Asko D5534ADAFI Guide de l'utilisateur

Asko Appliances, Inc

PO BOX 940609 • Plano • Texas • 75094

Phone 800.898.1879

www.askousa.com

MADE IN

SWEDEN

Art no: 6301706

Type: Fully integrated

Colors: Fully Integrated (FI) model

accommodates a selection of accessory

door panels or customer supplied custom

wood panel.

performance

Capacity: 14 place settings

Noise level 48 dB(A)

7Spray™ system

PowerZone™ Pots & Pans, PowerZone™ Cutlery

proGramS

Heavy Normal

Daily Quick

Super Quick Delicate

Eco Rinse & Dry

Rinse & Hold

Super Quick program in 15 minutes!

feaTUreS

7 Temperatures, Turbo drying™, Delayed start

1-24h, Hidden control, LCD display,

Uses as little at 2.6 gals of water in Quick wash,

Energy Star rated, Fits into opening as low as 32

1/4” height, 2 Plus 1 warranty

flexirackS™

Premium upper rack accommodates:

- 9” items

- Fold-down stemware shelves

- High-side design to protect dishes and glasses

Exclusive lower rack accommodates:

- 13 3/4” dishes

- Fold-down tines for storage flexibility

- Wide tine design for large bowls and platters

- Upper & lower rack handles

Cutlery basket

ASKO Logic Dishwasher

D5534ADAFI

Technical Data

Electricity120V,60Hz,15Amp

Water pressure 18-176 psi

Heating element 1200 watt

Max loading 1300 watt

Cutout Dimensions

US METRIC

HEIgHT: 32 ¼˝ – 34˝ 819 – 864 mm

WIDTH: 5424ADA, 5624ADAHS 24˝ 610 mm

5534ADAFI 23 5/8˝ – 24˝ 600 – 610 mm

DEPTH: 5233ADAHS, 5233ADAFI 22 7/8˝ 581 mm

Depth includes space for the high-loop drain hose

The electrical and water supplies should enter through the

area indicated by the shaded area. Preferably, they should

come through the right side of the machine. The access hole

must be round and smooth and no bigger than 2˝ (51 mm)

in diameter.

*32 ¼˝ / 819 mm height requires removal of top trim &

lower side trim (2)

24˝

(610 mm)

23 5/8˝ – 24˝

(600 mm – 610 mm)

32 ¼˝ – 34˝ minimum

(820 mm – 864 mm)

2˝

(51 mm)

6 ¼˝ – 8 ¼˝

(159 mm – 210 mm)

4˝

(102 mm)

Planning & Design: ADA Dishwashers

D5424ADA, D5534ADAFI, D5634ADAHS

Speciﬁcations are subject to change without notice. See installation instructions for additional details.

Unit Dimensions

US METRIC

HEIgHT:* 32 ¼˝ – 34˝ 819 – 864 mm

WIDTH: 5424ADA, 5634ADAHS 24˝ 610 mm

5534ADAFI 23 5/8˝ 600 mm

DEPTH: 22 7/8˝ 581 mm

DEPTHW/HANDLE:5634ADAHS24 7/8˝ 632 mm

DEPTHW/DOOROPEN: 48 3/8˝1229 mm

WEIgHT:5424ADA,5634ADAHS 106 lbs 48 kg

5534ADAFI 94 lbs 43 kg

2 ¼˝

(57 mm)

6 ¼˝

(159 mm)

32 ¼˝ – 34˝

(819mm – 864 mm)

5534ADAFI 22 7/8˝ (581 mm)

48 3/8˝

(1229 mm)

BACKSIDEFRONT

6 ¼˝ – 8 ¼˝

(159 mm – 210 mm)

2˝ (51 mm)

5534ADAFI 23 5/8˝ (600 mm)

5424ADA & 5634ADAHS 24˝ (610 mm) 5424ADA & 5634ADAHS

24 7/8˝ (632 mm)

*32 ¼˝-34˝

819 - 864 mm

Planning & Design: XXL Dishwashers

D5434XXL, D5624XXL, D5634XXLHS, D5654XXLHS, D5894XXLHS

ADA TALL TANK MODELS

ASKO ADA Compliant Dishwashers

NEW! Dishwasher D5534ADAFI

ASKO Appliances, Inc. - PO BOX 940609 - Plano, TX 75094-0609

Phone: 800-898-1879 - Fax: 972-941-1999

E-mail: [email protected] - www.askousa.com

Image not available!

COLORS:

- Accessory Panels in TouchProof™

Stainless Steel, White, Black and Glass.

Consumer supplied custom panel may

also be used.

CAPACITY:

- 14 place settings PROGRAMS:

- Daily Wash

- Heavy Wash

- Normal Wash

- Delicate Wash

- Quick Wash

- Super Quick Wash

- Eco

- Rinse & Hold

- Rinse & Dry Features:

- 7 Temperatures

- Turbo Drying™

- Delayed Start (1 - 24 hours)

FLEXIRACKS™:

- Premium Upper Rack

- 9" Clearance

- Exclusive Lower Rack

- 12" Clearance

- Wide Tine Design Accomodates Large

Items

- High-side Design Protects Dishware

- Adjustable Tines - Lower Rack

- 2 Adjustable Stemware Shelves

- Cutlery Basket

- Knife Guard CLEANING SYSTEM:

- PowerZone™ Pots-and-Pans

- PowerZone™ Cutlery

- 7Spray™ Wash System

- Self-Cleaning Triple Filtration System

(SCS)

- AquaLevel™ Sensor

DRYING SYSTEM:

- Turbo Drying™ SIMPLICITY /

COMFORT:

- EasyInstall™ Package

- Fully Integrated Model

- Hidden Control Panel w/LCD Display

- Quiet Operation - 48 dB(A)

- End-of-Program Signal SAFETY:

- AquaSafe™ water safety system

- AquaDetect™ Sensor

- SteamSafe™

- KidSafe™ QUALITY:

- 18:9 Stainless Steel Tank, Filter & Spray

Arms

- Anti-Jam, Auto-Reversing Pump

- Galvanized Steel Base Pan

- Balanced Door

- Check Valve

- PEX Water Line (rated 90 year life span)

WARRANTY:

- Industry Leading - 2 Plus 1 Year - Parts &

Labor Protection

Technical specifications - NEW! Dishwasher D5534ADAFI

ASKO Appliances, Inc. - PO BOX 940609 - Plano, TX 75094-0609

Phone: 800-898-1879 - Fax: 972-941-1999

E-mail: [email protected] - www.askousa.com

PROGRAMMING OPTIONS:

Number of programs 9

Delayed Start (hours) 24

End-of-Program signal Yes

COMFORT:

Adjustable feet Yes

CONSUMPTION:

Total annual energy consumption

(kWh) 231

Average water usage (gal) 2.4 (Quick Wash)

Frequency (Hz) 60

Voltage (V) 120

Current (A) 15

DIMENSIONS / WEIGHT:

Variable machine height (min & max)

(inches) 32 1/4 - 34

Width (inches) 24

Depth (inches) 22 7/8

Depth with door open (inches) 48 3/8

OTHER FEATURES:

Largest loadable dish in lower basket

(inches) 12

Noise level dB(A) 48

Stainless Steel hidden heating element Yes

Tank material 18:9 Stainless

steel
