ARJO HUNTLEIGH AUTO LOGIC Manuel utilisateur

Seat cushion:

Place on chair surface.

Use the xing straps to attach.

Connect the tubeset.

Insert the mains power plug into

mains power socket.

Install seat cushion and pump

• cells facing up

• tubeset at front right corner

• cells horizontal across chair,

V-shape towards front

Front of chair

Back of chair

Quick start

2 31

• Pump and mattress or seat

cushion installed correctly.

• CPR control is clicked into closed

position.

• Pump self check:

Beep - 10 seconds - beep - ready

to use.

Press Run/Standby button.

Wait until fully inated:

Mattress overlay: 7 minutes

Mattress replacement: 15

minutes

Seat cushion: 3 minutes

WARNING

CPR control must be

visible and accessible at

all times.

Once the Wait indicator turns off,

place bed sheet on mattress and

place patient on the mattress or

seat cushion.

The default setting is Active

mode (alternating pressure).

Install mattress overlay or mattress replacement and pump

Mattress overlay:

Place on top of base mattress.

Use the 4 corner straps to secure.

Mattress replacement:

Place on bed base.

Use the 8 straps to attach to

moving parts of bed frame.

Zip the protective cover

over the mattress with

the Arjo logo at the foot

end.

Auto Logic

• tubeset at foot end

• CPR at head end

• cells facing up

CPR unit is clicked into

closed position.

“Click”

Position the pump on

a horizontal surface or

hang from bed foot rail.

Connect the tubeset.

Insert the mains power

plug into mains power

socket.

Run mains power cable

along side of mattress.

Secure the ap round

the cable using the press

studs.

630937EN_01 • 06/2020 • Page 1/2

QUICK REFERENCE GUIDE - USE

Auto Logic

Transport mode (mattresses only)

Activate:

Push the button down and pull the tubeset connector.

The mattress supports the patient for up to 12 hours.

Resume normal operation:

Reconnect the tubeset.

CPR control (mattresses only)

Activate: Press the two CPR release buttons

simultaneously.

Reset: Push the front of the CPR unit until it clicks

into place.

“Click”

Cleaning and disinfection

Clean and disinfect between patients and at regular

intervals while in use.

WARNING

Remove the electrical supply to the pump before

cleaning by disconnecting the mains power cord

from the mains power supply or removing the

battery pack.

Protective clothing should always be worn when

carrying out decontamination.

Cleaning

1. Clean all exposed surfaces and remove any debris by

wiping with a cloth moistened with a neutral detergent

and water.

2. Dry thoroughly. Do not allow water or cleaning

solutions to collect on the surface of the pump.

Chemical disinfection

Use a chlorine releasing agent, such as sodium

hypochlorite, at a strength of 1000 ppm available chlorine

(from 250 ppm to 10 000 ppm depending on local policy

and contamination status).

Alcohol based disinfectants (strength 70%) may be used

as an alternative.

If an alternative disinfectant is selected, conrm suitability

for use with the chemical supplier prior to use.

1. Wipe all cleaned surfaces with the solution.

2. Wipe with a cloth moistened in water.

3. Dry thoroughly.

Thermal disinfection

For laundering of the mattress top cover, see label.

Autorm mode

Activate: Press and hold

the button.

Comfort indicators ash

and then illuminates in

sequence.

Extend:

Comfort indicators

ash + series of tones:

Press either comfort key

to extend 5 minutes.

Maximum 30 minutes.

1 2

Deactivate: Press and

hold the button.

Pressure reached:

• Comfort indicators

illuminated

• Pump beeps 3 times.

• Reactive (CLP) indicator

illuminated

ArjoHuntleigh AB

Hans Michelsensgatan 10

211 20 Malmö, Sweden

www.arjo.com 630937EN_01 • 06/2020 • Page 2/2
