Asus ROG STRIX XG27VQ Manuel utilisateur
ii
Copyright © 2017 ASUSTeK COMPUTER INC. All Rights Reserved.
No part of this manual, including the products and software described in it, may be reproduced,
transmitted, transcribed, stored in a retrieval system, or translated into any language in any form or
by any means, except documentation kept by the purchaser for backup purposes, without the express
written permission of ASUSTeK COMPUTER INC. (“ASUS”).
Product warranty or service will not be extended if: (1) the product is repaired, modied or altered, unless
such repair, modication of alteration is authorized in writing by ASUS; or (2) the serial number of the
product is defaced or missing.
ASUS PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS
OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OR CONDITIONS OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT SHALL ASUS, ITS
DIRECTORS, OFFICERS, EMPLOYEES OR AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL, INCIDENTAL,
OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF PROFITS, LOSS OF BUSINESS,
LOSS OF USE OR DATA, INTERRUPTION OF BUSINESS AND THE LIKE), EVEN IF ASUS HAS BEEN
ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM ANY DEFECT OR ERROR IN THIS
MANUAL OR PRODUCT.
SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE FURNISHED FOR
INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE AT ANY TIME WITHOUT NOTICE, AND
SHOULD NOT BE CONSTRUED AS A COMMITMENT BY ASUS. ASUS ASSUMES NO RESPONSIBILITY OR
LIABILITY FOR ANY ERRORS OR INACCURACIES THAT MAY APPEAR IN THIS MANUAL, INCLUDING THE
PRODUCTS AND SOFTWARE DESCRIBED IN IT.
Products and corporate names appearing in this manual may or may not be registered trademarks or
copyrights of their respective companies, and are used only for identication or explanation and to the
owners’ benet, without intent to infringe.
First Edition
June 2017
iii
Table of Contents
Notices ................................................................ iv
Safety information............................................. v
Care & Cleaning ................................................vii
Takeback Services .........................................viii
1.1 Welcome!.................................................. 1-1
1.2 Package Contents................................ 1-1
1.3 Assembling the Monitor Arm/Base.. 1-2
1.4 Connect Cables...................................... 1-3
1.4.1 Rear of the LCD Monitor ..........................1-3
1.5 Monitor Introduction............................. 1-4
1.5.1 Using the Control Buttons .......................1-4
1.5.2 GamePlus Function .....................................1-5
1.5.3 GameVisual Function..................................1-7
2.1 Detaching the Stand (for VESA Wall
Mount) ............................................................. 2-1
2.2 Adjusting the Monitor .......................... 3-1
3.1 OSD (On-Screen Display) Menu....... 3-2
3.1.1 How to Reconfigure ....................................3-2
3.1.2 OSD Function Introduction.......................3-3
3.2 Specifications........................................ 3-9
3.3 Troubleshooting (FAQ) ..................... 3-11
3.4 Supported Timing List...................... 3-12
iv
Notices
Federal Communications Commission
Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
• This device may not cause harmful interference, and
• This device must accept any interference received including
interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in
a residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with
manufacturer’s instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment to an outlet on a circuit different from that to
which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
This product implements power management functionality. In case of no
signal input after 10 seconds, the product automatically goes to sleep/standby
mode.
v
Canadian Department of
Communications Statement
This digital apparatus does not exceed the Class B limits for radio noise
emissions from digital apparatus set out in the Radio Interference Regulations
of the Canadian Department of Communications.
This class B digital apparatus complies with Canadian ICES-003.
AEEE Yönetmeliğine Uygundur
Regional Notice for India
This product complies with the “India E-Waste (Management) Rules, 2016”
and prohibits use of lead, mercury, hexavalent chromium, polybrominated
biphenyls (PBBs) and polybrominated diphenyl ethers (PBDEs) in
concentrations exceeding 0.1 % by weight in homogenous materials and
0.01% by weight in homogenous materials for cadmium, except for the
exemptions listed in Schedule II of the Rule.
Safety information
• Before setting up the monitor, carefully read all the documentation
that came with the package.
• To prevent re or shock hazard, never expose the monitor to rain or
moisture.
• Never try to open the monitor cabinet. The dangerous high voltages
inside the monitor may result in serious physical injury.
• If the power supply is broken, do not try to x it by yourself. Contact a
qualied service technician or your retailer.
• Before using the product, make sure all cables are correctly
connected and the power cables are not damaged. If you detect any
damage, contact your dealer immediately.
• Slots and openings on the back or top of the cabinet are provided for
ventilation. Do not block these slots. Never place this product near or
over a radiator or heat source unless proper ventilation is provided.
vi
• The monitor should be operated only from the type of power source
indicated on the label. If you are not sure of the type of power supply
to your home, consult your dealer or local power company.
• Use the appropriate power plug which complies with your local
power standard.
• Do not overload power strips and extention cords. Overloading can
result in re or electric shock.
• Avoid dust, humidity, and temperature extremes. Do not place the
monitor in any area where it may become wet. Place the monitor on a
stable surface.
• Unplug the unit during a lightning storm or if it will not be used for a
long period of time. This will protect the monitor from damage due to
power surges.
• Never push objects or spill liquid of any kind into the slots on the
monitor cabinet.
• To ensure satisfactory operation, use the monitor only with UL listed
computers which have appropriate congured receptacles marked
between 100-240V AC.
• The socket-outlet shall be installed near the equipment and shall be
easily accessible.
• If you encounter technical problems with the monitor, contact a
qualied service technician or your retailer.
• This product may contain chemicals known to the State of California
to cause cancer, and birth defects or other reproductive harm. Wash
hands after handling.
vii
Care & Cleaning
• Before you lift or reposition your monitor, it is better to disconnect
the cables and power cord. Follow the correct lifting techniques
when positioning the monitor. When lifting or carrying the monitor,
grasp the edges of the monitor. Do not lift the display by the stand or
the cord.
• Cleaning. Turn your monitor off and unplug the power cord. Clean the
monitor surface with a lint-free, non-abrasive cloth. Stubborn stains
may be removed with a cloth dampened with mild cleaner.
• Avoid using a cleaner containing alcohol or acetone. Use a cleaner
intended for use with the LCD. Never spray cleaner directly on the
screen, as it may drip inside the monitor and cause an electric shock.
The following symptoms are normal with
the monitor:
• The screen may icker during the initial use due to the nature of the
uorescent light. Turn off the Power Switch and turn it on again to
make sure that the icker disappears.
• You may nd slightly uneven brightness on the screen depending on
the desktop pattern you use.
• When the same image is displayed for hours, an afterimage of the
previous screen may remain after switching the image. The screen
will recover slowly or you can turn off the Power Switch for hours.
• When the screen becomes black or ashes, or cannot work anymore,
contact your dealer or service center to x it. Do not repair the screen
by yourself!
viii
Conventions used in this guide
WARNING: Information to prevent injury to yourself when trying to
complete a task.
CAUTION: Information to prevent damage to the components when
trying to complete a task.
IMPORTANT: Information that you MUST follow to complete a task.
NOTE: Tips and additional information to aid in completing a task.
Where to find more information
Refer to the following sources for additional information and for product and
software updates.
1. ASUS websites
The ASUS websites worldwide provide updated information on ASUS
hardware and software products. Refer to http://www.asus.com
2. Optional documentation
Your product package may include optional documentation that may
have been added by your dealer. These documents are not part of the
standard package.
Takeback Services
ASUS recycling and takeback programs come from our commitment to the
highest standards for protecting our environment. We believe in providing
solutions for our customers to be able to responsibly recycle our products,
batteries and other components as well as the packaging materials.
Please go to http://csr.asus.com/english/Takeback.htm for detail recycling
information in different region.
1-1
ASUS LCD Monitor XG27VQ Series
1.1 Welcome!
Thank you for purchasing the ASUS®LCD monitor!
The latest widescreen LCD monitor from ASUS provides a crisper, broader, and
brighter display, plus a host of features that enhance your viewing experience.
With these features, you can enjoy the convenience and delightful visual
experience that the monitor brings to you!
1.2 Package Contents
Check your package for the following items:
LCD Monitor
Monitor Base
Quick Start Guide
Warranty Card
Support CD
1x Adaptor
1x Power Cord
1x HDMI Cable (optional)
1x DP Cable (optional)
LED projection cover and changeable lms (optional)
Input/Output Ports Cover
• If any of the above items is damaged or missing, contact your retailer
immediately.
• Select “ON” when you see the message “LIGHT IN MOTION ON/OFF”
appears if you want to turn on the red light on the base. Select “OFF” if you
want it to turn off. If you disable this function but later wish to reactivate
it, please use the OSD menu to turn it on.
• If no signal is detected for around 12 minutes, the monitor automatically
enters saving mode.
1-2 Chapter 1: Product Introduction
1.3 Assembling the
Monitor Arm/Base
•While assembling the monitor arm/base, we recommend that you keep the
monitor inside its EPS (Expanded Polystyrene) packaging.
1. Align the screw hole on the arm with the bundled screw on the base. Then
insert the base into the arm.
2. Fix the base to the arm by fastening the bundled screw.
3. Align the triangle marks on the monitor base and the LED projection cover.
Then attach the LED projection cover to the monitor base.
4. Remove the monitor from its EPS packaging.
Table des matières
Autres manuels Asus Moniteur
Asus
Asus VG259 Series Manuel utilisateur
Asus
Asus VW223B Manuel utilisateur
Asus
Asus VE278Q Series Manuel utilisateur
Asus
Asus VS238 Series Manuel utilisateur
Asus
Asus VG258QM Series Manuel utilisateur
Asus
Asus VW226 Series Manuel utilisateur
Asus
Asus VZ27V Series Manuel utilisateur
Asus
Asus VG246 Series Manuel utilisateur
Asus
Asus PA34V Series Manuel utilisateur
Asus
Asus PA24A Series Manuel utilisateur
Asus
Asus VA24DQSB Manuel utilisateur
Asus
Asus SE465-Y Manuel utilisateur
Asus
Asus VP248 Series Manuel utilisateur
Asus
Asus ROG SWIFT PG329Q-W Manuel utilisateur
Asus
Asus VP32U Series Manuel utilisateur
Asus
Asus TUF Gaming VG279QM Series Manuel utilisateur
Asus
Asus MT276H Manuel utilisateur
Asus
Asus ZenScreen Touch MB16AMT Manuel utilisateur
Asus
Asus PA147CDV Series Manuel utilisateur
Asus
Asus VE198TL Series Manuel utilisateur
