2.1 CH MULTIMEDIA
SPEAKER SYSTEM
MMS-405
U S E R M A N U A L
(1)
(2)
(3)
(4)
(5)
(6)
Front Panel
• ST-BY/PLAY/PAUSE: Press to turn on speaker, long press into stand-by.
PLAY/PAUSE on the USB/SD/BT mode.
• SOURCE: Change the input mode.
• VOLUME+: Volume up.
•VOLUME-:Volume down
•TUNING+/NEXT: Press once to increase the FM frequency 0.1M, long press
to the semi-automatic search for radio. In USB/SD/BT mode, press “NEXT”
play next song.
•TUNING-/PREVIOUS: Press once to reduce the FM frequency 0.1M, long
press to the semi-automatic search for radio. In USB/SD/BT mode, press
“PREVIOUS” play previous song.
1. TUNING-/
2. SOURCE
3. ST-BY/
4. TUNING+/
6. VOLUME-
7. VOLUME+
Specification:
• Power Audio: 20W+10Wx2(RMS)
• Drive Units: 3” X 2 full range magnetically shielded +5 “subwoofer
• Frequency Response: Satellites: 120Hz-20KHz | Subwoofer: 20Hz-170Hz
• Separation-:≥40dB
• S/N: ≥70dB
• Distortion: ≤0.5%(1K,1W)
• Power Supply: 220V ~ 50Hz
• Dimensions: Subwoofer: W160 X H264 X D279 (mm)
Satellite: W105 X H172 XD99 (mm)
Features:
• Quality 2.1 speaker system with built-in amplifier
• Full audio spectrum performances, ideal for your favorites entertainment
from Mp3, Mp4, CD/DVD movies and digital playbacks
• Frequency Response: Satellites: 120Hz-20KHz | Subwoofer: 20Hz-170Hz
• Specially designed woofer cabinet for bass and resolution
• Comes with remote control and 3.5 stereo connection
Package Contents:
• Subwoofer Cabinet: 1 PC
• Satellite Speakers: 2 PCS
• Remote Control: 1 PC
• User Manual: 1 PC
• Audio Input Cord: 1 PC
Operation explanation:
How to use the remote control
1. Press “ST-BY” LED showing “Au18”, it is AUX mode playing state.
2.“MUTE” means to activate or deactivate mute.
3.“SOURCE”means you can choose AUX, DVD,USB/SD,FM,BL input mode,
at the same time, the LED will show “Au18” means AUX mode, “Du18”
means DVD mode. “87.5” means FM mode, “Bl18” means BL mode.
4.“TONE” means you can choose “TREBLE” and “BASS” “VOL+/-” means
you can increase or decrease volume of “TREBLE” or “BASS”.
5. When enter into FM mode, press “MEMORY” the number on the LED will
Blink. this means the machine is under save channel state. You can change
the blinking number by pressing “NEXT” or “PREV”, press “PLAY/PAUSE”
you can save the channel into same number. it will enter into automatic
search channel and automatic save channel when pressing “MEMORY” for
3-5 seconds (noted: the channel which you saved before will be deleted
when you press “MEMORY” for 3-5 seconds.
8. 0~9
9. MUTE
10. PRESET
11. MEMORY
12. TUNING+
13. PLAY/PAUSE
14. NEXT
VOL+
PRESET
TONE MEMORY
TUNE+
TUNE-
VOL-
SOURCE
(1)
(2)
(5)
(3)
(4)
(6)
(8)
(7)
(9)
(10)
(11)
(12)
(14)
(13)
1. ST-BY
2. SOURCE
3. TONE
4. TUNING-
5. VOL+
6. PREVIOUS
7. VOL-
Website: www.artis.in | www.artisstore.com
Customer care: +91-20-26113250/60
Email: supportpune@artis.in
(1)
(2)
(3)
(4)
Rear panel:
• ANTENNA
• AUX/DVD INPUT Connect to sound sources such as computer, CD
Player,MP3,etc.
• Output: Connect the satellite speakers.
• AC IN: AC Power cord
System connection diagram
L R
Connect the audio sources:
• Connect the 3.5" stereo cable to the input of the subwoofer,Connect the
3.5 stereo input jack into output of the audio sources,such as MP3,MP4,
walkman,computer etc.
• Power on system, adjust the master volume to the suitable level. Adjust
“VOL” to the suitable to meet your different requitement.
* Do not leave objects generating magnetism near the speakers.
SPEAKER TERMINALS
Connect the left & right channel satellite to 2.1 speaker output terminals.
In use please pay attention to the following items:
*if the remote control cannot function, it is because the battery of
remote control has been used up. thank you.
6. In FM mode, after finishing saving channel, press “PRESET” the number
on the LED will blink. This show you have selected the state of save
selected the state of save channel. Press “NEXT” or “PREV” you can
change the blinking number. Press “PLAY/PAUSE” you can choose the
channel which you saved before. Press the number “0-9” on the remote
control. You to choose the channel more faster. under FM function, press
the “ ST-BY ” or “ ” button on the front panel and then press
“ ” , “ ”, to change channel.
7. When entering into USB/SD mode. “NEXT” means next song; “PREV”
means previous song; “PLAY/PAUSE” means play/pause;pressing the
number “0-9” on the remote control, you can choose the corresponding
song.
8.
VOL+/- means you can increase or decrease volume.
9. ”TUNING-” means decrease the frequency of channel selection. Press
“TUNING-” for a long time means decrease the frequency of channel
selection continuously
10.
”TUNING+”means increase the frequency of channel selection. Press
“TUNING+” for a long time means increase the frequency of channel
selection continuously.
11.
”PLAY/PAUSE” means play/pause for USB/SD/BT.
12.
”PREV” means previous song for USB/SD/BT.
13. ”NEXT” means next song for USB/SD/BT.
14. Press “SOURCE” buttons on the remote to convert to BT input
mode, LED display right bottom start to flashing (2 seconds) to search the
BT device. Turn on your mobile BT device and search the device name “BT
SPEAKER”
, paired them well. When you have successfully paired
your mobile to the speaker system, the LED right bottom stop flashing.
When start to play your mobile music, the LED flashed every one second.
The functions as "PREVIOUS/NEXT", "PLAY/PAUSE"
, can operate via the
front panel. On BL mode, when connecting with mobile, press “ ” for 3
seconds, BT function can be force-disconnected .
