Specification Multi Sound Bar 1032 SL
Transducer:
LF-MF 6 x 3 inch cone, Symmetric Phase Aligned
HF 3 x 1 inch Dual Ring Radiator, Symmetric
Phase Aligned
Crossover:
Low Pass Filter 6 dB/octave 1000 Hz High Pass
12 dB/octave 4000Hz
Connection:
Single or Bi Amped Gold Plated Push Terminals
Optional multi channel or Mono configuration
Performance:
Operating Range 65 Hz (-3dB) to 40 kHz
Nominal Beamwidth Horizontal 90° Vertical 90°
Axial Sensitivity (whole space SPL) LF/MF-HF (Mono) 99 dB
(Stereo) 87 dB
Input Impedance Nominal Minimum (Mono) 4 ohms (Stereo) 12 ohms
Recommended High Pass Filter =>80 Hz, 24 dB/octave
Maximum Power Handling 80 Watt
Calculated Axial Output Limit (whole space SPL) Average Peak
LF/MF-HF (Mono)115dB (Stereo) 104dB
Weight 8 kg
Dimensions H: 120 W: 1039 D: 67 mm
Finish:
Silk Paint, Black, White and RAL colours
Grille options: Match System fabrics
Specification Multi Sound Bar 1676 SL
Transducer:
LF-MF 8 x 3 inch cone, Symmetric Phase Aligned
HF 3 x 1 inch Dual Ring Radiator, Symmetric
Phase Aligned
Crossover:
Low Pass Filter 6 dB/octave 1000 Hz High Pass
12 dB/octave 4000Hz
Connection:
Single or Bi Amped Gold Plated Push Terminals
Optional multi channel or Mono configuration
Performance:
Operating Range 65 Hz (-3dB) to 40 kHz
Nominal Beamwidth Horizontal 90° Vertical 90°
Axial Sensitivity (whole space SPL) LF/MF-HF (Mono) 99 dB
(Stereo) 87 dB
Input Impedance Nominal Minimum (Mono) 4 ohms (Stereo) 12 ohms
Recommended High Pass Filter =>80 Hz, 24 dB/octave
Maximum Power Handling 80 Watt
Calculated Axial Output Limit (whole space SPL) Average Peak
LF/MF-HF (Mono)115dB (Stereo) 104dB
Weight 12 kg
Dimensions H: 120 W: 1676 D: 67 mm
Finish:
Silk Paint, Black, White and RAL colours
Grille options: Match System fabrics
Specification Multi Sound Bar 1224 SL
Transducer:
LF-MF 6 x 3 inch cone, Symmetric Phase Aligned
HF 3 x 1 inch Dual Ring Radiator, Symmetric
Phase Aligned
Crossover:
Low Pass Filter 6 dB/octave 1000 Hz High Pass
12 dB/octave 4000Hz
Connection:
Single or Bi Amped Gold Plated Push Terminals
Optional multi channel or Mono configuration
Performance:
Operating Range 65 Hz (-3dB) to 40 kHz
Nominal Beamwidth Horizontal 90° Vertical 90°
Axial Sensitivity (whole space SPL) LF/MF-HF (Mono) 99 dB
(Stereo) 87 dB
Input Impedance Nominal Minimum (Mono) 4 ohms (Stereo) 12 ohms
Recommended High Pass Filter =>80 Hz, 24 dB/octave
Maximum Power Handling 80 Watt
Calculated Axial Output Limit (whole space SPL) Average Peak
LF/MF-HF (Mono)115dB (Stereo) 104dB
Weight 9 kg
Dimensions H: 120 W: 1224 D: 67 mm
Finish:
Silk Paint, Black, White and RAL colours
Grille options: Match System fabrics
Specification Multi Sound Bar 1449 SL
Transducer:
LF-MF 6 x 3 inch cone, Symmetric Phase Aligned
HF 3 x 1 inch Dual Ring Radiator, Symmetric
Phase Aligned
Crossover:
Low Pass Filter 6 dB/octave 1000 Hz High Pass
12 dB/octave 4000Hz
Connection:
Single or Bi Amped Gold Plated Push Terminals
Optional multi channel or Mono configuration
Performance:
Operating Range 65 Hz (-3dB) to 40 kHz
Nominal Beamwidth Horizontal 90° Vertical 90°
Axial Sensitivity (whole space SPL) LF/MF-HF (Mono) 99 dB
(Stereo) 87 dB
Input Impedance Nominal Minimum (Mono) 4 ohms (Stereo) 12 ohms
Recommended High Pass Filter =>80 Hz, 24 dB/octave
Maximum Power Handling 80 Watt
Calculated Axial Output Limit (whole space SPL) Average Peak
LF/MF-HF (Mono)115dB (Stereo) 104dB
Weight 11 kg
Dimensions H: 120 W: 1449 D: 67 mm
Finish:
Silk Paint, Black, White and RAL colours
Grille options: Match System fabrics
