All-in-One PC TV

Quick Start Guide

English

Setting up your Digital / Analog TV Tuner

Before launching your TV Tuner application, check if your digital TV-in or analog TV-in cable is

connected.

Launching your TV Tuner Application

To launch ArcSoft TV 5.0 in Windows® 8, do one of the following:

From the Windows® desktop, click the Arcsoft TV

5.0 icon.

NOTE: The Arcsoft TV desktop shortcut icon is

not available for AIO ET2300

•

Click + <Q> to launch the search screen for

applications. Type “Arcsoft” in the search eld

and click the Arcsoft TV icon from the search

results.

•

Setting up your TV Tuner Application

To set up ArcSoft TV 5.0:

1. On the main menu, click Live TV.

2. The Setup Wizard will launch to guide you

through setting up your TV Tuner application.

Select your country or region and click Next

to continue.

English

3. The Setup Wizard will attempt to detect

the installed TV Tuner device. Select the

appropriate TV tuner card which came with

your All-in-One PC.

5. Click Scan to begin scanning for available

channels.

4. Select the type of television service you use.

Select Cable TV for cable television.

Select Antenna TV for television received

via an antenna.

•

6. If your All-in-One PC came with both an

analog and digital TV tuner, the Setup Wizard

will prompt you to set up your second TV

tuner.

Select Yes to set up the second TV Tuner.

Select No to complete the Setup Wizard.

•

7. Click Finish to complete the Setup Wizard.

English

To schedule recordings of TV broadcasts:

1. On the main menu, click Schedule.

Scheduling recordings of TV broadcasts

2. On the left panel, click Add.

3. Congure the following options:

Program Name

Channel

Frequency

Start Date/Time - Specify the date/

time of recording.

Duration - Specify length of recording.

Shut down the computer when

nished recording

•

4. Click Done to save settings and schedule recording.

NOTE: The All-in-One PC needs to be powered on to automatically record TV broadcasts.

5. To schedule additional recordings, repeat steps 1~4.

NOTE: The number of recordings you can schedule is limited by the available storage on your

All-in-One PC.

Using the Entertainment Program Guide (EPG)

NOTE: EPG is only available for All-in-One

PCs with a digital TV tuner.

The EPG displays the time and TV programs

playing on a specied channel and date.

English

Using the Live TV Onscreen Controls

Home button

Click this icon to go to the Arcsoft TV 5.0 main menu.

TV/AV

Click this button to toggle between analog TV and digital TV.*

*This item is only available for All-in-One PCs with both an analog and digital TV tuner.

Take a screenshot

Click this button to take a screen capture of the video or media playing.

Record

Click this button to begin recording the television broadcast.

Pause

Click this button to pause recording or playback.

Volume Controls

Click this button to display onscreen volume controls to increase/decrease volume.

CH- / CH+

Click this button to increase or decrease the channel by one.

Add to Favorites

Click this button to add this channel to the Favorites list.

Favorites List

Click this button to display list of saved Favorites.

Subtitles and Audio Tracks

Click this button to display list of available subtitles and audio channels/tracks.

34 5 6 8

English

Using the Remote Control

RGYB

ABC DEF

GHI JKL MNO

PQRS TUV WXYZ

CLEAR ENTER

Channel controls

Information

Number keys

Volume controls

Clear

Back

Playback buttons

Navigation Keys

Power on/off

Enter

Mute

Shortcut buttons

Teletext buttons

Media Center buttons

Start

English

Playback Buttons

Play

Starts playing media. If playback is paused, pressing this button begins

playback from the current position.

Pause

Pauses media playback at the current position.

Stop

Stops playing media at the current position.

Record

Record the TV show to disk. If pressed while Live TV is on, records the

current show. If pressed from the EPG screen, records a TV show or TV

series to disk.

Fast Forward

Speeds up the playback of the media le to the rst forward value (3X).

Rewind

Reverses direction of playback and speeds up the time base to the rst

rewind value (3X).

Skip Forward

Skips forward one increment when this button is pressed.

Skip Back

Skips backward one increment when this button is pressed.

Navigation Keys

Press the up/down keys to move through the menu bar in a submenu.

Press the up/down keys to decrease/increase a numerical value.

Press the left/right keys to move through the main menus in the Home

screen.

Press the left/right keys to move through the items in a submenu.

Press OK to conrm the selection.

Start*

Takes the user to the Windows Media Center Start menu.

*This button is only available for All-in-One PCs installed with Windows Media

Center.

English

Volume controls

Press the (+) button to increase the volume by one unit. Press the (-) button to decrease

the volume by one unit.

Back

Moves back one position in the user interface,

Number keys

Clear

Clear any entered user input.

Power on/o

Press this button to put the All-in-One PC to sleep mode. Press a second time to wake

up the system from sleep mode.

Media Center Buttons*

Record TV

Displays the Recorded TV page in Windows Media Center.

Guide

Displays the media guide in Windows Media Center.

Live TV

Shows live TV on the currently selected channel.

DVD menu

Displays the DVD menu.

*These buttons are only available for All-in-One PCs installed with Windows Media Center.

Channel controls

Increases/decreases the current channel by one.

Mute

Mutes the computer audio.

Information

Press to display information about the movie, video, or music.

Enter

Press this button to select an option or input text.

CLEAR

ENTER

English

Media Center Shortcut buttons

Displays the main Radio page in Windows Media Center.

Displays the Music Library in Windows Media Center.

Displays the Picture Library in Windows Media Center.

Displays the Video Library in Windows Media Center.

*These buttons are only available for All-in-One PCs installed with Windows Media Center.

Teletext buttons*

Press these buttons to access Teletext features when available.

*These buttons are only available for All-in-One PCs installed with Windows Media

Center.

RGYB

NOTE:

• To avail of Windows Media Center features, you can purchase a Windows 8 Media Center

Pack separately.

• You can download a version of this manual in a dierent language at the ASUS support

site at http://support.asus.com
