Ariston AWD 121 NA Manuel utilisateur
Model type:
AWD121NA
Commercial code:
35356
mod.AWD121NA page 2
General notes
Technical Documentation guidelines
----------------------------------------------------------------------------------------------------------------------------------
-------------------------------------------------------------
You can find herewith some generic information to simplify cunsulting of technical documentation:
1. Models of same range share the same exploded views, which report the richest set of spare parts:generally, a model does not
necessarly have a related spare part for each particular shown on exploded views.
2. Some spare parts can not be represented directly on the exploded views (instruction booklets, specific kit, etc...). You can find
those codes in the spare parts list with the same reference of particular where spares are installed or with references 099, 999.
Instruction booklets, once managed, appear with 000 reference.
3. On the higher right site of each exploded view there is a serial number which indicates the beginning of the production of
certain range:some models might have more than an exploded view for a given category, each distinguished by a different serial
no.and linked to another spare parts list, In this case, serial no. is required to supply the right spare part code. Exploded view to be
considered is the one with a more recent serial no. but previous than the one of the model that needs assistance.
4.Exploded views might require further updates even after publishing. Addition of new spares will go on following the already
existing numeration references. Revision number of an exploded view is shown into last four digits of serial number into upper
right hand corner.
5.The spare parts list associated to an exploded view shows related codes of spares managed for a certain model; for each spare
part other informations are available:
REF: reference no of spare into a table; SUBSTITUTE: list of spare(s) which can replace a code but that keeps same functional
characteristics
INDUSTRIAL CODE: list of variables of a model (shown into model label) where such spare is used; NOTICE: code of
information(s) to refer to complete technical intervention, track for changes or to find correct spare part code.
6. Some notices, into a same section are generic therefore cannot be directly linked to a spare part. In order to assist a model in
the best way as possible, it is helpful to pay attention to all notices and constantly verify documentation updates
7.Technical documentation cover shows model name and its commercial codes
mod.AWD121NA page 3
1140110A Exploded views
mod.AWD121NA page 4
1140110A Spare parts
list
Ref. Code From To S/N Substitute Description Notice Industrial
000 C00116122 user instruct.bookl gb-es-f
001 C00090582 1 x C00116622 cabinet white n1040230 80353560000
n1040359
001 C00116622 cabinet white pw 80353560900
002 C00065186 1 x C00091882 pivot pin - drawer front 108.5x5
003 C00064784 bracket - timer support
004 C00099647 knob timer disc 'awd120na'
005 C00065180 1 x C00064506 wash timer knob white
006 C00064509 1 x C00117965 pushbutton white 0/i n1040359 80353560000
006 C00117965 pushbutton white pw 0/i 80353560900
007 C00099637 thermostat knob white awd120na n1040359 80353560000
007 C00099638 white dry timer knob awd120na 80353560000
007 C00116608 white knob thermostat pw 80353560900
007 C00116609 knob dryer white pw awd120na 80353560900
008 C00064507 pushbutton white n1040359 80353560000
008 C00116625 pushbutton white 0/i 80353560900
009 C00116105 control panel + handle awd121na 80353560000
009 C00116805 control panel + handle pw 80353560900
010 C00082825 1 x C00116624 door frame assy
011 C00065250 1 x C00116580 door handle kit n1040359 80353560000
011 C00116580 door handle kit pw lb2000 80353560900
012 C00110325 1 x C00116552 plinth white n1040359 80353560000
012 C00116552 plinth white pw 80353560900
013 C00087084 foot - m8 h = 2,3 cm
014 C00083828 spring for foot d =11 mm h = 8,5
015 C00065185 bolt m4,5 x 11
016 C00064541 hinge assy-outer case/door 180 n1040349 80353560000
016 C00115666 zama hinge 150° 80353560900
017 C00012687 self-tapping screw hi-lo 3,5x13
017 C00074149 bolt m4x9 tesrfr
019 C00064539 hinge plate door
022 C00065871 blanking plug
023 C00046666 collar for drain hose
023 C00099313 1 x C00116923 rear cover - white n1040359 80353560000
023 C00116923 rear cover - white pw 80353560900
mod.AWD121NA page 5
1140110A Spare parts
list
Ref. Code From To S/N Substitute Description Notice Industrial
024 C00084817 blanking plate-rear(test plug)
027 C00112436 1 x C00116618 top white + plate ariston n1040359 80353560000
027 C00116618 worktop - white pw aw121na 80353560900
028 C00046667 wiring stop
028 C00064550 drain hose holder
028 C00091904 cable clamp hose
029 C00099627 schakelaarplaat on-off 'awd120na'
030 C00090932 base cabinet plate usa normal ph
mod.AWD121NA page 6
1180240 Exploded views
mod.AWD121NA page 7
1180240 Spare parts list
Ref. Code From To S/N Substitute Description Notice Industrial
001 C00064786 1 x C00143260 bolt m8x23 torx tefl
002 C00013563 bearing 25 x52 x 15 6205-2z
003 C00064785 bolt m8x22 tb6lt
004 C00002591 bearing 20x47x14
005 C00096186 standard oil seal cv4 30 x 52/65 x n1040300
n1040326
006 C00080651 1 x C00032847 rear support
1 x C00114387
1 x C00114390
1 x C00145190
007 C00088408 bolt + washer
008 C00087811 upper counterweight 8,2 kg
010 C00080650 front support
011 C00080652 bolt m8x36 tefl. zig. p/p
012 C00064515 anchorage pad - suspension
013 C00080660 suspension spring - tank
014 C00080653 spacer
015 C00110429 door bellows seal wd 28-28 cm
016 C00064546 clamping ring - bellows seal front
017 C00064547 bellows clamp (tank front)
018 C00092178 front counterweight
019 C00092411 hose clamp
020 C00092174 hose tank to filter oko
021 C00092412 hose clamp
022 C00091148 1 x C00094908 clamp d=79 mm
023 C00065152 nut romob m6x22x1,5
024 C00047136 1 x C00144571 nut romob m8
025 C00093848 cradle outer- set
026 C00093885 shock absorber 120 n 8,15 mm
027 C00064789 wash paddles (extractable) 46 l
028 C00094281 1 x C00094275 outer- set 46 l. evo ii n1040300
1 x C00094280 n1040371
030 C00093750 bolt zink m8x40
031 C00092273 hose dispenser to tank
032 C00096077 bearing spider assembly n1040300
mod.AWD121NA page 8
1180240 Spare parts list
Ref. Code From To S/N Substitute Description Notice Industrial
033 C00074211 drum pulley d=210 mm h=20 mm
034 C00074218 belt l=1046 - 1051 mm h8 (hl)
099 C00001109 loctite 270 10 gr.
099 C00033026 ambljgon grease ta 100 gr.
mod.AWD121NA page 9
1180320A Exploded views
mod.AWD121NA page 10
1180320A Spare parts
list
Ref. Code From To S/N Substitute Description Notice Industrial
001 C00098928 supply cable 1,50 mt usa
003 C00019902 plastic -u- to make drain hose
004 C00091775 drain hose to sink
005 C00088394 push button switch na idc
005 C00090218 deviator switch (on-off)
007 C00086663 pilot light red 12 v rast 2.5
008 C00090195 programme select elbi 1665 rast
009 C00085195 1 x C00143096 potentiometer 8 pos. idc rast 2,5
010 C00064537 support - pressure switch
011 C00046152 additive container
013 C00046148 soap dispenser drawer (rotary)
014 C00092176 dispenser body
015 C00090200 pressure switch 1l 90-65
016 C00092412 hose clamp
017 C00092170 pipe pressostat l= 470mm. evo ii
018 C00098754 anti-vibration hose (foam) l= 330
021 C00092173 air trap x oko
023 C00090199 door interlock rold da rst 5usa idc
024 C00045027 filter element kit (hl)
025 C00112504 self cleaning pump 120v 60hz
026 C00074152 bolt m6x30
027 C00074151 rubber bush - motor mount
028 C00074153 spacer motor support l= 187 mm
030 C00040932 self locking nut m6
031 C00090196 motor ceset mcc61 usa 6kg
031 C00145001 1 x C00196554 brush motor ceset eame 6170
032 C00110422 hole for heating element
033 C00091054 coil to protect module 2002
034 C00116123 eeprom evoi awd121na sw
035 C00109898 module (less eeprom) wd usa mdl
036 C00066292 insulated tweezers
036 C00095669 hardware key mk1 n1040317
036 C00099862 serial cable lb2000 evoii - pc
037 C00046157 stopper detergent container
039 C00064534 seal - electrovale/dispenser
