ARJO HUNTLEIGH Auralis Manuel utilisateur

15 min

Auralis

Assemble seat cushion and pump

Start the Auralis system

When the pump is connected to a

power source it runs a self check:

Beep - 10 seconds - 2 beeps - ready

to use.

Press and hold Run/Standby button.

The following indicators are shown:

• Run/Standby

• Wait indicator

• Alternating mode button

• Comfort control indicator

• Battery charge indicator

• Green indicators on the front of

the pump

Once the Wait indicator turns off,

place bed sheet on mattress. Make

sure that the CPR rapid deation

unit is clearly visible.

Place patient on the mattress or

seat cushion.

Alternating mode is set by default.

Assemble mattress overlay or mattress replacement and pump

CPR unit is clicked into

closed position.

“Click”

Connect the tubeset.

Zip the protective cover

over the mattress. Arjo

logo visible at the foot

end.

Auralis

Mattress overlay:

Place on top of base mattress.

Secure with 4 xing straps.

Mattress replacement:

Place on bed base.

Attach the 8 securing straps to

moving parts of bed frame.

• tubeset at foot end

• CPR at head end

• cells facing up

4 5 6

Hang the pump at the

foot end of the bed.

Place cable in the cable

management. Close the

ap around the cable with

the press studs.

Connect power cable to

power source.

“Click”

Seat cushion:

Place on chair surface.

Use the xing straps to attach.

Place pump on oor, cable under chair,

tubeset placed alongside chair.

Connect the tubeset.

Connect power cable to power source.

• cells facing up

• tubeset at front right corner

• cells horizontal across chair,

V-shape towards front

Front of chair

Back of chair

“Click”

08.AI.02EN_01 • 06/2020 • Page 1/2

QUICK REFERENCE GUIDE - USE

Auralis

Autorm mode

Activate: Press and hold

the button.

Comfort indicators ash

and mattress inates to

Autorm.

Extend:

Press button to extend 5

minutes. Max. 30 min.

If not extended, pump

goes back to previous

mode.

1 3

Deactivate: Press and

hold the button or select

another mode.

Pressure reached –

Autorm and Control

comfort indicators turn to

constant.

Transport mode (mattresses only)

Activate:

Press side buttons simultaneously and remove tubeset.

The mattress supports the patient for up to 12 hours.

Deactivate:

Reconnect the tubeset. The pump goes back to the

previous mode

CPR rapid deation unit

Activate: Press both CPR release

buttons simultaneously.

Reset: Press down the open part

until it clicks into closed position.

“Click”

Make sure the front part is open.

The air evacuates in 15 seconds.

“Click”

Alternating mode, default setting

Activate:

Press button, the Alternating mode indicator is shown.

Adjacent cells inate and deate on a 10 minute cycle.

Deactivate:

Select Reactive CLP or Autorm mode.

If no further therapy is required, remove patient from

the surface and turn off the pump.

Reactive CLP mode

Activate:

Press and hold the button.

Reactive CLP mode indicator is shown.

Deactivate:

Select Alternating mode or Autorm mode.

If no further therapy is required, remove patient from

the surface and turn off the pump.

ArjoHuntleigh AB

Hans Michelsensgatan 10

211 20 Malmö, Sweden

www.arjo.com 08.AI.02EN_01 • 06/2020 • Page 2/2
