Argos Cube Coffee Table Manuel utilisateur

Simple Assembly Instructions - Please keep for future reference

IMPORTANT

1. Read these instructions carefully and

familiarise yourself with the procedure

before assembling the unit.

2. Check that you have all the component

parts following the list on the back

cover and familiarise yourself with

each part before proceeding.

3. Take all the fittings out of the plastic bag

and separate them into their groups.

4. Ensure you have enough space to lay out

all the parts before assembly.

Cube Coffee Table

Components

5. To avoid scratching it is recommended

that you assemble the unit on a soft

level surface.

Fittings

3-07

B26 x Dowel

1 x Table Top

1 x Bottom Panel

2 x Side Panel

2 x Base Side Panel

2 x Base Panel

D4 x Locking Nut

C4 x Locking Pin

1 x Glue

A4 x Screw

Assembly Instructions Assembly Instructions

Stage 2 – Fitting the Side PanelsStage 1 – Fitting the Base

CAUTION: Always check

the assembly method is correct

before applying Glue.

2. Place a small amount of Glue E

into the dowel holes and onto

the joints' surfaces. Fix the Base

Panels C onto the Base Side

Panels E.

See fig. 2.

NOTE: It would be useful to ask

someone to help you at this

stage.

3. Place a small amount of Glue E

into the dowel holes and onto

the joints' surfaces. Use Dowels

Bto fix the Bottom Panel B onto

the unit.

See fig. 3.

CAUTION: Always check

the assembly method is correct

before applying Glue.

NOTE: It would be useful to ask

someone to help you at this

stage.

2. Place a small amount of Glue E

into the dowel holes and onto

the joints' surfaces. Fix the Side

Panels D onto the unit.

See fig. 5.

NOTE: Ensure the screw holes on

the Side Panels are facing

inwards.

3. Use Screws Ato fix the Side

Panels B onto the unit.

See fig. 6.

1. Place a small amount of Glue E

into the dowel holes. Insert

Dowels B into the Base Side

Panels E.

See fig. 1.

1. Place a small amount of Glue E

into the dowel holes. Insert Dowels

Binto the Side Panels D.

See fig. 4.

NOTE: Ensure the top fixing holes

are aligned and face upwards

on the side panels before

assembly.

fig. 3

fig. 2

fig. 6

fig. 4

fig. 1

fig. 5

Assembly Instructions Assembly Instructions

Stage 4 – Finishing the UnitStage 3 – Fitting the Table Top

2. Carefully place the unit in the

desired location.

See fig. 10.

fig. 10

Care and Maintenance

Safety

To avoid any risk of suffocation to animals or children dispose of the plastic

bags immediately.

Fitting

From time to time please ensure there are no loose screws on the product.

Cleaning

As with all surfaces clean with a damp cloth and mild detergent, do not use bleach

or abrasive products.

NOTE: It would be useful to ask

someone to help you at this

stage.

NOTE: It would be useful to ask

someone to help you at this

stage.

CAUTION: Always check

the assembly method is correct

before applying Glue.

1. Screw in Locking Pins C into the

Table Top A.

See fig. 7.

2. Place a small amount of Glue E

into the dowel holes and onto the

joints' surfaces. Carefully locate

the Table Top A onto the unit.

See fig. 8.

1. Use Locking Nuts Dto fix the

Table Top A onto the unit.

See fig. 9.

NOTE: Before use make sure the

unit is secure. Allow Glue to

dry for 24 hours or be

completely dry before use.

fig. 7 A

fig. 8

fig. 9
