RS500-E6/PS4
Conguration Guide
II
Copyright © 2009 ASUSTeK COMPUTER INC. All Rights Reserved.
No part of this manual, including the products and software described in it, may be reproduced, transmitted,
transcribed, stored in a retrieval system, or translated into any language in any form or by any means,
except documentation kept by the purchaser for backup purposes, without the express written permission
of ASUSTeK COMPUTER INC. (“ASUS”).
ASUS provides this manual “as is” without warranty of any kind, either express or implied, including but not
limited to the implied warranties or conditions of merchantability or tness for a particular purpose. In no
event shall ASUS, its directors, ofcers, employees, or agents be liable for any indirect, special, incidental,
or consequential damages (including damages for loss of prots, loss of business, loss of use or data,
interruption of business and the like), even if ASUS has been advised of the possibility of such damages
arising from any defect or error in this manual or product.
Specications and information contained in this manual ae furnished for informational use only, and are
subject to change at any time without notice, and should not be construed as a commitment by ASUS.
ASUS assumes no responsibility or liability for any errors or inaccuracies that may appear in this manual,
including the products and software described in it.
Product warranty or service will not be extended if: (1) the product is repaired, modied or altered, unless
such repair, modication of alteration is authorized in writing by ASUS; or (2) the serial number of the
product is defaced or missing.
Products and corporate names appearing in this manual may or may not be registered trademarks or
copyrights of their respective companies, and are used only for identication or explanation and to the
owners’ benet, without intent to infringe.
E4332
First Edition V1
February 2009
III
Contents
Contents ...................................................................................................... III
Revision history.......................................................................................... III
Safety information ...................................................................................... IV
Chapter 1: Product introduction
1.1 Key features.................................................................................. 1-2
1.2 System overview.......................................................................... 1-3
1.3 Front panel features..................................................................... 1-4
1.4 Rear panel features...................................................................... 1-4
1.5 Systemspecications ................................................................. 1-5
Chapter 2: Components
2.1 Upgrading CPU and CPU heatsink............................................. 2-2
2.2 Upgrading system memory......................................................... 2-4
2.3 Upgrading hard disk drives......................................................... 2-6
2.4 Installing ASUS PIKE RAID module............................................ 2-7
2.5 Installing ASUS Server Management Board.............................. 2-8
2.6 OS support list ............................................................................. 2-9
Revision history
Revision Revision history Date
V1 First release of RS500-E6/PS4 conguration guide February 2009
IV
Safety information
Electrical Safety
• Before installing or removing signal cables, ensure that the power cables for
the system unit and all attached devices are unplugged.
• To prevent electrical shock hazard, disconnect the power cable from the
electrical outlet before relocating the system.
• When adding or removing any additional devices to or from the system, contact
a qualied service technician or your dealer. Ensure that the power cables for
the devices are unplugged before the signal cables are connected. If possible,
disconnect all power cables from the existing system before you service.
• If the power supply is broken, do not try to x it by yourself. Contact a qualied
service technician or your dealer.
Operation Safety
• Servicing of this product or units is to be performed by trained service
personnel only.
• Before operating the server, carefully read all the manuals included with the
server package.
• Before using the server, ensure all cables are correctly connected and the
power cables are not damaged. If any damage is detected, contact your dealer
as soon as possible.
• To avoid short circuits, keep paper clips, screws, and staples away from
connectors, slots, sockets and circuitry.
• Avoid dust, humidity, and temperature extremes. Place the server on a stable
surface.
This product is equipped with a three-wire power cable and plug for the user’s
safety. Use the power cable with a properly grounded electrical outlet to avoid
electrical shock.
Lithium-Ion Battery Warning
CAUTION! Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type recommended by the
manufacturer. Dispose of used batteries according to the manufacturer’s
instructions.
CD-ROM Drive Safety Warning
CLASS 1 LASER PRODUCT
Heavy System
CAUTION! This server system is heavy. Ask for assistance when moving or
carrying the system.
1-
This chapter describes the key
features of RS500-E6/PS4. It includes
the product overview and general
specications.
Chapter 1
Product introduction
Chapter 1: Product introduction1-2
1.1 Key features
Mass Storage & Memory Capacity
RS500-E6/PS4 has four 3.5” hot-swap HDD bays to support SATA or SAS HDDs,
meeting the demand of mass storage, using 12 DDR3-DIMM slots for enhanced
memory scalability.
Scalable & Flexible RAID solution –ASUS PIKE upgrade kit
ASUS unique PIKE upgrade kit meets the demand of direct SAS RAID upgrade
solution, connected through a unique slot without sacricing system expandability,
and compatible with all ASUS Tylersburg system.
User-friendly Server Remote Management - ASMB4-iKVM upgrade kit
With ASMB4 upgrade kit in remote severs, Local users can remote-manage remote
severs by keyboard, video monitor and mouse (KVM) of local side computer, and
share the date saved in a local side drive to remote target servers. It provides the
most quick and efcient way to recover the system in service and signicantly
improves the system’s availability by the complete remote management tools.
Virtualization Support
With Virtualization, Different application and operation software could share
hardware equipments in one system, It could increase server utilization, and
reduce IT total cost of ownership.RS500-E6/PS4 supports virtualization and is
certied by VMware.
GreenDesignwithhighpowerefciency
With 80+ PFC high efciency power supply, RS500-E6/PS4 is able to reduce the
power loss and power consumption, and save power bill for users.
ASUS EPU technology, which intelligently calibrates the best possible settings
to ensure the best power efciency, and all Japan-made 5000hr ultra durable
conductive polymer capacitors onboard provide durability, improved lifespan.
ASUS RS500-E6/PS4 1-3
1.2 System overview
Items Items
1. Central processing unit (CPU) 6. PIKE 1064E/1078 RAID module (optional)
2. CPU heatsink 7. Riser card bracket
3. System memory 8. Riser card
4. Hard disk drives 9. ASUS Server management board (optional)
5. HDD trays
6
2
1
9
8
7
5
4
3
Chapter 1: Product introduction1-4
1.3 Front panel features
1.4 Rear panel features
12
Hot-swap HDD bays
Optical drive
Rack screw Rack screw
USB ports
LAN2 LED
HDD Access LED
LAN1 LED
Message LED
Power
button
Power
LED
Location switch
Reset button
Location LED
PS/2 keyboard port
USB ports
LAN port 1
Serial port
VGA port
Expansion slots
LAN port 2
Power cord connector
Power supply fan
PS/2 mouse port
LAN port 3*
• * The port is for ASUS ASMB4-iKVM controller card only.
ASUS RS500-E6/PS4 1-5
1.5 Systemspecications
Model Name RS500-E6/PS4
Processor / System Bus
2 x Socket LGA1366
Intel®Xeon® 5500 series processors (45nm)
Quad-Core / Dual-Core
QPI 4.8 / 5.86 / 6.4 GT/s
Core Logic Intel® 5500 I/O Hub
Intel® ICH10R
ASUS Features Smart Fan √
ASWM 2.0 √
Memory
Total Slots 12 (3-channel per CPU, 6 DIMMs per CPU)
Capacity Maximum up to 96GB (RDIMM)
Maximum up to 48GB (UDIMM)
Memory Type DDR3 1333 / 1066 / 800 Reg DIMM / Unbuffered
DIMM with ECC
Memory Size 512MB, 1GB, 2GB, 4GB and 8GB
Expansion Slots
Total PCI/PCI-X/
PCI-E Slots 3
Slot Type
1 x PCI-E G2 x16 slot (G2 x8 link) (Full-Height/
Half-Length)
1 x PCI-E G2 x8 slot (G2 x8 link) (Full-Height/
Half-Length)
Additional Slot 1 x PIKE slot with PCI-E G1 x4 link
Storage
SATA Controller
Intel® ICH10R:
6 x SATA2 300MB/s ports
Intel®Matrix Storage (for Windows only)
- Supports software RAID 0, 1, 5 & 10
LSI MegaRAID (for Linux / Windows)
- Supports software RAID 0, 1 & 10
SAS Controller
Optional:
ASUS PIKE 1064E 4-port SAS RAID card
- Supports software RAID 0, 1 & 1E
ASUS PIKE 1078 8-port SAS RAID card
- Supports hardware RAID 0, 1, 10, 5 & 6
HDD Bays
I = Internal
A or S will be
hot-swappable
4 x Hot-swap 3.5” SAS/SATA HDD Bays
(continued on the next page)
Chapter 1: Product introduction1-6
*Specicationsaresubjecttochangewithoutnotice.
Networking LAN 2 x Intel® 82574L PCI-E GbE LANs
Graphic VGA Aspeed AST2050 / 8MB
Auxiliary Storage CD / DVD 1 x Slim-type Optical Device Bay
Options: No Device / DVD-RW
Onboard I/O
1 x External Serial Port
3 x RJ-45 ports
4 x USB 2.0 ports (Front x 2, Rear x 2)
1 x VGA port
1 x PS/2 keyboard port
1 x PS/2 mouse port
OS Support
Windows® Server 2008 R2 Enterprise 32 / 64-bit
Windows® Server 2003 R2 Enterprise 32 / 64-bit
RedHat® Enterprise Linux AS5.0 32 / 64-bit
SuSE® Linux Enterprise Server 10.0 32 / 64-bit
(Subject to change without any notice)
Anti-virus Software CA® eTrust™ 7.1 anti-virus software (Optional)
Management
Solution
Out of Band
Remote
Hardware
Onboard IPMI Solution
ASMB4-iKVM for KVM-over-IP support (Optional)
Software ASUS ASWM 2.0 and SNMP®
Dimension (HH x WW x DD) 615mm x 444mm x 43.4mm
Net Weight Kg (CPU, DRAM &
HDD not inclu ded) 14 Kg
Power Supply 600W 80+ Single Power Supply
Environment
Operation temperature: 10°C ~ 35°C / Non operation
temperature: -40°C ~ 70°C
Non operation humidity: 20% ~ 90% ( Non-condensing)
