ARMTEL DW-IP2 Manuel utilisateur

Document version 6

26.30.11.190

2020

DW-IP2

Weatherproof call station

RMLT.465311.006UM1

User Manual

Part 2

Versions from RMLT.465311.006-100 to RMLT.465311.006-207

ENG

armtel.com

DW-IP2 WEATHERPROOF CALL STATION

User Manual. Part 2

Versions from RMLT.465311.006-100 to RMLT.465311.006-207

armtel.com page 1/48

info@armtel.com © Armtel

ENG

INTRODUCTION

This User Manual is intended for introducing «DW-IP2 Weatherproof call station»

versions from RMLT.465311.006-100 to RMLT.465311.006-207 manufactured by Armtel LLC,

and is intended to familiarize the User with the device and the procedure for its operation

at the installation site.

For versions from RMLT.465311.006 to RMLT.465311.006-75 applies the document

«DW-IP2 Weatherproof call station. Part 1. User Manual. Versions from RMLT.465311.006 to

RMLT.465311.006-75» RMLT.465311.006UM.

DW-IP2 Weatherproof call station is the subscriber equipment to use at industrial and

transportation enterprises within digital Intercom and Public Address / General Alarm

(PA/GA) communication system IPN manufactured by Armtel LLC.

Short name of product – DW-IP2.

DW-IP2 can be used in chemical, mining, oil and gas, metal processing and wood

processing industries and other.

Maintenance personnel for DW-IP2 shall be appointed by the management at

the installation site.

The maintenance personnel shall be required to know the operating procedure of

DW-IP2 to the extent provided for by the User Manual.

Duties of the maintenance personnel shall include maintenance of DW-IP2 in

accordance with this User Manual

ATTENTION! In connection with systematic work to improve the design and

manufacturing technology, it is possible some discrepancy between the description and the

supplied product, which does not affect its operation or maintenance.

DW-IP2 WEATHERPROOF CALL STATION

User Manual. Part 2

Versions from RMLT.465311.006-100 to RMLT.465311.006-207

page 2/48 armtel.com

ENG

SAFETY PROVISIONS

During installation and operation, observe safety precautions laid out in “Occupational

safety rules when operating electrical installations” when working with electrical receivers

with voltage of up to 1000 V.

In order to ensure fire safety, follow the following rules:

−before connecting the product to the power supply, make sure the power and

communication cables are properly insulated;

−protect power and communication cables from damage.

To avoid electric shock, do not:

−turning on the device with damaged power and interface cables.

ATTENTION! NEVER DISMANTLE THE PRODUCT CONNECTED TO MAINS.

The safety provisions for specific operations described in this manual are marked with:

DW-IP2 WEATHERPROOF CALL STATION

User Manual. Part 2

Versions from RMLT.465311.006-100 to RMLT.465311.006-207

armtel.com page 3/48

info@armtel.com © Armtel

ENG

CONTENTS

INTRODUCTION.................................................................................................................................................................... 1

SAFETY PROVISIONS........................................................................................................................................................... 2

CONTENTS .............................................................................................................................................................................. 3

1 DESCRIPTION AND OPERATION................................................................................................................................. 5

1.1 Basic parameters and characteristics (properties) ...................................................................................... 5

1.1.1 Features ............................................................................................................................................................. 5

1.1.2 Main spetifications ........................................................................................................................................ 9

1.1.3 Operations conditions................................................................................................................................11

1.1.4 DW-IP2 design ..............................................................................................................................................12

1.1.5 Marking............................................................................................................................................................18

1.1.6 Package............................................................................................................................................................19

1.2 Description and operation of product components................................................................................20

1.2.1 General information....................................................................................................................................20

1.2.2 Integrated amplifiers ..................................................................................................................................20

1.2.3 ADSL module.................................................................................................................................................21

1.2.4 Dial pad (keypad module) ........................................................................................................................21

1.2.5 Pushbuttons (direct call buttons)...........................................................................................................21

1.2.6 «SOS» and «INFO» modules....................................................................................................................22

1.2.7 Handset............................................................................................................................................................22

1.2.8 Electrical mechanical relay........................................................................................................................22

1.2.9 CCS-DW-IP2 main board ..........................................................................................................................23

1.2.10 DART-6UL processor module ...............................................................................................................23

1.2.11 DW-BC board..............................................................................................................................................24

2 INTENDED USE ................................................................................................................................................................25

2.1 Operating limits .....................................................................................................................................................25

2.2 Safety precautions.................................................................................................................................................25

2.3 Preparation for use ...............................................................................................................................................26

2.4 Installation, connection and dismantling .....................................................................................................27

2.4.1 Installation ......................................................................................................................................................27

2.4.2 Connection .....................................................................................................................................................28

2.4.2 Dismantling ....................................................................................................................................................29

2.5 Operation .................................................................................................................................................................31

2.5.1 Configuration.................................................................................................................................................31

DW-IP2 WEATHERPROOF CALL STATION

User Manual. Part 2

Versions from RMLT.465311.006-100 to RMLT.465311.006-207

page 4/48 armtel.com

ENG

2.5.2 Product operating modes.........................................................................................................................31

2.5.3 Troubleshooting...........................................................................................................................................33

3 MAINTENANCE................................................................................................................................................................35

3.1 General guidelines ................................................................................................................................................35

3.2 Safety precautions.................................................................................................................................................35

3.3 Maintenance procedure......................................................................................................................................35

3.4 Checking operability ............................................................................................................................................36

3.4.1 Checking the audio path...........................................................................................................................36

3.4.2 Functional check for keys/buttons and indicators ..........................................................................36

4 PEPAIR ..............................................................................................................................................................................37

5 STORAGE............................................................................................................................................................................37

6 TRANSPORTATION.........................................................................................................................................................38

7 DISPOSAL...........................................................................................................................................................................38

APPENDIX A (reference) External appearance of DW-IP2 versions.................................................................39

APPENDIX B (reference) PoE function in DW-IP2...................................................................................................42

APPENDIX C (reference) Connection...........................................................................................................................44

APPENDIX D (reference) light indication...................................................................................................................48

DW-IP2 WEATHERPROOF CALL STATION

User Manual. Part 2

Versions from RMLT.465311.006-100 to RMLT.465311.006-207

armtel.com page 5/48

info@armtel.com © Armtel

ENG

1 DESCRIPTION AND OPERATION

1.1 Basic parameters and characteristics (properties)

1.1.1 Features

DW-IP2 Weatherproof call station is the subscriber equipment of a wired public

address system and is designed for use in distributed and centralized (based on the

dedicated SIP server manufactured by Armtel LLC) public address systems in industrial

facilities and on transportation.

DW-IP2 has a modular design, and depending on the modules installed. The version

may vary in accordance with Table 1.

Table 1 – Versions of the DW-IP2 (beginning)

Version identification

(without optional

equipment)

Version identification

with optional equipment

Version

specification

(without optional

equipment)

Overall dimensions,

max, mm

Amplifier 25 W

ADSL module

Amplifier 25 W,

ADSL module

Additional

Ethernet port

Additional

Ethernet port,

amplifier 25 W

RMLT.465311.006-100 -118 -136 -154 -172 -190 2 connections

see

Figure

2a)

-101 -119 -137 -155 -173 -191 4 connections

-102 -120 -138 -156 -174 -192 6 connections

-103 -121 -139 -157 -175 -193 8 connections

-104 -122 -140 -158 -176 -194 16 connections

-105 -123 -141 -159 -177 -195 24 connections

-106 -124 -142 -160 -178 -196

2 connections,

handset, dial pad

see

Figure

2b)

-107 -125 -143 -161 -179 -197

8 connection,

handset, dial pad

-108 -126 -144 -162 -180 -198 handset, dial pad

DW-IP2 WEATHERPROOF CALL STATION

User Manual. Part 2

Versions from RMLT.465311.006-100 to RMLT.465311.006-207

page 6/48 armtel.com

ENG

Table 2 – Versions of the DW-IP2 (end)

Version identification

(without optional

equipment)

Version identification

with optional equipment

Version

specification

(without optional

equipment)

Overall dimensions,

max, mm

Amplifier 25 W

ADSL module

Amplifier 25 W,

ADSL module

Additional

Ethernet port

Additional

Ethernet port,

amplifier 25 W

-109 -127 -145 -163 -181 -199 10 connections

see

Figure

2a)

-110 -128 -146 -164 -182 -200 18 connections

-111 -129 -147 -165 -183 -201 12 connections

-112 -130 -148 -166 -184 -202

2 connections,

dial pad

-113 -131 -149 -167 -185 -203

4 connections,

dial pad

-114 -132 -150 -168 -186 -204

8 connections,

dial pad

-115 -133 -151 -169 -187 -205

10 connections,

dial pad

-116 -134 -152 -170 -188 -206

16 connections,

dial pad

-117 -135 -153 -171 -189 -207

With keys SOS and

INFO, info module

External appearance of version DW-IP2 with 2 connections, dial pad and handset is

shown on Figure 1. The external appearance of all DW-IP2 versions is shown in

Appendix А.

DW-IP2 WEATHERPROOF CALL STATION

User Manual. Part 2

Versions from RMLT.465311.006-100 to RMLT.465311.006-207

armtel.com page 7/48

info@armtel.com © Armtel

ENG

Figure 1 – External appearance o DW-IP2

(versions RMLT.465311.006-106, -124, -142, -160, -178, -196)

DW-IP2 housing structure and material ensure its protect unit elements of dust, foreign

matter and water ingress and etc. DW-IP2 housing and handset (in corresponding versions)

are made of special-purpose UF-resistant fiber-glass reinforced polyester resin.

Rubber gasket seals under the cover, integrated loudspeaker, and microphone, two-

way toggle, as well as in cables glands of DW-IP2 ensure its IP66 ingress protection rating

as per GOST 14254-2015 (IEC 60529:2013).

Integrated loudspeaker has a diaphragm that is resistant to moisture and vapors of

aggressive chemicals. The use of contactless (optical) pairs as sensitive elements of toggle

switches prevents sparks and bad contact due to corrosion. To this end, pushbuttons and

dial pad are sealed with rubber gasket. A porous silicone cord with a diameter of 3 mm is

placed in the groove around the cover.

All of the above-mentioned enables to operate the product regardless of its version in

administrative facilities, in open space and (or) in facilities with high levels of humidity, noise,

dust and temperature, as well as presence of smoke, corrosive gases and chemical vapors in

the air.

DW-IP2 contains embedded software and configuration data stored in RОM, which

allows it to communicate with other digital communication system users directly, handle

priority connections and manage communication and indication modes. An IP-network built

using standard network equipment is used to facilitate communication.

Within the digital intercom system IPN, DW-IP2 provides the following functions:

−Armtel-IP, SIP and SNMP protocol support;

DW-IP2 WEATHERPROOF CALL STATION

User Manual. Part 2

Versions from RMLT.465311.006-100 to RMLT.465311.006-207

page 8/48 armtel.com

ENG

−individual simplex communication via SIP and Armtel-IP protocols;

−half-duplex (manual control) communication via SIP protocol;

−indication of busy call, incoming and outgoing calls, unanswered call notification

on direct buttons;

−free programming of the direct buttons (up to 24 pcs.);

−voice message recording via the programmed key with the local function of

fragment recording and playback of voice messages on end-user devices;

−control of the ACM-IP2 analogue subsystem module with “Relay” function;

−free addressing of subscribers for versions with dial pad;

−connection to the IP network via ADSL or Ethernet 100BaseT;

−enabling organization of a group simplex call;

−call implementation on a priority basis (up to 255 priority levels);

−setting up unilateral control and “End” function modes;

−control (commutation) of external actuating devices using an integrated electro-

mechanical relay (lamp-type signaling device).

Configuration of the DW-IP2 shall be carried out using the personal computer of

the IPN network administrator on which IPN2 RU.RMLT.00041-01 IPN Config Tool software

configuration application is installed.

Autres manuels pour DW-IP2

Table des matières

Autres manuels ARMTEL Système d'interphone

ARMTEL

ARMTEL TOP-PAD-IP2 Manuel utilisateur

ARMTEL

ARMTEL CCS-IP2 Manuel utilisateur

ARMTEL

ARMTEL DIS-IP2 Manuel utilisateur

ARMTEL

ARMTEL DW Manuel utilisateur

Manuels Système d'interphone populaires d'autres marques

Bticino

Bticino LINEA 3000 Manuel utilisateur

MSI

MSI MSI-140 Manuel utilisateur

golmar

golmar Stadio Plus Manuel utilisateur

CyberData

CyberData 011211 series Manuel

Vidos

Vidos duo M1021 Manuel utilisateur

Vimar

Vimar ELVOX 7539/E Manuel utilisateur

SSS Siedle

SSS Siedle BTSV 850-03 Manuel utilisateur

Dahua

Dahua VTO Series Manuel utilisateur

Elvox

Elvox 5651 Manuel utilisateur

Videx

Videx VIDEOKIT Series Manuel utilisateur

Rocom

Rocom Doortello Business FW T2.05W2.04 Manuel utilisateur

Viking

Viking E-35-EWP Manuel utilisateur

Safeguard Supply

Safeguard Supply LRA-EX1000 Manuel utilisateur

SSS Siedle

SSS Siedle BFCV 850 Series Manuel utilisateur

GRD

GRD MAX V2 Manuel utilisateur

Alecto

Alecto ADI-250 Manuel utilisateur

Aiphone

Aiphone IE-8MD Manuel utilisateur

Perel

Perel EDB4 Manuel utilisateur
