Ariston SD 350 I (FE) Instructions de montage

UP RI GHT RE FRI GE RATOR

MODEL:SD 350 I (FE)

12

13

12

15

Caution:risk of fire

The refrigerant isobutene (R600a) is contained within the refrigerant circuit of the appliance, a

natural gas with a high level of environmental compatibility, which is nevertheless flammable.

During transportation and installation of the appliance,ensure that none of the components of

the refrigerant circuit becomes damaged.

The refrigerant (R600a) is flammable.

If the refrigerant circuit should become damaged:

Avoid open flames and sources of ignition.

Thoroughly ventilate the room in which the appliance is situated.

available from the manufacturer or its service agent in order to avoid a hazard.

—Please keep the appliance away from substance, which can cause

ignition.

WARNING Before obtaining access to terminals, all supply circuits must be

disconnected.

WARNING—Please remove all the doors before you dispose your refrigerator.

WARNING—The fridge is only applied with power supply of single phase alternating

current of 220~240V/50Hz. If fluctuation of voltage in the district of user is so large that

the voltage exceeds the above scope, for safety sake, be sure to apply A.C. Automatic

voltage regulator of more than 350W to the fridge. The fridge must employ a special

power socket instead of common one with other electric appliances. Its plug must

match the socket with ground wire.

—

Interior accessories

IMPORTANT! – in order to make the most of the volume of the fresh food storage compartment ,

the user can removed one ormore shelves, drawers, out of the appliance, according to your daily

use.

Defrosting

Why defrosting

Water contained in food or getting into air inside the fridge be opening doors may form a layer pf

frost inside. It will weaken the refrigeration when the frost is thick. While it is more than 10mm thick,

you should defrost.

Defrosting in fresh food storage compartment

It is automatically controlled by switching the temperature regulator on or off so that there is no

need of operation of defrosting. Water from defrosting will be drained into an drip tray through a

drain pipe at the back of the fridge automatically.

Storage shelves/wire tray

Various glass or plastic storage shelves or wire trays are included with your appliance different

models have different combinations .

You should always slide one of the full size glass storage shelves into the lowest set of guides,

above the fruit and vegetable containers, and keep it in this position.

The height of the storage shelves can be adjusted:

To do this, pull the storage shelf forward until it can be swiveled upwards or downwards and

removed.

Please do the same in reverse to insert the shelf at a different height.

Warning!

Switching off the appliance.

IMPORTANT!

-This application perform well from N to ST.You can find the climate classification on the

circuit-diagram-serial-plate located at the left-upper side of the appliance. The following table

shows this climateclassification and its matching ambient temperature:

top of the appliance and any overhanging furniture, and a gap of 100mm on either side of the

appliance.It is advisable for there to be 75mm separating the back of the fridge to the wall,and

a clear space upfront to allow the doors to open 160 .

。

6.Crisper drawer 7.Egg rack(inside) 8.Door rack 9.Door lower rack
