Ariens Path-Pro Manuel

EN - 1

Path-Pro

Setup Instructions

IDENTIFICATION

1. Handlebar

2. Auger Control Bar

3. Auger Control Cable Assembly

4. Remote Discharge Chute Handle Assembly

(Model 938033)

5. Recoil Starter Handle

6. Discharge Chute Handle

(Models 938030, 031, 032, 034)

7. Discharge Chute Deflector Handle

8. Discharge Chute

9. Wing Knob

10. Auger Paddle

11. Oil Fill (Models 938030, 034)

12. Oil Fill (Models 938031, 032, 033)

13. Oil Drain Plug

14. Fuel Cap & Tank

15. Fuel & Oil Door

16. Pivot Bolt

17. Knob

18. Water Guard Ring

19. 1/4 x 1 1/4" Plastic Tapping Screw (3)

20. 16 oz 5W-30 Oil

Tools Required:

• 7/16" wrench or socket

• 3/8" wrench or socket

EN - 2

ASSEMBLY

Open box and remove all parts. Verify there is no

damage or missing parts.

Assemble handlebar.

a. Loosen knobs (# 17) on each side of handlebar

and rotate handlebar to operating position.

b. Insert lower end of pivot bolt (# 16) into

handlebar holes.

c. Ensure auger control cable is not pinched and

tighten knobs. Do not overtighen.

Attach remote discharge chute handle. (Model 938033)

a. Remove flange nuts and bracket from remote

chute handle assembly (# 4).

b. Position remote chute handle assembly on

handlebar.

c. Place bracket on handlebar and secure with

flange nuts. Do not overtighten.

d. Move remote chute handle completely forward

and rearward to ensure proper operation.

e. Place remote chute handle halfway between full

forward and full rearward.

Attach discharge chute.

a. Place water guard ring (# 18) on discharge

chute.

b. Position discharge chute (# 8) onto ring.

c. Position chute handle (# 6) on top of discharge

chute. (Models 938030, 031, 032, 034)

d. Ensure holes in all pieces align and secure with

three screws (# 19). Do not overtighten.

e. Move remote chute handle (model 938033) or

chute handle (models 938030, 031, 032, 034) to

ensure proper operation of discharge chute.

WARNING: AVOID INJURY. Read and

understand the entire Safety section in the

Owner’s Manual before proceeding.

DO NOT start engine until all assembly steps

have been completed.

Bracket

Flange Nuts

Auger Control Bar

Remote

Chute

Handle

EN - 3

Engage auger control bar (# 2) to ensure proper

operation. There should be no excessive tension on

cable. When auger control bar is disengaged, there

should be slight slack in cable and no tension.

See Owner’s Manual if adjustment is necessary.

Add oil. (Models 938031, 032, 033)

a. Open fuel and oil door (# 15) to access oil fill

(# 12).

b. Remove cap and add 16 oz. 5W-30 oil (# 20).

Check oil level on dipstick to ensure proper

operating level. See Owner’s Manual for

instructions.

c. Replace cap and close door.

Add oil. (Models 938030, 034)

a. Remove cap from oil fill (# 11) and add 16 oz.

5W-30 oil (# 20). Check oil level on dipstick to

ensure proper operating level. See Owner’s

Manual for instructions.

b. Replace cap.

Models 938030, 031, 032, 034

WARNING: AVOID INJURY. DO NOT

proceed until operation and safety rules

are fully understood.

Read and understand entire Owner’s

Manual before proceeding.
