11
3-13
4. Maintenance and Customer Support 4-1
■
■
■
■
■
In Case of Difficulty
4-2
Power Failure Operation 4-3
Common Problems
4-3
Troubleshooting
4-3
Electrical Block Diagram
4-5
A. FCC Statement and Warranty Information A-1
B. Feedback Form B-1
IN. Index IN-1
iv
Tables
1.
Overview
1-1
1-1. PagePac Plus Connectivity Chart
1-4
1-2. AmpliCenter Specifications
1-10
2. Hardware Configuration
2-1. Controls and Indicators, Terminals and Connectors
2-1
2-4
v
Figures
1.
Overview
1-1
1-1. Installation Steps
1-3
1-2. AmpliCenter Components
1-7
1-3. PagePac Plus AmpliCenter
1-9
2. Hardware Configuration 2-1
2-1. AmpliCenter Controls and Indicators,
Terminals and Connectors
2-3
3.
Installing the Hardware 3-1
3-1.
3-2.
3-3.
3-4.
3-5.
3-6.
3-7.
AmpliCenter Interface with PagePac Plus Controller
3-4
Series AmpliCenters, without Controller
3-5
Wall Mounted Hardware 3-6
Rack Mounted Hardware
3-7
Speaker Run Method
3-8
AmpliCenter Interconnection to Telephone System
or to Controller 3-10
Music Input Connections
3-12
4. Maintenance and Customer Support
4-1
4-1. AmpliCenter Electrical Block Diagram
4-5
vi
Overview
Contents
About This Guide
How to Use This Guide
Before You Start
Installation Steps
Connectivity Chart
Product Safety Labels
Terminology
Reference Materials
How to Comment on this Guide
Shipping Container Contents
Ordering Information
Features and Capabilities
Specifications
1-2
1-2
1-2
1-3
1-4
1-6
1-6
1-6
1-6
1-7
1-8
1-9
1-10
Overview 1-1
About This Guide
The PagePac Plus AmpliCenter Installation and Use Manual explains the
features of the AmpliCenter, how to install and configure the AmpliCenter,
and interface to a communication system and other auxiliary equipment.
It is intended that PagePac Plus be installed by a trained telephone, audio,
or electrical installer with basic electronic knowledge. PagePac Plus
conforms to common installation practices and preferences found within
the Telcom Electrical and Commercial Sound installers manual.
How to Use This Guide
■
■
■
■
Overview.
This section provides an overview of AmpliCenter features
and capabilities, specifications, and a summary of installation steps for
the experienced installer.
If you are installing the PagePac Plus AmpliCenter for the first time,
you should read this entire guide before getting started to familiarize
yourself with the features.
Hardware Configuration.
This section describes and illustrates the
AmpliCenter D20, D100, and D300 units.
Installing the Hardware.
This section provides instructions for
mounting the PagePac Plus AmpliCenter hardware on a wall or in a
standard 19" equipment rack. Complete, detailed instructions for
connection and operation with telephone systems, music source,
speakers, and any control device inputs or outputs is provided.
Maintenance and Customer Support.
This section gives some basic
troubleshooting tips if a paging zone does not operate properly after
connection to the AmpliCenter. Should a problem arise which requires
technical assistance, call AT&T technical support groups at the
numbers listed in this section.
Use the Contents and Index to locate specific items of interest.
Before You Start
Before installing your system, read and understand the safety instructions
in section 3. Be sure you have all the necessary parts— see Shipping
Container Contents, below. In addition, see Tools Required in section 3
for a few tools and test equipment that will be needed for installation.
1-2 Overview
Installation Steps
NOTE: The numbers in these
steps match the numbers in
figure 1-1.
1.
2.
3.
4.
5.
6.
7.
Mount the PagePac Plus AmpliCenter to either the wall, cabinet or a
rack.
Pull cables.
Hookup cabling to AmpliCenter and auxiliary equipment. (Refer to
Example Setups in section 3.) Use stick-on labels to identify the
AmpliCenter/zone (i.e., cafeteria - zone 1).
Set the AmpliCenter Telephone Mode Selection Switch to match the
host telephone system and make connection.
Install power cord and plug into outlet.
Test paging zone served by the AmpliCenter. (Refer to Testing the
System, in section 3.)
Adjust sound levels using AmpliCenter controls. (Refer to
Adjustments, in section 4.)
TO HOST TEL.
SYSTEM
MUSIC INPUT
Figure 1-1. Installation Steps
Overview 1-3
Connectivity Chart
The Connectivity chart gives the trunk interface requirements for the host
systems listed. This information is then used to set the telephone mode
function switch on the PagePac Plus AmpliCenter.
Table 1-1. PagePac Plus Connectivity Chart
Merlin Plus
Merlin 206/820
Merlin 1030/3070
Merlin II
Merlin Legend
Mode
C.O.
Line
Page
Port
C.O.
Line
Page
Module
C.O.
Line
Service
Module
C.O.
Line
Analog
Station
C.O.
Line
Analog
Station
Loop
Start Yes
Note 1
—
—
—
Ground
Start 3
—
—
—
—
Yes
Note 1
—
—
—
—
—
—
—
Yes
Note 1
—
—
—
—
—
—
—
Yes
Note 1
—
—
—
—
—
—
—
Yes
—
—
—
—
—
—
—
Dry
Loop
(Hi Z)
Dry
Loop
(600 Ω)
Spirit 308/616 Spirit
1224/2448
Partner Partner II
Partner Plus
Mode
C.O. Line
Page Port
C.O. Line
C.O. Line
Analog
Station
C.O. Line
Analog
StationPage
Port
Loop
Yes
—
Yes Yes
—
Yes
— —
Start
Ground
————————
Start 3
Dry
—— — ————
Loop
—
(Hi Z)
Dry
—
No
——— — —
Yes
Loop
Note 2
(600 Ω)
1-4 Overview
