Assembly Instructions - Please keep for future reference
Important - Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline:
Argos = 0345 640 0800
Issue 1 - 21/04/15
Dimensions
Width - 40cm
Depth - 49.5cm
Height - 89cm
426/9610
404/4952
Chicago Dining Set - Chair
Care and maintenance
Handy Hints
• Only clean using a damp cloth
and mild detergent, do no use
bleach or abrasive cleaners.
• From time to time check that
there are no loose screws on
this unit.
• Do not stand on the chair.
• Do not use this chair as step
ladder.
• This product should not be
discarded with household
waste. Take to your local
authority waste disposal centre.
• Assemble all parts and bolts
loosely during assembly, only
once the product is complete
should you fully tighten the
bolts.
• Regularly check and ensure
that all bolts and fittings are
tightend properly.
• Check you have all the
components and tools listed on
the following pages.
• Remove all fittings from the
plastic bags and separate them
into their groups.
• Keep children and animals
away from the work area, small
parts could choke if swallowed.
• Make sure you have enough
space to layout the parts before
starting.
• During assembly do not stand
or put weight on the product, this
could cause damage.
• Assemble the item as close to
its final position (in the same
room) as possible.
• Assemble on a soft level
surface to avoid damaging the
unit or your floor.
• Parts of the assembly will be
easier with 2 people.
• We do not
recommend the
use of power
drill/drivers for
inserting screws,
as this could damage the unit.
Only use hand screwdrivers.
• Unit weight: 5.2 kgs.
• Maximum safe weight of user:
110kgs.
1
Safety and Care Advice
Important - Please read these instructions fully before starting assembly
2
Components - Parts
Please check you have all the parts listed below
If you have damaged or missing components, call the
Customer Helpline: Argos = 0345 640 0800
Seat
(2 x 39.5 x 40cm)
3Front Leg
(4.5 x 37 x 42cm)
2
Side Rail x 2
(2 x 6 x 33cm)
4Stretcher x 2
(1.2 x 2.2 x 36cm)
5Backrest
(8 x 40 x 89cm)
1
Components - Fittings
Please check you have all the fittings listed below
Note: The quantities below are the correct amount to complete the assembly of 1 chair. In some cases more
fittings may be supplied than are required.
A
Wooden dowel x 6
B
Spring washer x 6
C
M6 x 50mm Bolt x 6
D
M4 x 32mm Screw x 7
E
Allen key x 1
Tools required
Crosshead screwdriver
Ruler - Use this ruler to help correctly identify the screws
0 5 10 15 20 25 30 35 40 45 50 55 60 65 70 75 80 85 90 95 100 110 115 120 125 130 135 140 145 150 155 160 165 170
105
Note: The quantities below are the correct amount to complete the assembly of 1 chair.
3
Assembly Instructions
C
C
C
C
C
C
C
C
4
4
4
4
4
4
2
2
A
A
B
B
A
B
Attaching stretchers
Place the backrest on
a flat protected surface.
Position the stretcher
as shown and insert into
the hole on the backrest.
Step 1
Step 2
Step 3
Fitting dowels
Insert wooden dowels
into holes on the side
rails as shown.
C
4
Attaching side rails
Place the front leg on
a flat protected surface.
Position the siderails
as shown and insert the
wood dowels into holes
on the front leg. Then fix
using bolts and spring
washers .
Important note:
Ensure to connect
the front edge of
the side rail which
is marked with a
hole as shown on
the inset diagram.
Fasten bolts
using allen key
but do not fully
tighten at this
stage. Use oval
head of allen key
when tigthening
bolts on corner
positions.
A
E
B
1
2
4
5
1
1
5
5
5
Assembly Instructions
1
1
1
1
4
4
4
4
4
4
5
52
5
2
A
B
A
B
A
B
A
B
A
B
A
B
Attaching backrest
Then align and insert the
stretchers into holes
on the front leg .
Position the siderails
as shown and insert the
wood dowel into center
holes on backrest .
Step 4
2
4
1
5
Step 5
Securing backrest
Fix the backrest to
siderail using bolts
and spring washers .
Note:
Fasten bolts
using allen key
but do not fully
tighten at this
stage.
Use oval head of
allen key when
tigthening bolts
on corner
positions.
1
A
B
4
E
4
Assembly Instructions
E
2
4
4
4
3
3
D
D
D
D
Attaching seat
Carefully place the seat
face down on a
raised protected surface.
Position the chair on the
centre of the seat and fix
through holes on side
rails and front leg
using screws .
Tighten screws using a
crosshead screwdriver.
D
3
4 2
Step 7
Aligning the legs
Carefully turn the chair
upright and place on a
flat surface.
Make adjustments to
ensure the chair frame is
straight and the legs are
even on the floor then
fully tighten all bolts
assembled in previous
steps using allen key .
E
Step 6
5
6
Assembly Instructions
If you need help or have damaged or missing parts, call the Customer Helpline:
Argos = 0345 640 0800
Assembly is complete.
Carefully turn over the
unit after assembly.
D
1 5
D
D
D
D
1
5
5
2
Step 8
Securing the stretchers
Secure the stretchers
to the backrest and
front leg using scews
. .
Tighten screws using
crosshead screwdriver.
2
1
D
5
