Asus W5A Instructions d'utilisation
E1846 / Nov 2004
Notebook PC
Hardware User’s Manual
2
Contents
1. Introducing the Notebook PC ..................................................................5
Preparing your Notebook PC .....................................................................................9
2. Knowing the Parts...................................................................................11
Top Side ...................................................................................................................12
Bottom Side..............................................................................................................14
Left Side ...................................................................................................................16
Right Side.................................................................................................................17
Rear Side .................................................................................................................18
Front Side.................................................................................................................19
3. Getting Started ....................................................................................... 21
Power System ..........................................................................................................22
Using AC Power ..................................................................................................22
Using Battery Power............................................................................................23
Charging the Battery Pack...................................................................................23
Powering ON the Notebook PC...........................................................................24
The Power-On Self Test (POST) .........................................................................24
Checking Battery Power......................................................................................25
Battery Care ........................................................................................................25
Powering OFF the Notebook PC.........................................................................26
Restarting or Rebooting.......................................................................................26
Using the Keyboard..................................................................................................27
Colored Hot Keys ................................................................................................27
Keyboard as Cursors...........................................................................................28
Keyboard as a Numeric Keypad..........................................................................28
Microsoft Windows™ Keys..................................................................................28
Buttons and Status Indicators ..................................................................................29
Buttons (LCD Panel)............................................................................................29
Status Indicators (left of touchpad)......................................................................30
Status Indicators (top cover)................................................................................31
4. Using the Notebook PC ......................................................................... 33
Operating System ....................................................................................................34
Support Software.................................................................................................34
3
Contents
Pointing Device ........................................................................................................35
Using the Touchpad.............................................................................................35
Touchpad Usage Illustrations ..............................................................................36
Caring for the Touchpad ......................................................................................37
Storage Devices.......................................................................................................39
PC Card (PCMCIA) Socket .................................................................................39
Removing a PC Card (PCMCIA) .........................................................................39
Optical Drive ........................................................................................................41
Flash Memory Reader .........................................................................................42
Hard Disk Drive ...................................................................................................42
Modem Connection ..................................................................................................43
Fast-Ethernet Connection (Gigabit on selected models) .........................................44
Power Management Modes .....................................................................................45
Full Power Mode & Maximum Performance........................................................45
ACPI ....................................................................................................................45
Suspend Mode ....................................................................................................45
Power Savings.....................................................................................................45
Stand by and Hibernate.......................................................................................46
Appendix..................................................................................................... 49
Optional Accessories................................................................................................50
USB Hub (Optional).............................................................................................50
USB 2.0 Slim Combo Drive (Optional) ................................................................50
USB Flash Memory Disk .....................................................................................51
USB Communication Cable.................................................................................51
Wireless LAN Card or USB Adapter ....................................................................51
USB Keyboard and Mouse..................................................................................52
USB Floppy Disk Drive ........................................................................................53
Optional Connections...............................................................................................53
Monitor Out Connection.......................................................................................53
External Audio Connections ................................................................................53
Securing Your Notebook PC................................................................................54
IEEE1394 Connection .........................................................................................54
Printer Connection...............................................................................................54
4
Contents
Glossary ...................................................................................................................55
Declarations and Safety Statements........................................................................60
DVD-ROM Drive Information ...............................................................................60
Internal Modem Compliancy................................................................................61
Federal Communications Commission Statement ..............................................62
Canadian Department of Communications Statement ........................................63
UL Safety Notices................................................................................................64
Power Safety Requirement..................................................................................64
Optical Drive Safety Information..........................................................................65
Laser Safety Information .....................................................................................65
CDRH Regulations ..............................................................................................65
Macrovision Corporation Product Notice.............................................................65
Nordic Cautions (for Notebook PC with Lithium-Ion Battery) ..............................67
CTR 21 Approval (for Notebook PC with built-in Modem) ...................................67
Notebook PC Information.........................................................................................68
5
1. Introducing the Notebook PC
About This User’s Manual
Notes For This Manual
Safety Precautions
Preparing your Notebook PC
6
1 Introducing the Notebook PC
About This User’s Manual
You are reading the Notebook PC User’s Manual. This User’s Manual provides information on the
various components in the Notebook PC and how to use them. The following are major sections of this
User’s Manuals:
1. Introducing the Notebook PC
Introduces you to the Notebook PC and this User’s Manual.
2. Knowing the Parts
Gives you information on the Notebook PC’s components.
3. Getting Started
Gives you information on getting started with the Notebook PC.
4. Using the Notebook PC
Gives you information on using the Notebook PC’s components.
5. Appendix
Introduces you to optional accessories and gives additional information.
Notes For This Manual
A few notes and warnings in bold are used throughout this guide that you should be aware of in order to
complete certain tasks safely and completely. These notes have different degrees of importance as
described below:
NOTE: Tips and information for spe-
cial situations.
TIP: Tips and useful information for
completing tasks.
Text enclosed in < > or [ ] represents a key on the keyboard; do not actually type the <
> or [ ] and the enclosed letters.
< >
[ ]
WARNING! Important information that
must be followed for safe operation.
IMPORTANT! Vital information that
must be followed to prevent damage
to data, components, or persons.
User’s Manual
7
Introducing the Notebook PC 1
Safety Precautions
The following safety precautions will increase the life of the Notebook PC. Follow all precautions and
instructions. Except as described in this manual, refer all servicing to qualified personnel. Do not use
damaged power cords, accessories, or other peripherals. Do not use strong solvents such as thinners,
benzene, or other chemicals on or near the surface.
Disconnect the AC power and remove the battery pack(s) before cleaning. Wipe the
Notebook PC using a clean cellulose sponge or chamois cloth dampened with a solu-
tion of nonabrasive detergent and a few drops of warm water and remove any extra
moisture with a dry cloth.
DO NOT expose to or use near liq-
uids, rain, or moisture. DO NOT use
the modem during an electrical storm.
DO NOT expose to dirty or dusty en-
vironments. DO NOT operate during
a gas leak.
DO NOT expose to strong magnetic
or electrical fields.
DONOTexposetoextremetemperatures
above 50˚C (122˚F) or to direct sunlight.
Do not block the fan vents!
DO NOT place on uneven or unstable
work surfaces. Seek servicing if the
casing has been damaged.
DO NOT place or drop objects on top
and do not shove any foreign objects
into the Notebook PC.
DO NOT press or touch the display
panel. Do not place together with small
itemsthatmayscratchorentertheNote-
book PC.
DO NOT leave the Notebook PC on
your lap or any part of the body while
the Notebook PC is turned ON or is
charging in order to prevent discom-
fort or injury from heat exposure.
DO NOT throw batteries in fires as
they may explode. Check local codes
for special battery disposal instruc-
tions.
DO NOT expose to extreme tempera-
tures (below 0˚C (32˚F), otherwise the
Notebook PC may not boot.
Safe Operating Temperatures: This
notebook PC should be used in envi-
ronments with ambient temperatures
between 0°C/32°F and 30°C/86°F.
30°C/86°F
0°C/32°F
8
1 Introducing the Notebook PC
Transportation Precautions
To prepare the Notebook PC for transport, you should turn it OFF and discon-
nect all external peripherals to prevent damage to the connectors.The hard
disk drive’s head retracts when the power is turned OFF to prevent scratching
of the hard disk surface during transport. Therefore, you should not transport
the Notebook PC while the power is still ON. Close the display panel and check
that it is latched securely in the closed position to protect the keyboard and
display panel.
Cover Your Notebook PC
Use a carrying case such as the one supplied with your Notebook PC to protect it from dirt, water,
shock, and scratches.
Charge Your Batteries
If you intend to use battery power, be sure to fully charge your battery pack and any optional battery
packs before going on long trips. Remember that the power adapter charges the battery pack as long as
it is plugged into the computer and an AC power source. Be aware that it takes much longer to charge
the battery pack when the Notebook PC is in use.
Airplane Precautions
Contact your airline if you want to use the Notebook PC on the airplane. Most airlines will have restric-
tions for using electronic devices. Most airlines will allow electronic use only between and not during
takeoffs and landings.
CAUTION! There are three main types of airport security devices: X-ray machines
(used on items placed on conveyor belts), magnetic detectors (used on people walk-
ing through security checks), and magnetic wands (hand-held devices used on people
or individual items). You can send your Notebook PC and diskettes through airport X-
ray machines. However, it is recommended that you do not send your Notebook PC or
diskettes through airport magnetic detectors or expose them to magnetic wands.
NOTE: The surface glaze is easily dulled if not properly cared for. Be careful not to rub
or scrap the Notebook PC surfaces when transporting your Notebook PC.
9
Introducing the Notebook PC 1
Preparing your Notebook PC
These are only quick instructions for using your Notebook PC. Read the later pages for detailed infor-
mation on using your Notebook PC.
1. Install the battery pack
3. Open the Display Panel 4. Turn ON the Notebook PC
2.Connect the AC Power Adapter
Press the power button and release.
(In Windows XP, this button can also be used to
safely turn OFF the Notebook PC.)
This Notebook PC features a latchless design.
Lift the display panel with one hand while hold-
ing the system portion with your other hand.
3
1
2
1
2
3
WARNING! When opening, do not force the display panel down to the table or else
the hinges may break! Never lift the Notebook PC by the display panel!
10
Autres manuels pour W5A
2
Ce manuel convient aux modèles suivants
2
Table des matières
Autres manuels Asus Ordinateur portable
Asus
Asus TUF Gaming FX504 Manuel utilisateur
Asus
Asus T100 Series Manuel utilisateur
Asus
Asus G1Sn Instructions d'utilisation
Asus
Asus 1000HD - Eee PC Celeron M 900MHz 1GB 120GB 10.1" Netbook XP... Manuel utilisateur
Asus
Asus L1A Manuel utilisateur
Asus
Asus E3101 Instructions d'utilisation
Asus
Asus Eee PC 1002HA Manuel utilisateur
Asus
Asus AX201D2 Mode d’emploi
Asus
Asus K401UQ Mode d’emploi
Asus
Asus B9440UA-GV0028R-OSS Mode d’emploi
Asus
Asus Eee PC 701SD Series Instructions de montage
Asus
Asus ROG G752VS GC018T Mode d’emploi
Asus
Asus X88Se Manuel utilisateur
Asus
Asus Chromebook Flip C214MA Manuel utilisateur
Asus
Asus G73JH-A1 Manuel utilisateur
Asus
Asus S62 Series Guide d'installation
Asus
Asus Eee PC 1003HAG Manuel utilisateur
Asus
Asus E203 Mode d’emploi
Asus
Asus B23E Manuel utilisateur
Asus
Asus W1N Manuel utilisateur
