FriendlyNET 10/100 CardBus Installation Manual

Page 3

Installation Guide for the FriendlyNET

10/100 CardBus

Package Contents

❑

FriendlyNET 10/100 CardBus Adapter

❑

Media coupler

❑

Driver diskette (3 1/2”)

Hardware Description

The FriendlyNET 10/100 CardBus is a credit-card size Ethernet

Adapter for connecting a notebook PC or Macintosh to an

IEEE802.3 or 802.3u Ethernet network. The notebook PC or Mac-

intosh must be equipped a with Cardbus (32bit) extension bus and

Type II or Type III PC Card slot(s). The FriendlyNET 10/100 Card-

Bus is supplied with a media coupler which plugs into the back end

(15-pin) of the adapter. The other end of media coupler has one RJ-

45 connector that connects to UTP network cable. The media cou-

pler has two LED indicators that make it easy to monitor data trans-

mitting, link status, and network speed to assist in troubleshooting.

Table 1:

LED Function Color Description

Link/Act Green Lit: Indicates link

Blinking: Data is being

Transmitted or

Received

100 Green Lit: Indicates that link

is established at

100Mbps

FriendlyNET 10/100 CardBus Installation Manual

Page 4

Hardware Installation for the FriendlyNET 10/100 Card-

Bus

1. Open the Type II or Type III PC Card slot on your notebook

computer.

2. Insert the front end of the FriendlyNET 10/100 CardBus (Black

triangle on top right hand side) into the CardBus slot

3. Slide the FriendlyNET 10/100 CardBus all the way into the slot

until it reaches a ﬁrm stop.

4. Attach the media coupler to the FriendlyNET 10/100 CardBus.

Keep the media coupler triangle mark on top when you plug the

media coupler into the CardBus Adapter.

5. Attach the UTP cabling to connect the Ethernet CardBus

Adapter to your network (hub/switch) (The 100Base-TX maxi-

mum length is 100 meters.)

6. Install the network drivers.

▼

Make sure you have the correct wiring.To reliably operate your net-

work at 100Mbps, you must use Unshielded Twisted-Pair (UTP) Cate-

gory 5 Data Grade wire.

•••••

FriendlyNET 10/100 CardBus Installation Manual

Page 5

Removing the FriendlyNET 10/100 CardBus

1. To remove the media coupler plug from the FriendlyNET 10/

100 CardBus, it is necessary to unlatch the hooks by depressing

the two small latch wings of the plug.

2. Use thumb and foreﬁnger to squeeze the latch wings into the

plug body, gently pull the plug out of media coupler.

3. Firmly press the notebook computer’s eject button to disengage

the FriendlyNET 10/100 CardBus from the slot connector.

4. Grip the FriendlyNET 10/100 CardBus’s protruding end

between your ﬁngers and withdraw it from PC Card slot.

FriendlyNET 10/100 CardBus Installation Manual

Page 6

Software Installation - Macintosh

1. Insert the FriendlyNET 10/100 CardBus disk into the disk

drive.

2. Open the Power Book folder.

3. Double click the FriendlyNet 10_100 Installer icon.

4. Click

Yes

when asked if you wish to continue.

5. Click

Restart

Software Installation for Windows 95 OSR2

1. Insert the FriendlyNET 10/100 CardBus into the CardBus slot.

Windows detects the PCI Ethernet Controller.

2. Insert the FriendlyNET 10/100 CardBus disk and click

3. Windows displays it found the FriendlyNET 10/100 CardBus.

Click

Finish

4. Click

when asked to insert the disk labeled FriendlyNET

10/100 CardBus driver disk.

5. Specify

and click

6. After all ﬁles are copied restart the computer.

▼

The driver works on Windows 95 OSR2 or later version.If your sys-

tem is an older version please upgrade to latest version of Windows

95. MSWindows 95 old versions (ver:950, 950a) cannot support plug

& play for the FriendlyNET 10/100 CardBus.

FriendlyNET 10/100 CardBus Installation Manual

Page 7

Software Installation for Windows 98

1. Insert the FriendlyNet 10/100 CardBus into the CardBus slot.

Windows detects the PCI Ethernet Controller and searches for

new drivers for

PCI Fast Ethernet DEC 21143 Based

Adapter.

2. Insert the FriendlyNet 10/100 disk and click

3. Select “Search for the best driver for your device” and click

4. Specify

and click

5. Click

on the next window when Windows ﬁnds the

FriendlyNet 10/100 CardBus.

6. Click

when asked to insert the FriendlyNet 10/100 CardBus

driver disk.

7. Specify

then click

8. Click

Finish

and restart the computer after ﬁles are copied.

Software Installation for Windows NT 4

1. Insert the FriendlyNET 10/100 CardBus into the CardBus slot.

2. Double click the

Network

icon in the “My Computer” ->

“Control Panel”

3. Click the

Adapters

tab then click the

Add

button.

4. Insert the FriendlyNET 10/100 CardBus disk and click the

Have Disk

button.

5. Specify

then click

6. Windows displays “FriendlyNET 10/100 CardBus”. Click

7. Accept the default settings for the Connection Type

(AutoSense), I/O Base Address (0x3000), Interrupt Level (9),

and Store and Forward mode (Enabled).

8. After all ﬁles are copied click the

button and restart the

computer.

FriendlyNET 10/100 CardBus Installation Manual

Page 8

Table 2: Product Speciﬁcations

Standard IEEE802.3/802.3u 10Base-T/

100Base-TX standards

Host Interface PC Card 95 CardBus Standard

Ethernet Data Rate 10Mbps and 100Mbps via Auto-

Negotitation

I/O base address/Interrupt

Number assigned Plug & Play system

Cable Connections RJ-45 (10Base-T) UTP Category 3 or

higher.

RJ-45(100Base-TX) UTP Category 5

or higher

Software Drivers Microsoft Windows NT v4.x, Win-

dows 95/98, Macintosh OSVer 8.5 or

higher

LED Indicators Link/Act - Green

100Mbps - Green

Physical Speciﬁcations Type II size

Operating Environment 0 to 55 C°

Certiﬁcation FCC Class B, CE Mark Class B,

VCCI Class B, C-Tick Class B

FriendlyNET 10/100 CardBus Adapter Installation Manual

Page 9

Technical Support

Contacting Technical Support

To contactAsantéTechnical Support:

Telephone (800) 622-7464

Fax (801) 566-3787

Bulletin Board Service (BBS) (408) 432-1416

FTPArchive ftp.asante.com

Internet Mail [email protected]

WorldWideWeb Site http://www.asante.com

Technical Support Hours

6:00AM to 6:00 PM Mountain time USA,Monday - Friday.
