Asko DC7784V Manuel utilisateur
Drying cabinet
DC7784V.W.U
USER MANUAL
Read the user manual before using the machine.
879787ae.indd 1879787ae.indd 1 7. 02. 2023 14:53:507. 02. 2023 14:53:50
Dear ASKO customer,
Congratulations on the choice you have made, and welcome to the
ASKO family, a global family with its roots in Sweden.
We at ASKO thank you for your trust and hope that you will enjoy
using your new drying cabinet.
A good drying cabinet should be well designed, dry clothes well,
have a low enironmental impact, be user-iendly, save time and
energy, have a long service life and be reliable. ASKO meets all these
requirements.
When you buy an ASKO product you can be sure that the inside is
just as good as the outside and that the ethics and morality that go
into manufacturing this product are just as high as the quality and
function you are getting. at's what Swedish quality is all about.
Before using the product for the rst time, please read the user
instructions and the advice on caring for the product. is will
help you get the best possible results om your product and all its
functions.
If you have any questions, do not hesitate to call us or to contact us
through our website.
Best wishes om Sweden and the ASKO team.
879787ae.indd 2879787ae.indd 2 7. 02. 2023 14:54:037. 02. 2023 14:54:03
3
CONTENTS
IMPORTANT SAFETY
INFORMATION 5
Important safety instructions 6
Installation and connection 9
FOR A GOOD ENVIRONMENT 10
Packaging materials 10
Management of end-of-life drying
cabinet 10
COMPONENTS 11
Control panel 12
Language 13
Unpacking 14
DOOR REVERSING 15
INSTALLATION 20
Location requirements 20
Installation instruction –
Laundry care concept 21
Mounting into custom cabinetry 22
Ventilation connection 25
Ventilation requirements 26
Evacuation / air supply 27
Connection to evacuation 27
Electrical connection 29
BEFORE USING THE DRYING
CABINET 30
OPERATION 31
Arranging laundry for drying 31
Cabinet equipped with coat
hanger rack and shoe rack 31
User advice 31
Air flow 32
Drying programs 33
Child lock 34
Start automatic program 35
Starting a manual program 35
User advice 36
SETTING DRYING PROGRAMS 37
Programming mode 37
Parameter list 38
Adjustment 40
Procedure 41
Restoring to factory setting 41
CARE 42
Cleaning 42
Replacement part 42
OVERHEAT CUT-OUT 43
TROUBLESHOOTING 44
SERVICE AND WARRANTY 45
Service 47
TECHNICAL DATA 48
Energy consumption and drying
times 48
879787ae.indd 3879787ae.indd 3 7. 02. 2023 14:54:037. 02. 2023 14:54:03
4
THIS USER MANUAL
The contents of this user manual describe the function and operation of the drying cabinet,
as well as instructions for installation and maintenance.
The following symbols are used throughout the manual and they have the following
meanings:
Information, advice, tip, or
recommendation Warning – danger of hot surface
Warning – general danger Warning – danger of fire
Warning – danger of electric shock
879787ae.indd 4879787ae.indd 4 7. 02. 2023 14:54:037. 02. 2023 14:54:03
5
This drying cabinet meets applicable safety requirements. Incorrect
use may, however, lead to injuries and damage to objects.
The advice and caution notices in this manual have been written
to enable you to avoid incorrect use and unnecessary risks of
accidents, and should be read before installing and using the drying
cabinet.
IMPORTANT SAFETY INFORMATION
CAUTION: This equipment is intended only to be used to dry
fabrics washed in water.
The appliance is not intended for use by persons (including
children) with various disabilities or inadequate experience
and knowledge.
They may use the appliance only under supervision or
if they have received instructions on how to use the
appliance form a person who is responsible for their
safety.
Children must be supervised to ensure that they do not
play with the appliance.
The drying cabinet must be installed and kept indoors.
If the power cord is damaged, it must be immediately re-
placed, and this must be done only by the manufacturer,
the manufacturer's service agent or similarly qualified
persons in order to prevent danger.
Follow ASKO instructions in repair and replacement of
parts.
879787ae.indd 5879787ae.indd 5 7. 02. 2023 14:54:057. 02. 2023 14:54:05
6
IMPORTANT SAFETY INSTRUCTIONS
WARNING – To reduce the risk of fire, electric shock, or injury
to persons when using your appliance, follow basic precautions,
including the following:
1 Read all instructions before using the appliance.
2 Do not dry articles that have been previously cleaned
in, washed in, soaked in, or spotted with gasoline, dry-
cleaning solvents, or other flammable or explosive
substances, as they give offvapors that could ignite or
explode.
3 Risk of suffocation and injury from entrapment: Do
not allow children to play on or in the appliance. Close
supervision of children is necessary when the appliance is
used near children.
4 Before the appliance is removed from service or discarded,
remove the door to the drying compartment.
5 Do not install or store this appliance where it will be exposed
to the weather.
6 Do not tamper with controls.
7 Do not repair or replace any part of the appliance or attempt
any servicing unless specifically recommended in the
user-maintenance instructions or in published user-repair
instructions that you understand and have the skills to carry
out.
879787ae.indd 6879787ae.indd 6 7. 02. 2023 14:54:057. 02. 2023 14:54:05
7
8 Do not use heat to dry articles containing foam rubber or
similarly textured rubber-like materials.
9 Keep area around the exhaust opening and adjacent
surrounding areas free from the accumulation of lint, dust,
and dirt.
10 The interior of the appliance and exhaust duct should be
cleaned periodically.
11 Do not place items exposed to cooking oils in your drying
cabinet. Items contaminated with cooking oils may contribute
to a chemical reaction that could cause a load to catch fire.
To reduce the risk of fire due to contaminated loads, the final
part of a drying cabinet cycle occurs without heat (cool down
period). Avoid stopping a drying cabinet before the end of the
drying cycle unless all items are quickly removed and spread
out so that the heat is dissipated.
12 Do not use replacement parts that have not been
recommended by the manufacturer (e.g. parts made at home
using a 3D printer).
879787ae.indd 7879787ae.indd 7 7. 02. 2023 14:54:057. 02. 2023 14:54:05
8
For a grounded, cord-connected appliance:
GROUNDING INSTRUCTIONS
This appliance must be grounded. In the event of malfunction
or breakdown, grounding will reduce the risk of electric shock
by providing a path of least resistance for electric current.
This appliance is equipped with a cord having an equipment-
grounding conductor and a grounding plug.The plug must be
plugged into an appropriate outlet that is properly installed and
grounded in accordance with all local codes and ordinances.
WARNING– Improper connection of the equipment-
grounding conductor can result in a risk of electric shock. Check
with a qualified electrician or service representative or personnel
if you are in doubt as to whether the appliance is properly
grounded.
Do not modify the plug provided with the appliance: if it will
not fit the outlet, have a proper outlet installed by a qualified
electrician.
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE!
879787ae.indd 8879787ae.indd 8 7. 02. 2023 14:54:057. 02. 2023 14:54:05
9
WARNING!
Install the drying cabinet according to the
manufacturer’s instructions and local codes.
WARNING!
Drying cabinet installation must be performed by
a qualified installer.
WARNING!
To reduce the risk of severe injury or death,
follow all installation instructions.
WARNING!
Save these instructions.
WARNING!
Do not install a drying cabinet with flexible
plastic venting materials. If flexible metal (foil
type) duct is installed, it must be of a specific
type identified by the appliance manufacturer
as suitable for use with drying cabinets. Flexible
venting materials are known to collapse, be
easily crushed, and trap lint. These conditions
will obstruct drying cabinet airflow and increase
the risk of fire.
WARNING!
• The appliance shall not be exhausted into
a chimney, a wall, a ceiling, an attic, a crawl
space, or a concealed space of a building;
• Only rigid or flexible metal duct shall be used
for exhausting;
• Maximum duct length shall be 8 feet (2.4 m)
and maximum number of bends shall be 4;
• The total length of flexible metal duct shall not
exceed 8 feet (2.4 m);
• The duct shall not be assembled with screws
or other fastening means that extend into the
duct and catch lint.
WARNING!
Do not install a booster fan in the exhaust duct.
INSTALLATION AND CONNECTION
879787ae.indd 9879787ae.indd 9 7. 02. 2023 14:54:067. 02. 2023 14:54:06
10
PACKAGING MATERIALS
The packaging that protects the drying
cabinet against damage in transit has been
chosen with concern for the environment in
mind and is therefore recyclable.
Packaging that is returned to the material
cycle means reduced consumption of raw
materials and a smaller volume of waste.
FOR A GOOD ENVIRONMENT
MANAGEMENT OF END-OF-LIFE
DRYING CABINET
When the drying cabinet has reached the
end of its useful life, it must be taken to a
recycling center for disposal.
Many parts of the drying cabinet can be re-
used, but it also contains other material that
must be handled correctly.
You should therefore never leave the drying
cabinet or parts of the cabinet for collection
with household waste, as this may lead to
risks to health and cause damage to the
environment.
The end-of-life drying cabinet should
instead be taken to a recycling center.
Check with your dealer if necessary.
All the plastic parts of the drying
cabinet are marked with internationally
standardised symbols.
The parts of the drying cabinet can
therefore be recycled in an environmentally
sound manner by waste separation.
879787ae.indd 10879787ae.indd 10 7. 02. 2023 14:54:067. 02. 2023 14:54:06
