Page 1 of 8

Date: February 26, 2014 No. C-2014R

Replaces C-2014

Ariens Company has identified a potential safety concern on models and serials listed in the table below.

The auger drive pulley, #00268951, may develop a crack which could affect the brake's ability to stop the

auger/impeller, resulting in an unsafe condition.

Dealers are instructed to Stop Sale Immediately of any unsold inventory which falls into the model and

serial ranges listed. Additionally, dealers are asked to contact consumers who purchased affected

machines from your dealership to coordinate repair of those machines as soon as possible. Ariens

Company is sending a letter to registered owners of all affected machines alerting them to this situation.

Ariens Company has been reworking product since this issue was identified, and all machines which have

been reworked by Ariens Company will have a black check mark on the carton label as well as the model/

serial label on the machine.

Dealers are asked to order kit #52001800 and install it on each affected unit. The kit consists of a

replacement pulley and hub assembly. Dealers should file a warranty claim for each pulley replacement

using a flat rate code of 20999. Please make sure that the machine is within the model/serial numbers

listed below. Warranty claims will be reimbursed for 0.50 at the dealer's standard shop labor rate.

Please direct any questions to Ariens Technical Service at:

(888) 927 – 4367

Ariens Company

655 W. Ryan St.

Brillion, WI 54110

www.ariens.com

Service Campaign

Product Family: Ariens Compact Sno-Thro, Ariens Compact Track Sno-Thro, Sno-Tek,

Ariens PB-28, Gravely PB- 28

Subject: Important Product Safety Recall

Dealer Action: STOP SALE – Repair Immediately

Page 2 of 8

Date: February 26, 2014 No. C-2014R

Replaces C-2014

ATTACHMENT DRIVE BELT PULLEY REPLACEMENT – SNO-THRO & SNO-TEK

MODELS

Models 920013, 920014, 920021, 920022, 920402, 920403, 939401

Remove Attachment Drive Belt

(Figures 1, 2 and 3)

1. Shut off engine, remove key, disconnect spark plug wire and allow unit to cool completely.

2. Loosen the hardware securing belt cover to unit.

NOTE: DO NOT completely remove the hardware from unit.

3. Remove belt cover.

4. Remove gear cover from top of chute pedestal.

5. Remove spring clip pin from chute crank and separate.

6. Remove remote deflector control cable from control lever if equipped).

7. Remove belt finger by removing cap screws mounting belt finger to engine (Figure 2).

8. Remove attachment drive belt from engine sheave (it may be necessary to turn engine sheave using

recoil starter handle).

Model Description Serial Number Range

920013 AriensST22LECompact

Sno-Thro 124912 – 124935, 124937 – 125008, 125037 – 125060,

125094 – 125271

920014 AriensST24LECompact

Sno-Thro 142966 – 142999, 143264 – 143272, 143274 – 143281,

143284 – 143287, 143289, 143291 – 143304, 143306 – 143309,

143313 – 143432, 143434 – 143435, 143439 – 143445, 143448,

143450 – 143462, 143466 – 143467, 143469 – 143496, 143500,

143502 – 143506, 143511, 143513 – 143518, 143520 – 143535,

143700 – 143728

920021 AriensST22LECompact

Sno-Thro 3089 – 3100, 3510 – 3940, 3942 – 4360, 4363, 4365 – 4372,

4374 – 4377, 4382 – 4384, 4386, 4389 – 4398, 4400, 4404 – 4405,

4409, 4411 – 4415, 4418 – 4593, 4595 – 4617, 4619 – 4621, 4623 –

5815, 5817, 5819 – 5847, 5849 – 5883, 5885 – 5886, 5893 – 5895,

5899, 6000 – 6151, 6153 – 6172

920022 Ariens ST24LET

Compact Track Sno –

Thro

531 – 576, 701 – 712

920402 Sno-Tek 24E 143967 – 145036, 145062, 145095, 145097, 145500 – 145591,

145593 – 145594, 145596, 145598 – 145699, 146057

920403 Sno-Tek 28E 126501 – 127141, 127143 – 127145, 127185, 127197 – 127237,

127241 – 127291, 127293 – 127326, 127328 – 127338,

127340 – 127341

921025 AriensPB-28All-Season

Brush 40600 – 40660

921026 Gravely PB-28 All-

Season Brush 40061 – 40079

921313 Ariens 28” Brush – CE 40163 – 40174

939401 Sno-Tek 20E 90112, 90140 – 90619, 90621 – 90623

Page 3 of 8

Date: February 26, 2014 No. C-2014R

Replaces C-2014

IMPORTANT: To avoid bending bottom cover when tipping unit apart, support handlebars firmly or tip unit

up on housing and remove bottom cover by removing six cap screws before separating unit.

9. Support Sno-Thro frame and housing.

10. Remove hex bolts securing housing to frame (two on each side). Tip housing and frame apart on

pivot pin.

11. Separate housing from unit.

12. Remove attachment drive belt from attachment pulley.

13. Remove attachment pulley and discard. DO NOT reuse pulley.

14. Replace attachment pulley with kit #52001800. Torque to 120 lbs-in.

Replace Attachment Drive Belt

1. Place new belt onto attachment pulley (Figure 2).

NOTE: Engage attachment clutch lever while connecting housing to frame to hold brake out of the way.

2. Tip housing and frame back together and secure with hex bolts.

3. Place belt onto engine sheave.

4. Replace belt finger.

IMPORTANT: With the attachment clutch lever engaged, the belt finger located opposite the belt idler must

be less than 1/8" (3.2 mm) from the belt, but not touching the belt, or belt grabbing may occur causing

impeller to rotate while the attachment clutch is disengaged (Figure 3).

5. Adjust clutch (see Attachment Clutch/Brake Adjustment on page 5).

CAUTION: Always support Sno-Thro frame and housing when loosening the cap screws

holding them together. Never loosen cap screws while unit is in service position.

WARNING: AVOID INJURY. Auger must stop within 5 seconds when attachment lever

is released or serious injury or unit damage may result.

Figure 1

1. Pinion Gear

2. Belt Cover

3. Spring Clip Pin

4. Chute Crank

5. Gear Cover

6. Chute Pedestal

Page 4 of 8

Date: February 26, 2014 No. C-2014R

Replaces C-2014

6. Replace chute crank and secure with spring clip pin.

• If Equipped: Reconnect remote deflector cable to control lever.

7. Replace gear cover on top of chute pedestal.

8. Run in the attachment belt(see Run-in Attachment Belt on page 4).

9. Replace belt cover and tighten hardware.

RUN-IN ATTACHMENT BELT

1. Start unit in a well-ventilated area.

2. Engage attachment clutch lever and run attachment for about 15 minutes.

3. Stop unit, wait for all moving parts to stop, and remove spark plug wire.

4. Adjust clutch idler (see Attachment Clutch/Brake Adjustment on page 5).

Figure 2

1. Traction Belt Idler

2. Traction Drive Belt

3. Engine Sheave

4. Belt Finger

5. Attachment Drive Belt

6. Attachment Pulley

7. Attachment Idler Nut

8. Attachment Belt Idler

Figure 3

1.Belt Finger

2.Attachment Drive Belt

3.Swing Gate Pivot Bushing

1/8" (3.2 mm)

(Maximum)

Page 5 of 8

Date: February 26, 2014 No. C-2014R

Replaces C-2014

ATTACHMENT CLUTCH/BRAKE ADJUSTMENT

Remove Attachment Cable Slack

(Figures 4 and 5)

1. Shut off engine, remove key, disconnect spark plug wire and allow unit to cool completely.

2. Loosen hardware securing belt cover to unit.

3. DO NOT completely remove the hardware from unit.

4. Remove belt cover.

5. Loosen jam nut on cable adjustment barrel, and then turn the adjustment barrel down to shorten

cable and remove all cable slack (Figure 4).

6. With the attachment clutch disengaged, check that the attachment idler arm lightly touches the frame

(Figure 5).

7. Tighten jam nut on cable adjustment barrel.

WARNING: IMPROPER ADJUSTMENT could result in unexpected movement of auger and

impeller causing death or serious injury. AUGER / IMPELLER MUST STOP within 5 seconds

when Attachment Clutch Lever is released.

WARNING: Adjustment procedure requires the engine to be run with the belt cover off.

AVOID INJURY. Read and understand the entire Safety section before proceeding.

Figure 4

1.Attachment Clutch Cable

2.Cable Adjustment Barrel

3.Jam Nut

Page 6 of 8

Date: February 26, 2014 No. C-2014R

Replaces C-2014

8. Draw a check mark on the model/serial number label with an indelible black marking pen to signify

that the repair has been completed (Figure 6).

Figure 5

With the attachment clutch

disengaged, check the

attachment idler arm position

here. The attachment idler arm

should lightly touch the frame.

Draw check mark on model/

serial number label.

Figure 6

Page 7 of 8

Date: February 26, 2014 No. C-2014R

Replaces C-2014

ATTACHMENT DRIVE BELT PULLEY REPLACEMENT – POWER BRUSHES

Models 921025, 921026, 921313

Remove Attachment Drive Belt

(Figures 7 and 8)

1. Shut off engine, disconnect spark plug wire and allow unit to cool completely.

2. Remove the hardware attaching the remote trigger cable to the brush assembly.

3. Remove two screws securing belt cover to unit and remove belt cover.

4. Remove belt finger by removing cap screws mounting belt finger to engine (Figure 8).

5. Remove attachment drive belt from engine sheave (it may be necessary to turn engine sheave using

recoil starter handle).

IMPORTANT: To avoid bending bottom cover, when tipping unit apart, support handlebars firmly and

remove bottom cover by removing six cap screws before separating unit.

6. Support frame and brush assembly.

7. Remove cap screws holding brush assembly to frame (two on each side).

8. Separate assembly from unit. Lower handlebar on floor.

9. Remove attachment drive belt from lower pulley (hold brake away from belt).

10. Remove attachment pulley and discard. DO NOT reuse pulley.

11. Replace attachment pulley with kit #52001800. Torque to 120 lbs-in.

Replace Attachment Drive Belt

(Figures 8 and 9)

1. Place new belt onto lower pulley and while holding brake out of way, tip unit together.

2. Secure brush to frame with cap screws.

3. Place belt onto engine sheave.

4. Replace belt finger.

WARNING: Always support Sno-Brush frame and brush assembly when

loosening the cap screws holding them together.

-A--A-

Figure 7

1.Brush Assembly

2.Cable Attaching Hardware

3.Remote Trigger Cable

4.Bottom Cover

5.Assembly Bolt Holes

Page 8 of 8

Date: February 26, 2014 No. C-2014R

Replaces C-2014

IMPORTANT: With the clutch lever engaged, the belt finger located opposite the belt idler must be less

than 1/8 in. (3.2 mm) from the belt, but not touching the belt, or belt grabbing may occur causing brush to

rotate while the attachment clutch is disengaged (Figure 9).

5. Adjust clutch (see Attachment Clutch/Brake Adjustment on page 5).

6. Replace belt cover and secure with cap screws.

7. Replace bottom cover and secure with cap screws.

8. Reinstall remote trigger cable to brush assembly.

9. Run in the attachment belt (see Run-in Attachment Belt on page 4).

10. Replace the belt cover.

11. Draw a check mark on the model/serial number label with an indelible black marking pen to signify

that the repair has been completed. See Figure 6.

Figure 8

1.Traction Belt Idler

2.Traction Drive Belt

3.Engine Sheave

4.Belt Finger

5.Attachment Drive Belt

6.Attachment Pulley

7.Attachment Idler Nut

8.Attachment Belt Idler

Figure 9

1.Belt Finger

2.Belt

1/8in.(3.18mm)

(Maximum)

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Ariens Souffleuse à neige

Ariens

Ariens 920402 - Sno-Tek 24E Manuel du propriétaire

Ariens

Ariens 916302 amp 24 sno-thro Manuel utilisateur

Ariens

Ariens 921017 Manuel du propriétaire

Ariens

Ariens SNO-THRO 932510 - ST5520 Manuel du propriétaire

Ariens

Ariens Sno-Thro Deluxe 24 Manuel utilisateur

Ariens

Ariens Sno-Thro Pro 28 926038 Manuel utilisateur

Ariens

Ariens 924505 - 1332 Manuel du propriétaire

Ariens

Ariens Sno-Thro 932001 Manuel utilisateur

Ariens

Ariens Sno-Thro Deluxe 30 EFI Manuel utilisateur

Ariens

Ariens SNO-THRO 932037 - 724 Manuel du propriétaire

Ariens

Ariens Hydro Pro 28 Manuel du propriétaire

Ariens

Ariens Sno-Thro 921010-ST27LE Manuel du propriétaire

Ariens

Ariens Promaster 252 Manuel du propriétaire

Ariens

Ariens SNO-THRO Manuel utilisateur

Ariens

Ariens Sno-Thro 932100-824 Manuel du propriétaire

Ariens

Ariens 924 Manuel du propriétaire

Ariens

Ariens 924 Manuel utilisateur

Ariens

Ariens 924124-ST926DLE, 924125-ST1152 Manuel du propriétaire

Ariens

Ariens SNO-THRO CAB KIT Manuel utilisateur

Ariens

Ariens Professional 21 938024-SSR Manuel utilisateur

Ariens

Ariens SNO-THRO 924337 ST11528DLE Manuel du propriétaire

Ariens

Ariens ST T8 Manuel utilisateur

Ariens

Ariens Sno-Thro 920001 Manuel du propriétaire

Ariens

Ariens SNO-THRO 924318-ST824 Manuel du propriétaire

Manuels Souffleuse à neige populaires d'autres marques

Murray

Murray 624504X4A Manuel utilisateur

Blizzard

Blizzard POWER PLOW 8100PP Manuel utilisateur

Craftsman

Craftsman 486.24837 Manuel utilisateur

Yard-Man

Yard-Man E2B5 Manuel utilisateur

ST ST 526 A Manuel utilisateur

MTD

MTD 3AA Manuel utilisateur

Toro

Toro Power TRX 1428 OHXE Manuel utilisateur

Ryobi

Ryobi RYAC800 Manuel utilisateur

Poulan Pro

Poulan Pro 416829 Manuel utilisateur

Poulan Pro

Poulan Pro 437986 Manuel utilisateur

MTD

MTD 319-180-00 Manuel utilisateur

Brute

Brute 1695565 Manuel utilisateur

Egholm

Egholm City Ranger 2250 Manuel utilisateur

Poulan Pro

Poulan Pro 420915 Manuel utilisateur

GreenWorks

GreenWorks SNF402 Manuel utilisateur

LOFTNESS

LOFTNESS 601D1 Manuel utilisateur

LOFTNESS

LOFTNESS 1082I Manuel utilisateur

LOFTNESS

LOFTNESS 481EL Manuel utilisateur
