Asus BR-HD3 Manuel
Index
1. English .................................................................................1
2. FrançaisFrançais ...............................................................................8
3. Deutsch ................................................................................15
4. Italiano................................................................................22
5. Русский .............................................................................29
6. Español ..............................................................................36
7. Čeština...............................................................................43
8. Nederlands ........................................................................50
9. Português...........................................................................57
10. 繁體中文.............................................................................64
11. ไทย.....................................................................................71
12. Türkçe ................................................................................78
13. Notice.................................................................................85
Q5328_BR-HD3_FAQ.indb 1 2/9/10 3:29:23 PM
E5328 / January 2010
First Edition
BR-HD3 Wireless HDMI Kit
Supplementary Guide
ASUS BR-HD3 receiver
ASUS BR-HD3 transmitter
®
Q5328_BR-HD3_FAQ.indb 1 2/9/10 3:29:26 PM
BR-HD3 Wireless HDMI Kit Supplementary Guide
2
English
Setting up PS3 and XBox to 1080i output
Setting up PS3 to 1080i output
To set up PS3 to 1080i output:
1. UsinganHDMIcable,connectthePS3toahigh-denitionexternaldisplay.
2. Go to My PS3 > System Settings > Display > Video output settings > HDMI
> Customer,thenchoose1080i or 720P.
3. TurnoffthePS3.
4. ConnecttheHDMItransmittertothePS3andtheHDMIreceivertotheexternal
display.
5. Turnonallthedevices.
Setting up XBox 360 to 1080i output
1. UsinganHDMIcable,connecttheXBox360toahigh-definitionexternal
display.
2. Go to My XBOX > System Settings > Console Settings > Display > HDTV
Settings,thenchoose1080i or 720P.
3. TurnofftheXBox360.
4. UsingthebundledHDMIcables,connecttheHDMI transmittertotheXBox360
andtheHDMI receivertotheexternaldisplay.
5. Turnonallthedevices.
BeforeusingtheBR-HD3WirelessHDMIKit,ensurethatyourPS3orXBox360’sscreen
resolutionissetto1080i.Refertothefollowingsectionsformoredetails.
Q5328_BR-HD3_FAQ.indb 2 2/9/10 3:29:27 PM
BR-HD3 Wireless HDMI Kit Supplementary Guide
3
English
Setting up your computer to 1080i output
Using Windows®utility
To use Windows utility:
1. Right-clickanywhereonWindows
desktop,andclick Screen resolution.
2. Click Advanced settings.
• Ensurethatyourcomputerisconnectedtoahigh-denitionexternaldisplayusingan
HDMIcable.
• BeforeusingtheBR-HD3WirelessHDMIKit,ensurethatyourcomputer’sscreen
resolutionissetto1080i.Refertothefollowingsectionsformoredetails.
Q5328_BR-HD3_FAQ.indb 3 2/9/10 3:29:27 PM
BR-HD3 Wireless HDMI Kit Supplementary Guide
4
English
3. Click List All Modes.
4. Select1920 by 1080, True
color (32 Bit), 30Hertz
(Interlaced).
Q5328_BR-HD3_FAQ.indb 4 2/9/10 3:29:28 PM
BR-HD3 Wireless HDMI Kit Supplementary Guide
5
English
Using NVIDIA®utility
To use NVIDIA utility:
1. LaunchtheNVIDIAControlPanel.SelectVideo &Television.
2. SelectChange the signal or HD format
3. Select1080i HDTVsignalformat.
Using ATI®utility
To use ATI utility:
1. L a u n c h t h e ATi C o n t r o l
Center.SelectAdvanced.
Q5328_BR-HD3_FAQ.indb 5 2/9/10 3:29:28 PM
BR-HD3 Wireless HDMI Kit Supplementary Guide
6
English
2. Click Graphics.
3. SelectDesktop Properties.
4. From theDesktop area field,
select1920 X 1080.
5. FromtheRefreshratedropdown
list,select30i Hz.
Q5328_BR-HD3_FAQ.indb 6 2/9/10 3:29:29 PM
BR-HD3 Wireless HDMI Kit Supplementary Guide
7
English
Troubleshooting
IR relay does not work.
1. ChecktheIRcableconnection.
a. Thepart of the IR Blaster withthe Player sidestickeronitmustbe
connectedtotheBR-HD3transmitter.
Player Side
2. EnsurethattheIRReceiverandIRBlasterarenotplaceddirectlyfacingeach
other.
PlacingtheIRReceiverandIRBlasterdirectlyfacingeachotherresultstoan
innitesignalloop,whichcausestheIRrelayfunctiontofail.
b. ThepartoftheIRReceiverwiththeTV sidestickeronitmustbeplaced
ontheBR-HD3receiver.
TV Side
Q5328_BR-HD3_FAQ.indb 7 2/9/10 3:29:30 PM
F5328/Janvier2010
Premièreédition
Kit HDMI sans l BR-HD3
Guide complémentaire
Récepteur ASUS BR-HD3
Émetteur ASUS BR-HD3
®
Q5328_BR-HD3_FAQ.indb 8 2/9/10 3:29:31 PM
BR-HD3 Wireless HDMI Kit Supplementary Guide
9
Français
Congurer une PS3/XBox en sortie 1080i
Sortie 1080i sur PS3
Pour congurer la PS3 sur une sortie vidéo de 1080i :
1. Àl'aided'uncâbleHDMI,connectezlaPS3àunpériphériqued'afchageHD.
2. SélectionnezParamètres > Paramètres afchage > Paramètres de sortie
vidéo > HDMI > Personnalisé,puissélectionnez1080i ou 720P.
3. ÉteignezlaPS3.
4. Connectezl'émetteurHDMIàlaPS3etlerécepteuraupériphérique
d'afchage.
5. Allumeztouslespériphériques.
Sortie 1080i sur XBox 360
1. Àl'aided'uncâbleHDMI,connectezlaXBox360àunpériphériqued'afchage
HD.
2. Sélectionnez Ma Xbox > Paramètres système > Paramètres de la console >
Afchage > Paramètres TVHD,puissélectionnez1080i ou 720P.
3. ÉteignezlaXBox360.
4. AveclescâblesHDMIfournis,connectezl'émetteurHDMI àlaXBox360etle
récepteurHDMIaupériphériqued'afchage.
5. Allumeztouslespériphériques.
Avantd'utiliserlekitHDMIsanslBR-HD3,assurez-vousquelarésolutiondevotrePS3ou
XBox360estdéniesur1080i.Référez-vousauxsectionssuivantespourplusdedétails.
Q5328_BR-HD3_FAQ.indb 9 2/9/10 3:29:32 PM
