VivoTab User Manual

E7824

ASUS is devoted to creating environment-friendly products

and packaging to safeguard consumers’ health while

minimizing the impact on the environment. The reduction

of the number of the manual pages complies with the

reduction of carbon emission.

For the detailed user manual and related information, refer

to the user manual included in the VivoTab or visit the ASUS

Support Site at http://support.asus.com/.

E7824_ME400CL_User_Manual.indd 1 12/5/12 2:41:06 PM

Charging Your Batteries

Ensure to fully charge your battery pack before using your

VivoTab in battery mode for extended periods. Remember that

the power adapter charges the battery pack as long as it is

plugged into an AC power source. Be aware that it takes much

longer to charge the battery pack when the VivoTab is in use.

IMPORTANT! Do not leave the VivoTab connected to the power

supply once it is fully charged. VivoTab is not designed to be left

connected to the power supply for extended periods of time.

Airplane Precautions

Contact your airline provider to learn about related inight

services that can be used and restrictions that must be followed

when using your VivoTab in-ight.

IMPORTANT! You can send your VivoTab through x-ray

machines (used on items placed on conveyor belts), but do not

expose them from magnetic detectors and wands.

Safety Precautions

This VivoTab should only be used in enviroments with ambient

temperatures between 0°C (32°F) and 35°C (95°F).

Long time exposure to extremely high or low temperature

may quickly deplete and shorten the battery life. To ensure the

battery’s optimal performance, ensure that it is exposed within

the recommended environment temperature.

E7824_ME400CL_User_Manual.indd 2 12/5/12 2:41:06 PM

ASUS VivoTab

Package contents

NOTES:

• If any of the items is damaged or missing, contact your

retailer.

• The bundled power adapter varies with country or region.

VivoTab Power adapter

Micro USB cable Technical documentations

and warranty card

Cleaning cloth Micro SIM card tray eject pin

E7824_ME400CL_User_Manual.indd 3 12/5/12 2:41:07 PM

ASUS VivoTab

Your VivoTab

Front view

Front camera

This built-in 2-megapixel camera allows you to take

pictures or record videos using your VivoTab.

Camera indicator

The camera indicator lights up when either of the

built-in cameras is in use.

Ambient light sensor

The ambient light sensor detects the amount of

light in your environment. It allows the system to

automatically adjust the brightness of the display

depending on the ambient light condition.

E7824_ME400CL_User_Manual.indd 4 12/5/12 2:41:08 PM

ASUS VivoTab

Touch screen panel

The touch screen panel allows you to operate your

VivoTab using touch gestures or a stylus pen.

Windows® 8 touch button

Touch this button to go back to the Start screen. If you

are already in the Start screen, touch this button to go

back to the last app you opened.

E7824_ME400CL_User_Manual.indd 5 12/5/12 2:41:08 PM

ASUS VivoTab

Rear view

Headphone output/microphone input combo jack

port

This port allows you to connect the VivoTab’s audio-

out signal to amplied speakers or headphones. You

can also use this port to connect your VivoTab to an

external microphone.

IMPORTANT! For microphone input function, the

jack only supports headset microphone.

Volume button

Press this button to increase or decrease the volume.

E7824_ME400CL_User_Manual.indd 6 12/5/12 2:41:11 PM

ASUS VivoTab

Manual reset hole

If the system becomes unresponsive, insert a

straightened paper clip into the hole to force-restart

your VivoTab.

IMPORTANT! Forcing the system to restart may result

to data loss. We strongly recommend that you back

up your data regularly.

Microphone

The built-in mono microphone can be used for

video conferencing, voice narrations or simple audio

recordings.

Camera LED ash

Use the LED ash when taking pictures or recording

videos in a low-light environment.

You can set the LED ash to any of these settings:

Setting Description

AUTO The system automatically uses the LED

ash when taking pictures depeding on the

lighting condition.

ON The system uses the LED ash constantly

when taking pictures in any lighting

condition.

TORCH The system uses the LED ash as a constant

lighting xture or torch when taking photos

or recording videos.

OFF The system disables the LED ash.

E7824_ME400CL_User_Manual.indd 7 12/5/12 2:41:12 PM

ASUS VivoTab

Rear camera

This built-in 8-megapixel camera allows you to take

high-denition pictures or record high-denition

videos using your VivoTab.

Power button

Press the power button to turn your VivoTab on, put

it to sleep or hibernate and wake it up from sleep or

hibernate mode.

Press and hold the power button for about ve (5)

seconds to force shut down your VivoTab when it

becomes unresponsive.

IMPORTANT! Forcing the system to restart may result

to data loss. We strongly recommend that you back

up your data regularly.

Battery charge indicator

This two-color LED provides a visual indication of

the battery’s charge status.

Refer to the table below for details:

Color Status

White Fully charged.

Orange Charging mode.

Dim The AC adapter is not plugged to the

VivoTab.

E7824_ME400CL_User_Manual.indd 8 12/5/12 2:41:12 PM

ASUS VivoTab

Micro HDMI port

This port is for a micro HDMI (High-Denition

Multimedia Interface) connector and is HDCP

compliant for HD DVD, Blu-ray and other protected

content playback.

MicroSD card slot

The VivoTab comes with a built-in memory card

reader slot that supports microSD, microSDHC and

microSDXC card formats.

Micro SIM card slot

The VivoTab comes with a built-in micro SIM

(Subscriber Identity Module) card slot that supports

GSM, WCDMA, and LTE network bands.

NOTE: Refer to section Installing a micro SIM card

for more details.

Micro SIM card tray eject hole

Insert the bundled micro SIM card tray eject pin into

this hole to eject the micro SIM card tray.

Built-in NFC (Near Field Communication) tag

The built-in NFC tag allows you to conveniently share

contacts, pictures, business cards, and other les.

To use the NFC tag, put your VivoTab’s NFC tag near

another NFC-enabled device.

E7824_ME400CL_User_Manual.indd 9 12/5/12 2:41:14 PM

ASUS VivoTab

Audio speaker

Your VivoTab is equipped with a built-in high quality

stereo speaker. Audio features are software controlled.

Micro USB 2.0 port

Use the micro USB (Universal Serial Bus) 2.0 port to

charge the battery pack or supply power to your

VivoTab.

Charging your VivoTab

Connect the micro USB cable to the power adapter.

Plug the micro USB connector into your VivoTab.

Plug the power adapter into a grounded socket outlet.

To charge your VivoTab:

E7824_ME400CL_User_Manual.indd 10 12/5/12 2:41:15 PM
