Aspen 70-0200 Manuel utilisateur
GLD Products Aspen Table Tennis
Item 70-0200
Item 70-0200
September 2013 UPC Code 7-19265-51830-3
ASPEN OUTDOOR
TABLE TENNIS
Replacement Parts
Order direct at www.gldproducts.com
or call our Customer Service department at
(800) 225-7593
8 am to 4:30 pm Central Standard Time
GLD Products Aspen Table Tennis
Item 70-0200
Staple your receipt here.
Important: A copy of your receipt will be needed to activate your warranty (see page 18)
GLD Products Aspen Table Tennis
Item 70-0200
3 1-800-225-7593
www.gldproducts.com
Congratulations and THANK YOU for purchasing the
Aspen Outdoor Table Tennis. You have chosen a
product that should provide years of entertainment.
To assist you with customer service and warranty
claims, staple your receipt to the inside cover, then
keep this manual in a safe place for future reference.
GLD Products
S84 W19093 Enterprise Drive
Muskego, WI 53150 USA
1-800-225-7593
Fax: 1-800-841-6944
Email: [email protected]
Web: www.gldproducts.com
This manual may have been updated. For the latest manual visit the GLD products website.
Place your package near the location where it will be used. Carefully unpack
all components and verify you have all the correct pieces.
If you notice missing or defective parts, please call us at:
1-800-225-7593 ext 113.
Please read and understand all instructions before beginning assembly.
This assembly will require 2 adults.
This product is not for use by children without adult supervision.
GLD Products Aspen Table Tennis
Parts Identifier Item 70-0200
1-800-225-7593 4
www.gldproducts.com
Part
No./
Qty
Illustration/
Order Number
Part
No./
Qty
Illustration/
Order Number
Part
No./
Qty
Illustration/
Order Number
1
Qty.
2
Table Top
2
Qty.
4
Leg
Order No. 9-30
3
Qty.
4
Leg Link
Order No. 9-31
4
Qty.
4
Leg Stabilizer
Order No. 9-32
5
Qty.
2
Caster Support
Order No. 9-33
6
Qty.
1Center Bracket
Order No. 9-34
7
Qty.
4
Wheel Support
Order No. 9-35
8
Qty.
8
Wheel
Order No. 9-36
9
Qty.
2
Side Support
Order No. 9-37
10
Qty.
1
Paddle Holder
Order No. 9-38
11
Qty.
2
Net Holder
Order No. 9-39
12
Qty.
2
Net Pin
Order No. 9-40
13
Qty.
1Net
Order No. 9-41
14
Qty.
4Hex Head Bolt
M12 x 140 mm
Order No. 9-14
15
Qty.
4Phillips Head Screw
M8 x 60 mm
Order No. 9-15
16
Qty.
4Hex Head Bolt
M8 x 85 mm
Order No. 9-16
17
Qty.
4Hex Head Bolt
M8 x 60 mm
Order No. 9-17
18
Qty.
4Hex Head Bolt
M6 x 50 mm
Order No. 9-18
GLD Products Aspen Table Tennis
Item 70-0200
5 1-800-225-7593
www.gldproducts.com
19
Qty.
8
Hex Head Bolt
M6 x 40 mm
Order No. 9-1
20
Qty.
4Washer Head Nut M12
Order No. 9-19
21
Qty.
12
Locking Nut M8
Order No. 9-12
22
Qty.
16 Nut M6
Order No. 9-6
23
Qty.
6
Nut M5
Order No. 9-20
24
Qty.
4Washer 12 mm I.D.
Order No. 9-21
25
Qty.
12
Washer 8 mm I.D.
Order No. 9-11
26
Qty.
16
Spacer 6 mm I.D.
Order No. 9-22
27
Qty.
4Spacer 8 mm I.D.
Order No. 9-23
28
Qty.
6
Washer 5 mm I.D.
Order No. 9-24
29
Qty.
36
Washer 6 mm I.D.
Order No. 9-3
30
Qty.
2
Phillips Round Head Screw
M5 x 15 mm
Order No. 9-25
31
Qty.
4
Phillips Round Head Screw
M5 x 25 mm
Order No. 9-26
32
Qty.
4
Hex Head Bolt
M6 x 65 mm
Order No. 9-28
33
Qty.
2
Spacer
Order No. 9-27
GLD Products Aspen Table Tennis
Item 70-0200
6 1-800-225-7593
www.gldproducts.com
IF YOU HAVE A WARRANTY CLAIM, CALL US FIRST
Please see page 18.
GLD Products
Available 8 am to 4:30 pm Central Standard Time
S84 W19093 Enterprise Drive
Muskego, WI 53150 USA
1-800-225-7593
Fax: 1-800-841-6944
Email: [email protected]
Web: www.gldproducts.com
For all claims, please have your receipt and item number when you call. The
product item number can be found on the front cover.
If you are instructed to return the product for service, you are
responsible for shipping the unit at your expense.
PRODUCT REGISTRATION
Important: The product registration form on page 19 and a copy of your
receipt must be completed and returned within 10 days of purchase to
validate your warranty.
Online registration is also available. Go to
www.gldproducts.com/index.php/registration or click on this link. Follow the
online instructions.
Preparing for Assembly
• Be sure to unpack all of the parts included in this package. Some
parts may be in obscure locations of the packaging. Check inside
any tubes or sleeves. Save all packing material until the product is
fully assembled and functional.
• Compare the parts in your package with the Parts Identifier
description on pages 4 and 5.
• After unpacking large products, some disassembly may be required
prior to beginning the assembly.
GLD Products Aspen Table Tennis
Item 70-0200
7 1-800-225-7593
www.gldproducts.com
Tools Required
• Hex Open End Wrenches:
8 mm, 10 mm, 13 mm, and 18 mm (not included)
• Phillips screwdriver (not included)
• Electric screwdriver may be helpful. CAUTION: You must set at
LOW TORQUE and use extreme caution because you could
overtighten the hardware, strip the screws, or damage the table.
• Rubber mallet or hammer (not included)
Precautions to Prevent Personal Injury and Damage
• Indoor only tables will not withstand outdoor conditions. If using the
table outdoors, move it indoors as soon as possible.
• Be alert for surface changes when moving the table. Cracks and
changes in the slope may cause the table to tip over.
• The table is not designed for supporting heavy loads. Do not place
heavy items on the table. Collapse of the support structure is
possible. Do not sit or stand on the top of the table.
• When using the table all the support legs and wheels must be in
contact with the floor. Failure to properly support the table may
damage the frame and table top.
• Opening or closing the table presents a risk for pinching. Keep all
children away and alert adults when moving the table top up or
down.
• Liquids left on the playing surface for extended peroids will damage
the table top. Wipe up any spills immediately.
For Outdoor Tables
• Strong winds may move or tip the table over. Take precautions as
needed to prevent damage or injury.
• Do not leave balls or paddles outside. They will likely be damaged
by outdoor conditions.
GLD Products Aspen Table Tennis
Item 70-0200
8 1-800-225-7593
www.gldproducts.com
Assembly Tips
Make sure you understand the following before you begin to assemble your table tennis.
1. READ THIS MANUAL all the way through before beginning assembly.
2. When installing parts that have more than one bolt, start ALL bolts in that part by hand
before tightening anything.
3. Some drawings or images in this manual may not look exactly like your product.
4. You will need a second adult to assist with this assembly.
Note: Save all packing materials until the parts have been inspected and the table is
assembled.
Unpack the Pieces
• Lay the box on a flat surface (floor). You may want this near your
area of assembly.
• Unpack the boxes and part bags. Inspect and count the parts. The
Parts Identifier page can be used to record your results.
• If any parts are damaged or missing contact GLD customer service.
• Missing fasteners may be purchased at a hardware store using the
descriptions on the Parts Identifier page(s).
• Paddles and balls not included.
GLD Products Aspen Table Tennis
Item 70-0200
9 1-800-225-7593
www.gldproducts.com
STEP 1 - ASSEMBLE CASTER SUPPORTS
1. Locate the two caster supports (#5).
2. Position a wheel support (#7) and insert a bolt (#14) thru the support and then thru the
caster support.
3. Place a washer (#24) onto the bolt and secure the assembly with a washer head nut
(#20). The caster support must rotate smoothly.
4. Locate two wheels (#8) and insert a bolt (#16) thru a wheel, the caster support and the
second wheel.
5. Use a locking nut (#21) to secure the wheels. Tighten the locking nut and be certain the
wheels roll smoothly.
6. Repeat numbers 2 thru 5 on the second wheel assembly.
7. Locate the parts for the second wheel and support assembly. Follow numbers 1 thru 6.
8
21 14
5
8
16
20
24
7
GLD Products Aspen Table Tennis
Item 70-0200
10 1-800-225-7593
www.gldproducts.com
STEP 2 - ASSEMBLE SIDE SUPPORTS AND CENTER BRACKET
1. Locate the two side supports (#9), the center bracket (#6) and the paddle holder (#10).
2. Position one of the side supports (#9) so the smooth side will face away from the wheel
assembly.
3. Insert two screws (#15) thru the side support and into the caster support.
4. Hold the screws in position and place one end of the center bracket (#6) over the screws.
5. Use a washer (#25) and a locking nut (#21) to secure the three pieces.
6. Repeat numbers 2 thru 5 on the other end of the center bracket.
7. On one end of the assembly, position the paddle holder (#10). Insert two screws (#30)
thru a washer (#28) and the holder. Hold the screws in place thru the holes in the side
support (see detail A).
8. Tighten two nuts (#23) onto the screws.
10
23
28 30
28 30
A
625
21
15
9
25
21
