Arjo Auralis Manuel utilisateur
Assemble seat cushion and pump
Assemble mattress overlay or mattress replacement and pump
CPR unit is clicked into
closed position.
Connect the tubeset.
Seat cushion:
Place on chair surface.
Use the xing straps to attach.
Place pump on oor, cable under chair,
tubeset placed alongside chair.
Connect the tubeset.
Connect power cable to power source.
• cells facing up
• tubeset at front right corner
• cells horizontal across chair,
V-shape towards front
Front of chair
Back of chair
Zip the protective cover
over the mattress. Arjo
logo visible at the foot
end.
Auralis
2
Mattress overlay:
Place on top of base mattress.
Secure with 4 xing straps.
Mattress replacement:
Place on bed base. Attach the 8
securing straps to moving parts of
bed frame (+ 3 at head end for Auralis
Plus only)
• tubeset at foot end
• CPR at head end
• cells facing up
5
1
4
Hang the pump at the
foot end of the bed.
43
Place cable in the cable
management. Close the
ap around the cable with
the press studs.
Connect power cable to
power source.
6
1 2
08.AI.02EN_04 • 09/2022 • Page 1/4
QUICK REFERENCE GUIDE - USE
Auralis
10s
2s
Autorm mode
Activate: Press and
hold the button.
Comfort indicators ash
and mattress inates to
Autorm.
Extend: Press button to
extend 5 minutes. Max.
30 minutes.
If not extended, pump
goes back to previous
mode.
Deactivate: Press and
hold the button or select
another mode.
Pressure reached –
Autorm and Control
comfort indicators turn to
constant.
CPR rapid deation unit
Activate: Press both CPR release
buttons simultaneously.
Reset: Press down the open part
until it clicks into closed position.
Make sure the front part is open.
The air evacuates rapidly.
2s
Alternating mode, default setting
Activate:
Press button, the Alternating mode indicator is shown.
Adjacent cells inate and deate on a 10 minute cycle.
15 min
Start the Auralis system
When the pump is connected to a power
source it runs a self check:
Beep – 10 seconds – 2 beeps – ready to use.
Press and hold Run/Standby button.
The following indicators are shown:
• Run/Standby
• Wait indicator
• Alternating mode button
• Comfort control indicator
• Battery charge indicator
• Green indicators on the front of the pump
Once the Wait indicator turns
o, place bed sheet on mattress.
Make sure that the CPR rapid
deation unit is clearly visible.
Place patient on the mattress or
seat cushion.
Alternating mode is set by default.
2
1
1
1
2
2
Auralis
Deactivate:
Select Reactive CLP or Autorm mode.
If no further therapy is required, remove patient from
the surface and turn o the pump.
08.AI.02EN_04 • 09/2022 • Page 2/4
2s
Deactivate:
Reconnect the tubeset.
The pump goes back to the previous mode.
Transport mode (mattresses only)
Reactive CLP mode
Activate:
Press and hold the button.
Reactive CLP mode indicator is shown.
Deactivate:
Select Alternating mode or Autorm mode.
If no further therapy is required, remove patient from
the surface and turn o the pump.
Activate:
Press side buttons simultaneously and remove tubeset.
The mattress supports the patient for up to 12 hours.
Lock out mode
Locking:
Push and hold the comfort control buttons
simultaneously.
Comfort control indicators ashes.
Pump is now locked.
Unlocking:
Push and hold the comfort control buttons
simultaneously.
Comfort control indicators ashes.
Pump is now unlocked.
2s 2s
08.AI.02EN_04 • 09/2022 • Page 3/4
Bolster ination and deation (Auralis Plus only)
Bolster deation:
Locate the valve symbol (A).
Turn the valve (B) on the bolster fully clockwise
Repeat on the other bolster, if required.
Leave to deate for 5 minutes.
Note: Deate bolsters before reducing the bed frame
width.
Bolster ination:
Locate the valve symbol (A).
Turn the valve (B) on the bolster fully anticlockwise
Repeat on the other bolster, if required.
Leave to inate for 8 minutes.
Note: Extended bed frame width before inating the
bolsters.
Risk of injury or discomfort
Deactivate transport mode
AA
BB
Bolster congurations:
• One bolster inated (left or right)
• Both bolsters inated (left and right)
• Both bolsters deated (left and right)
ArjoHuntleigh AB
Hans Michelsensgatan 10
211 20 Malmö, Sweden
www.arjo.com 08.AI.02EN_04 • 09/2022 • Page 4/4
