ARP 692 User Reference Manual
２
Specifications
Model No
ARP692
Construction
Rugged Aluminum Construction with shock absorbing rubber corners
Motherboard
Support Standard ATX M/B
Display
2x 21.5" LCD display, 1920x 1080
Slots
Offer 7 full-length expansion slots
Drive bay
3x 5.25”, 6x 3.5”drive bays
VGA
AD conversion board
2x DP output for 2 screens
KB/MS
Industrial multi-language keyboard/ touchpad
Power Supply
PS2, 750W, 100~240VAC, Auto switch
Speaker
Built-in amplified 2x 3W speaker
Dimension
536Wx 394.5Hx 297.5D mm
Weight
18 kgs
Carrying Case
Padded carrying case with wheels
Environmental Factors
Operating
Non-Operating
Temperature
0°C~50°C
-20°C~60°C
Relative Humidity
10%~90%
10%~95%
Approval
CE, FCC, RoHS
Options
Touch Screen
●
None
Touch Screen
３
ARP 692
Model
Accessory Kit SKD
Qty
ARP 692
1
ARP692 Portable Computer Chassis
1
2
Carrying Case with wheels
1
3
User’s Manual
1
4
Power Cord
1
5
Anti-Static Bag
1
6
Screw Pack (stabilizer)
1
7
Stabilizer Supports Pack
1
8
9
Standard Accessory Kits
Carrying Case with Wheels
４
ARP 692 features:
● Rugged Aluminum Construction with shock absorbing rubber corners
● Built-in 2x 21.5” LCD display support Full HD, 1920x 1080 resolution
● Support standard ATX Motherboard
● Offer 7-slot full-length expansion capability
● Creates a stretched desktop with a maximal resolution of 3840x 1080 (2x 1920x 1080)
● Open an application on each display or span one across 2-screens
● Experience surround gaming by expanding supported 3D games
●PS2 750W power supply, 100~240VAC
● Offer 3x 5.25”, 6x 3.5”drive bays
● Carrying case to manage portable PC with ease
The ARP692 is a dual LCD screen rugged portable computer which can be folded into a
neatly package for transportation. The system has two 21.5" widescreen LED LCD, each
with 1920x1080 resolution panel are available for a total 3840x1080 resolution. The
ARP692 is a combination of triple display highly mobile multi-slot computing system with
rugged aluminum chassis construction and corner bumper protection. It offers 7-slot
expansion slots and designed for ATX motherboard. Everything is integrated and folded
into a light weight portable package with the latest brightness contrast LED backlit LCD,
processors and foldable keyboard w/ touchpad.
1.0 Introduction
５
2.0 Getting Started
1. Push the 2 taps located on left of the outer LCD to release lock and open the first LCD
panel from the main unit by swinging the LCD fixture toward the right
3. Once the right LCD is opened. You will be able to view 2 LCD in full view.
4. Connect the power cable outlet into the power supply unit in the main chassis
2.0 Operation
Insert Power Cord
LCD 1
LCD 2
６
5. Turn on the power by pressing the power button located in the front of the main unit.
6. Front panel button control allows you to adjust the LCD via OSD. Each individual LCD has its
own set of OSD control. There have indicator LED lights for Power and HDD activity, 2x USB in
the front for USB KB/MS connecting.
7. Access the available expansion slots on the left side of the chassis, and support 3x 5.25”, 1x
slim, 6x 3.5” drive bays.
HDD/ POWER LED
Reset button
Drive bays
2x USB Port
Press Once to Power On
LCD OSD MANUAL
Power on/off
7 expansion slots
７
Be sure power cable is not connected to the system before proceeding
1. Open Back Cover
2. Remove the Card stabilizer bar
3.0 Internal Hardware Access
Unscrew
Unscrew
Unscrew
Unscrew
Unscrew
Unscrew
Unscrew
Unscrew
Unscrew
Unscrew
Unscrew
Unscrew
Unscrew
Unscrew
Unscrew
UnscrewUnscrew
UnscrewUnscrew
８
3. Remove the Power Supply
3.1 Remove the left side screws
3.2 Slide and move out the PSU slowly
UnscrewUnscrew
Unscrew
Unscrew
Slide & Move out
９
4. Remove the drive bay
4.1 Loosen the right-side drive bay cover screws, and remove the drive bay cover.
4.2 Loosen these drive bay screws.
Unscrew
UnscrewUnscrew
Unscrew
Unscrew
UnscrewUnscrew
UnscrewUnscrew
UnscrewUnscrew
１０
4.3 Slide and move out the drive bay slowly
5. Install the proper stand-off matching the ATX Motherboard into the
chassis and correct I/O plate supplied by board manufacturer and
secure it the motherboard onto chassis.
Slide & Move out
