Operation and Maintenance
Manual
RT60-ROW
SN 00623-Current
English
All
Language:
Geographic Region:
Serial Number Range:
This manual is complements of
TrackLoaderParts.com
The world's best source for ASV parts.
Track Loader Parts 6543 Chupp Road Atlanta, Georgia 30058 USA (800)616-8156
https://tractormanualz.com/
CONTENTS
Introduction .................................................. 2
Safety ........................................................ 5
Technical Data.............................................. 29
Machine Description / Controls..................... 35
Operation ..................................................... 45
Transportation .............................................. 55
Maintenance ................................................ 61
California Proposition 65 .............................. 83
1
Page
The operator must read and understand all the instructions
in this manual before operating the RT-60/R160T/R190T.
RT-60/R160T/R190T ROW O&M
0404-659 2016-05
https://tractormanualz.com/
1 INTRODUCTION
2
1.1 Product Identification (PIN)
The machine PIN is located on the identification plate, behind and to the left of
the operator seat.
Please state the model of the machine and PIN when making inquiries in regards
to parts, service, or warranty.
1.2 Introduction
Thank you for purchasing your RT-60/R160T/R190T Compact Track Loader.
We are confident that the machine you have chosen will provide excellent per-
formance and efficient operation.
The information contained in this manual is intended to provide the operator with
all necessary information for the proper use of the machine.
It is imperative that this manual be provided to the end user at the time of pur-
chase, prior to operation and kept with the machine at all times. If lost or dam-
aged, contact your dealer immediately to obtain a replacement prior to resuming
operation.
The operator is responsible for the safe operation of the machine.
The operator must read, understand and obey the instructions in both this
and the AEM safety manual for skid steer and compact track loaders prior
to operating or performing maintenance or service on the machine.
Should you need clarification or further explanation of the topics in this manual,
please contact your dealer immediately for assistance.
Information describing special equipment or attachments and their operation are
not included in this manual.
This manual should be stored in the black plastic manual box located inside the
cab enclosure to protect it from the elements.
1.3 Safety Alert Symbol
The safety alert symbol is used to alert you to potential personal injury
hazards. Obey all safety messages that follow this symbol to avoid
possible injury or death.
RT-60/R160T/R190T ROW O&M
0404-659 2016-05
https://tractormanualz.com/
1 INTRODUCTION
3
1.4 Intended Use
The RT-60/R160T/R190T with bucket attachment is intended to be used solely for
work consistent with its design. Such work involves loosening, collecting, trans-
porting, and distributing soil, rock, or similar materials as well as loading these
materials onto trucks, conveyors, or other methods of transport.
After installation of compatible (see section 4.10) special working attachments,
the equipment can be used for corresponding applications.
The operator must follow the operating instructions for any externally supplied
components or attachments.
Any use varying from that described here or any lack of adherence to the operat-
ing instructions, maintenance procedures, or replacement intervals described in
this manual shall be regarded as unintended or improper use. The supplier cannot
be held responsible for any damage resulting from improper use. This risk is
borne solely by the user.
1.5 Bulletin Compliance
It is very important to comply with all safety related bulletins. Bulletins are tied to
the most current owner on record. Therefore, it is important that any new owner
contact their local dealer to register the machine in their name. This will ensure
that they will be notified in the event of a safety related bulletin affecting their
machine.
1.6 Contacting the Manufacturer
If you have questions relating to ownership including, but not limited to: accident
reporting, current owner updates, product applications and safety, standards and
regulations compliance, product modifications, transfer of ownership, please
consult your local dealer as the first point of contact.
1.7 Copyright
This manual is intended for use by personnel responsible for operation, mainte-
nance, repair, and supervision activities involving the machine described within.
This manual is copyrighted. It shall not, either in whole or in part, be reproduced,
transmitted, or used for the purpose of competition without our prior written con-
sent.
RT-60/R160T/R190T ROW O&M
0404-659 2016-05
https://tractormanualz.com/
1.8 Warranty
Your RT-60/R160T/R190T is warranted under the Compact Track Loader and
Utility Vehicle Standard Limited New Product Warranty (“Warranty”). A copy of the
Warranty certificate is available from your authorized RT-60/R160T/R190T
Distributor.
4
RT-60/R160T/R190T ROW O&M
0404-659 2016-05
1 INTRODUCTION
https://tractormanualz.com/
2 SAFETY
5
2.1 Safety Alert System ................................ 7
2.2 Graphical Symbols ................................. 8
2.3 Safety Signs (ISO)................................... 12
2.4 General Notes ........................................ 14
2.5 Personal Protection Equipment............... 15
2.6 Hazard Zone........................................... 15
2.7 Operation ............................................... 16
2.8 Stability.................................................. 17
2.9 Transport of Persons............................... 17
2.10 Fire Prevention ..................................... 18
2.11 Crush / Burn Avoidance........................ 19
2.12 Placing Into Operation .......................... 20
2.13 Starting the Machine............................ 20
2.14 Jobsite Safety ...................................... 21
2.15 Parking the Machine ............................ 22
2.16 Towing / Retrieving............................... 22
2.17 Transporting ......................................... 23
2.18 Maintenance ........................................ 24
2.19 Battery ................................................. 26
2.20 Hydraulic Lines / Hoses........................ 27
Page
RT-60/R160T/R190T ROW O&M
0404-659 2016-05
https://tractormanualz.com/
6
RT-60/R160T/R190T ROW O&M
0404-659 2016-05
This Page Intentionally Left Blank
https://tractormanualz.com/
2.1 Safety Alert System
Safety Alert Symbol
This symbol means: Attention! Be alert! Your safety
is involved!
The safety alert symbol is used to alert you to potential
personal injury hazards. Obey all safety messages
that follow this symbol to avoid possible injury or
death.
This symbol is used as an attention-getting device throughout this manual as well
as on decals and labels fixed to the machinery to assist in potential hazard recog-
nition and prevention.
NOTICE indicates a property damage
message.
2 SAFETY
7RT-60/R160T/R190T ROW O&M
0404-659 2016-05
https://tractormanualz.com/
2 SAFETY
8
2.2 Graphical Symbols
Hazard Avoidance
Pictorial Pictorial Description
Hazard: Skin/Oil Injection
Avoidance:
• Relieve internal pressure before
disconnecting any line or fitting.
• Keep away from leaks or pin-
holes.
• Use cardboard to check for leaks.
Fluid injected into skin must be
surgically removed within a few
hours by a doctor familiar with this
type of injury or gangrene will
result.
Hazard: Corrosive
Avoidance: Read and understand
the operator’s manual.
Hazard: Entanglement
Avoidance: Stop machine and
remove key before servicing.
Hazard: Burn/Scald
Avoidance: Allow to cool before
opening.
RT-60/R160T/R190T ROW O&M
0404-659 2016-05
bf di ti
https://tractormanualz.com/
2 SAFETY
9
Hazard Avoidance
Pictorial Pictorial Description
Hazard: Explosion/Burn
Avoidance:
• Keep all flames/sparks away!
• No Smoking!
• Read and understand all
manuals.
Hazard: Fall
Avoidance: Use the provided
access system when entering or
exiting the machine.
Hazard: Fall
Avoidance: No Riders.
Hazard: Burn
Avoidance: Do not touch hot
surfaces.
Hazard: Crush
Avoidance: Fasten seat belt.
RT-60/R160T/R190T ROW O&M
0404-659 2016-05
https://tractormanualz.com/
