Argos Devon 532/7623 Manuel utilisateur

Width-45.5cm

Depth -30cm

Height -42.7cm

Issue1-15/03/16

Important - Please read these instructions fullybefore starting assembly

Dimensions

Ifyouneedhelporhavedamagedormissingparts,call the CustomerHelpline:03456400800.

Forfurtherassistancepleasevisit http://www.argos-support.co.uk/.

Assembly Instructions - Please keep for future reference

Devon End Table

532/7623

Checkyouhaveall the

componentsand toolslisted on

pages 2and3.

Removeall fittingsfromthe

plasticbagsand separatethem

intotheir groups.

Keepchildrenandanimals

awayfrom the workarea,small

partscouldchokeifswallowed.

Makesureyouhaveenough

spacetolayoutthepartsbefore

starting.

Donot standorput weighton

theproduct,thiscouldcause

damage.

Assembletheitem ascloseto

itsfinalposition(inthe same

room)aspossible.

Assembleonasoftlevel

surfacetoavoiddamagingthe

unitoryourfloor.

Partsoftheassemblywillbe

easierwith2people.

SafetyandCareAdvice

Important -Pleaseread theseinstructionsfully before starting assembly

Fromtimetotimecheckthat

therearenoloosescrewson

thisunit.

Thisproductshouldnotbe

discardedwithhouseholdwaste.

Taketoyourlocalauthority

wastedisposalcentre.

Onlycleanusingadampcloth

andmilddetergent,donouse

bleachorabrasivecleaners.

Careandmaintenance

Assembleall partsand bolts

looselyduring assembly, only

oncethe product iscomplete

shouldyou fullytighten the bolts

HandyHints

Regularlycheck and ensure

that all boltsand fittingsare

tightend properly.

Toreduce

the likelihood of

damaging your

product please

ensurethat your

power drill isset on alow torgue

setting.

Top panel1 (45.5 30cm)

Components-Panels

Pleasecheckyouhaveallthepanelslistedbelow

Sideframe 2 (40.9 28cm)

Rail 2 (38.7 4.5cm)

Bottom panel 1 (42.5 27cm)

If youhavedamaged ormissing componets,call the

Customer Helpline:03456 400800.For further

assistance please visit http://www.argos-support.co.uk/

Components-Fittings

0101520253035404550556065707580859095100 110115120125130135140145150155160165170

105

Note: The quantitiesbelow arethecorrectamounttocompletetheassembly. Insomecasesmorefittings

may be supplied thanarerequired.

Phillipsscrewdriver

(medium &large)

Flatbladescrewdriver

(medium)

Pleasecheckyouhaveallthefittingslistedbelow

Ruler -Usethisrulertohelpcorrectlyidentifythescrews

Toolsrequired

Rubber

mallet

Ø8 30mmWooden dowel 4

Locking pin 4

DØ3.5 45mm

Screw 12

Locking nut 4

Step1

Step2

AssemblyInstructions

a. Insert2 Locking pin

to Side frame .

b. Insert2 Wooden dowel

to Side frame .

Repeat Step a& b forthe

otherSide frame.

a. Attach Rails and

Bottompanelto the

Side frames .

b. Insert Locking nut

to the Bottompaneland

use screwdriver turn

Locking nutclock

wise to lock as showon

picture.

Step3

Step4

AssemblyInstructions

Fix the unitto Top panel

by 8 Screwas

showon picture.

Assembly is completed.

Fixing railsto Side

frameby 4 Screw

as showon picture.Use

screw driverturn Screw

clock wise to fix.

Dx4

Dx8
