ASUS CX200 Internet Camera
®
E2864
CX200
Mimic CX200 Internet Camera
User Manual
Copyright © 2006 ASUSTeK COMPUTER INC.
All Rights Reserved.
ASUS CX200 Internet Camera
ii
Chapter 1 Introduction
Section 1. Features...................................................................1
Section 2. ASUS Mimic CX200 as a Remote Surveillance
System........................................................................................3
Section 3. Package Contents....................................................4
Chapter 2 Hardware Installation
Section 1. Installation Procedure (Without PoE Injector).........6
Section 2. Installation Procedure (With PoE Injector)..............6
Chapter 3 Web Interface
Section 1. Introduction.............................................................7
Section 2. Using the Web Interface..........................................8
2.1 To View Video.......................................................9
2.2 Information..........................................................12
2.2.1 System Status.................................................12
2.2.2 Current Connections........................................13
2.2.3 Event Log........................................................14
2.3 Basic Settings.....................................................14
2.3.1 Camera Settings..............................................14
2.3.2 Network...........................................................16
2.3.3 Account Settings.............................................21
2.4 Advanced Settings..............................................25
2.4.1 Event Notication............................................26
2.4.2 Motion Detection.............................................30
2.4.3 Image Recording..............................................34
2.4.4 E-mail / FTP.....................................................36
ASUS CX200 Internet Camera iii
2.4.5 System Settings..............................................40
2.4.6 About..............................................................44
Chapter 4 View Images Using PDA/PPC/mobile
Chapter 5 Using the Utility
Section 1. Installation.............................................................48
Section 2. Using the Utility Program......................................50
2.1 Setup Wizard.......................................................50
2.2 Launch Mimic CX200..........................................55
2.3 IP Conguration...................................................56
2.3.1 IP Address........................................................57
2.3.2 Advanced (for password and HTTP
conguration)..............................................................58
2.4 Upgrade Firmware...............................................60
2.5 About.................................................................60
2.6 Refresh................................................................61
Chapter 6 MultiMonitor
Section 1. Installating MultiMonitor........................................62
Section 2. Using MultiMonitor.................................................62
2.1 Device.................................................................65
2.2 View....................................................................78
2.3. System...............................................................79
2.4 User....................................................................79
2.5 Help....................................................................81
2.6 Drag-and-Drop Feature.......................................81
ASUS CX200 Internet Camera
iv
Appendix A:
Methods to Update ASUS Mimic CX200 Firmware.................83
Appendix B:
IP Address, Subnet and Gateway............................................84
Appendix C:
Glossary....................................................................................87
ASUS Contact Information
1ASUS CX200 Internet Camera
Section 1. Features
ASUS Mimic CX200 is a compact stand-alone web-server capable of
remote video surveillance. It can be accessed from anywhere in the
world via a standard browser by entering the IP Address, account and
password. Each system can support an additional USB PC cameras be
it regular, infra-red or pan-tilt. With its built-in web-server, ASUS Mimic
CX200 can stream video images directly to the Internet without have to
go through a computer.
ASUS Mimic CX200 features a Windows-based software that allows the
user to archive streaming video directly to the hard-drive. The same
software also allows the user to monitor multiple cameras on one screen.
Chapter 1: Introduction
Features:
• LCD display.
• Built-in Web Server
• Built-in Power over Ethernet (PoE)
• Built-in CMOS Camera
• Extra Mini USB Port for USB PC Camera
• Support Pan/Tilt and Infrared USB PC Camera (sold separately)
• 10/100Mbps Fast Ethernet Network Access
• Support Any Java-Enabled Web Browser
• LCD display shows the IP address, Subnet Mask and Gateway
• 32-Bit RISC CPU
• Support Up to 30 Remote Viewers for each camera
• Allow Up to 8 User Accounts and Passwords
• 5.3VDC 1A Maximum
2ASUS CX200 Internet Camera
• Operating Temperature: 0°C ~ 60°C; Operating Humidity: 10% ~ 90%
• Dimensions: 13mm x 70mm x 170mm
• Weight: 75g
• For Indoor Use. Protective housing required for outdoor use.
• Network Protocol: HTTP, TCP/IP, UDP, SMTP, PPPoE, Dynamic DNS, DNS
Client, SNTP, BOOTP, DHCP, FTP, SNMP
• Support USB PC Camera with VIMICRO ZC0301 Plus processor built-in
• Resolution available: 640x480 (VGA), 352x288 (CIF), 320x240
(QVGA), 176x144 (QCIF), 160x120 (QQVGA).
• Frame Rate: Up to 15fps in 640x480, Up to 20fps in 320 x 240.
• Motion JPEG streaming video
3ASUS CX200 Internet Camera
Section 2. ASUS Mimic CX200 as a Remote Surveillance System
Once ASUS Mimic CX200 is installed, the user can check any of the
connected PC cameras using a standard web browser. The user can
monitor and control these cameras simply by entering the IP address
shown on the LCD into a Browser.
ASUS Mimic CX200 Network Diagram
4ASUS CX200 Internet Camera
Section 3. Package Contents
ASUS Mimic CX200 package contain the following items:
1. ASUS Mimic CX200 IP camera
2. Quick Installation Guide
3. Utility CD containing:
a. Utility: to congure IP address, update the rmware, etc.
b. MultiMonitor: to monitor multiple ASUS Mimic CX200 cameras.
c. Time Server: Time adjustment utility.
d. Adobe Acrobat 5.0 Reader.
e. ASUS Mimic CX200 User Manual
f. Camera Windows Driver
4. Power adaptor
ASUS Mimic CX200 LCD displayed information
5ASUS CX200 Internet Camera
ASUS Mimic CX200 Front and Back view
6ASUS CX200 Internet Camera
1. Connect the Power Adaptor to the mini
USB port.
2. Connect the LAN cable to a router.
3. Wait a moment and the LCD will display
the IP Address, Subnet and Gateway. Use a
Browser to log into ASUS Mimic CX200 Web
Interface.
The icon on the LCD shows that a USB
camera is connected.
Chapter 2: Hardware Installation
The following details the hardware installation procedure for ASUS Mimic
CX200 IP camera.
Section 1. Installation Procedure (Without PoE Injector)
1. Connect power and LAN cable into the PoE
Data In port.
Next connect ASUS Mimic CX200 LAN cable to
the PoE Data Out port.
2. Wait a moment and the LCD will display
the IP Address, Subnet and Gateway. Use a
Browser to log into ASUS Mimic CX200 Web
Interface.
The icon on the LCD shows that a USB
camera is connected.
1
2
3
1
2
