Argos Adele 257/6549 Manuel utilisateur

Adele 4ft6 Bed

257/6549

AssemblyInstructions - Please keepfor future reference

If youneed help or havedamaged or missingparts,call the CustomerHelpline: 08456400800

Important –Pleasereadthese instructions fullybefore starting assembly

Issue 1 -13/05/14

Dimensions

Width - 148cm

Depth-204,5cm

Height - 112cm

244/8378

Safety andCare Advice

Important – Please read these instructions fullybeforestarting assembly

Note: if required the next page

can be cutout and used as

reference throughout the

assembly. Keep this page with

these instructions forfuture

reference.

.Checkyou have all the

componentsand tools listed on

pages2 and 3.

Remove allfittings fromthe

plastic bagsand separate them

into their groups.

Keep children and animals

awayfrom the work area, small

parts could choke if swallowed.

Makesure you have enough

space to layout the parts before

starting.

Do not stand or put weight on

the product, thiscould cause

damage.

We do not

recommend the

use of power

drill/drivers for

inserting screws,

asthiscould damagethe unit.

Onlyuse hand screwdrivers.

Parts ofthe assembly willbe

easier with 2 people.

Dispose of allpackaging

carefullyand responsibly.

care and maintenance

.Use an appropriate furniture

polish for natural wood

furniture anda drycloth to

clean the product.

.Avoid placing the furniture in

direct sunlight as thiswillcause

the timber to prematurely age.

.From time to time check

that there are no loose

screws on thisunit.

.This product should not be

discardedwith household

waste. Take to yourlocal

authority waste disposal

centre.

Assemble on asoft level

surface to avoid damagingthe

unit oryour floor.

.This product hasbeen produced

from naturaltimber; you may

notice some variation in thegrain

and colour of different component

parts whichisnormal for furniture

produced using natural wood and

isnot the result of any

manufacturing fault.

Assemble the item asclose

to its final position (in the same

room) as possible.

Components -Panels

Pleasecheck you have all thepanels listed below

01 Headboard (148x 112cm)

02 Foot (45 x 6.5cm)

03 Side rails x 2 (190 x 11.5cm)

05 Support Foot (29.5 x 6cm)

04 CentralSupport (194x 6cm)

06 Footboard Rail (132.5 x 11.5cm)

Components - Fittings

Please check you have all the fittings listed below

If you have damaged or missingcomponents,

callthe CustomerHelpline: 08456 400 800

Note: The quantitiesbelow are the correct amount to complete the assembly. In some cases more

fittings maybe supplied than are required.

Ruler -Use thisrulerto help correctly identifythe screws

0510 15 20 25 30 35 40 45 50 55 60 65 70 75 80 85 90 95 100105110115120125130135140145150155160165170

Tools required

Phillips screwdriver

(medium & large)

Eye protection

(when using a

hammer orglue)

Small

hammer

Ruler/tape

measure

16mm Screw x08

40mm Wooden dowel x06

100mm Bolt x 08

Half-Moon Nut x 08

35mm Screw x12

50mm Bolt x 02

80mm LShaped Bracket x 02

40mm Bolt x 02

Nut x 02 100mm Bolt x 04

Allen key

Step 1

Fittingdowels

Insertdowels

intothe indicatedparts.

Assembly Instructions

Step2

Step3

Assembly Instructions

Fixing footboard:

Fix footboardrailinto

foot and foot using

boltsandallenkey as

shown.

2A 2B

Assembling siderails:

Attach side railsto the

headboard. Insert half

moon nut into

side railsasshown.

Then fix themtothe

headboard usingbolts

andallen key.

Caution:

Assemblingof

Step3and Step4

willbeeasierwith 2

people.It can alsoavoid

damages or brakesof any

partorcomponent.

Assembly Instructions

Step4

Step5

Assembling side rails:

Inserthalf moonnut into

side railsas shown.

Then fix them tothe

footboard using bolts

and allen key.

03 B

Fixing support foot:

Fix support foot to

centralsupport using

bolt and allenkey as

shown.

Step6

AssemblyInstructions

FixingLshapedbracket:

FixLshaped brackets

into pre-drilled holesinthe

headboard and

footboardusingscrew

asshown.

Step7

Fixingcentral support:

Fix central support

toLshapedbrackets in

headboard and

footboardusing bolts

andnutasshown.

Step 8

AssemblyInstructions

Assemble is complete!

Fixing slats:

Centralizeslatsin bed

frameprior to fixing.Fix

slats using screwsas

shown.

Fix slatsinonesidefirst,

thenfixthem in theother

sidebypushingtherail

againsttheslats if

necessary.

Periodically check that all

screwsaretight.

Step 9

Additional steptofixing

slats:

Warning!Thescrewsthat

attach theslatholdersto

the sidesnevercollideto

the screwsthatfixtheslats

to theslatholders.

Warning!
