3,000 & 5,000 Series Dishwasher Training Manual

Each section contains:

•Access/Disassembly

•Installation/Reassembly

•Service Tips

•Access to the service menus

•Resistance readings

•Function of components

Dishwasher Service Training Manual

There’s also helpful serial

#label information.

This manual covers the 3,000 & 5,000 series

dishwashers.

Distinctive Features & Innovations

QUALITY:

-18:9 Stainless Steel Tank, Filter & Spray Arms

-Anti-Jam, Auto-Reversing Pump

-Galvanized Steel Base Pan

-Balanced Door

-Check Valve

-PEX Water Line (rated 90 year life span)

WARRANTY:

-Industry Leading -2 Plus 1 Year -Parts & Labor Protection

Distinctive Features & Innovations

FLEXIRACKS™:

-Industry's Only 4 Level Rack System

(High end 5,000 series)

-Exclusive Upper Rack -Height Adjustable

-Exclusive Middle Rack with 2 Removable

Baskets

-Exclusive Lower Rack

-Adjustable Tines / Upper and Lower Racks

-China Guard

-2 Adjustable Stemware Shelves

-Wineglass Shelf -Lower Rack

-Knife Rack

-Cutlery Plus Basket

-Knife Guard

Distinctive Features & Innovations

CAPACITY:

-17 place settings

Distinctive Features & Innovations

CLEANING SYSTEM:

-PowerZone™ Pots-and-Pans

-PowerZone™ Plate

-PowerZone™ Cutlery

-10Spray™ Wash System

-Self-Cleaning Triple Filtration

System (SCS)

-AquaLevel™ Sensor

-SensiClean™ Sensor

DRYING SYSTEM:

-TurboDry™

Warranty Serial # Info

Please hold all warranty parts for (60)

days for possible return for analysis.

The serial label is fastened to the

right side of the tank

Understanding Art. #

•The first 2 #s represent the year: 09 = 2009

•The next 2 #s represent the week: 25 = 25th week of the year

•The next 8 #s represent the serial #

Understanding Serial #

Sometimes a particular model

will have 2 different Art #s

indicating different part lists. The

different Art # indicates a running

change

In the US the model number is located on the

front of the control panel, or on the top of the

door. The TYPE designation, for example DW

20.1 shown on the data plate above is the

Sweden reference or model number. It should

be used when consulting the service manual or

the service menus.

Table of Contents

1st edition and is intended

for service personnel.

Installation……………………………………5

How the dishwasher works………………..9

Drain Pump………………………………….14

Fill Valve……………………………………..15

Pressure sensor……………………………21

Circulation Pump…………………………..22

Heater .……………………………………….25

Water Diverter………………………………26

Float Switch…………………………………27

Detergent dispenser……………………….28

Fan assisted dry……………………………29

Door latch/switch…………………………..30

Upper basket rail bearing & holder……..35

Water fill/air break assemblies…………..38

Service menus &fault codes…………….41

Installation

Easy Install:

All connections are external. No

need to remove kick plates and

panels.

Unit has line cord with plug

already connected

Drain hose with check valve

and multiple connection size

options

Pex fill hose already

attached to unit, and with

3/8” fitting to connect to

water supply 5

Installation –adjusting the springs

Printed from

Installation manual 6
