Arlo Audio Doorbell
Quick Start Guide
3
View a video tutorial
To view a video tutorial, visit www.arlo.com/support and click the
Arlo Doorbell.
For more information, look for How do I set up my Arlo Audio
Doorbell?.
Scan the QR code to
view the video
4
What’s in the box
Wire screws
Doorbell Wall screws
and anchors
Wire nuts
AA batteries
Wire extensions
Screwdriver
5
Get the Arlo mobile app
You must use the app to install your Arlo Audio Doorbell. The app
provides step-by-step instructions.
6
Power your doorbell and
add it to your Arlo account
1. Insert two AA batteries into your doorbell. Your doorbell runs
on battery power.
2. Use your app to set up your Arlo Doorbell and add it to your
account.
Select your Arlo device.
7
Mount your doorbell without wiring
1. Secure the battery cover on your wall using the provided
screws.
2. Attach the doorbell to the battery cover.
3. Secure the Arlo doorbell with the screw on the bottom of the
battery cover.
Note: To mount your doorbell with wiring,
see page 8.
8
Connect your Arlo doorbell to
trigger your existing chime (Optional)
You can connect your Arlo doorbell to existing mechanical or
electronic doorbells if they operate at a voltage between 8 and 24
volts AC. After you connect your doorbell, press the button on your
Arlo doorbell to trigger your existing chime.
9
Set the chime switch
Determine whether you have a
mechanical or a digital chime.
Mechanical chimes usually make a
sound like ding dong. Digital chimes can
have a variety of sounds, some can play
tunes.
1. If you have a mechanical chime, set
the chime switch to position 2.
2. If you have a digital chime, set the
chime switch to position 1.
10
Connect the doorbell battery cover
to your existing chime
1. Turn o the power to your
current doorbell at the breaker.
2. Remove your current doorbell.
3. Connect the wires coming out of
the wall to the terminals on the
back of the Arlo doorbell battery
cover with the screws we provide.
Wire screw
Battery cover
Current doorbell wires from
your wall (Either wire can
connect to either terminal.)
