Argon audio 6344C Manuel utilisateur

w w w . a r g o n a u d i o . c o m 1

6344C

02 OWNER’S MANUAL

03 ILLUSTRATIONS

04 SPECIFICATIONS

w w w . a r g o n a u d i o . c o m 2

6344C

Owner ’s manual

Introduction

Thank you for choosing Argon Audio loudspeakers, we hope

It will bring you many years of enjoyment.

Please read this manual fully before unpacking and installing

the product.

Carton contents

We have during production and packing carefully checked and

inspected this loudspeaker.

After unpacking please check for any damage from transport.

We recommend that you keep the original carton box and

packing material for any future shipping.

Loudspeaker installation

The speaker is best used with the tweeters approximately

at ear level when seated. There is a bracket hole on the

back of the 6344C. This can be used for mounting the 6344C

flat on a wall.

Loudspeaker positioning

Variations in placement of your loudspeakers can produce

dramatic differences in the way music sounds. No listening

rooms are the same and therefore we encourage you to spend

some time experimenting with which placements work best in

your listening room. Trust your ears and be willing to experiment

freely. You can start with our basic recommendations.

To begin with, the centre loudspeaker should be positioned

horizontal directly under your TV.

Home Theatre Systems

Argon 6344C can be used as centre channel in a surround

sound home theatre system.

Positioning the centre loudspeaker close to your TV will create

the best sound image in scale with the visual image.

If Argon 6344C are to be used for reproducing the surround

channels in a multi channel home theatre system, we suggest

you place them as illustrated in Figures 2 to 5 depending on the

number of channels.

Magnetic interference

Argon 6344C tweeter and woofer drive units are magnetically

shielded ensuring that the magnetic field outside the cabinet,

except the front, is too low to cause distortion of the TV picture,

and you can place the loudspeakers as close to the TV screen

as possible without causing visual interference or electromagnetic

interference with the TV.

Because of the higher magnetic field in front of the

loudspeakers, all magnetically sensitive articles (audio and

video tapes, computer discs etc) should be kept at least 0,3

meters away from the front of the loudspeaker.

Connecting your loudspeakers

We recommend that you read the manual of your amplifier or

av-receiver carefully before connecting your loudspeaker.

Please switch off all equipment when connecting your

loudspeaker.

The binding posts on the terminal accepts wire up to Ø 4mm or

cables with banana plugs.

Make sure that positive terminal binding posts on the speaker

(marked + and colored red) are connected to the positive

output terminal binding posts on the amplifier and that the

negative terminals on the speaker (marked – and colored

black) are connected to the negative output terminal on the

amplifier. See fig 5.

You are now ready to enjoy your Argon 6344C loudspeaker...!

w w w . a r g o n a u d i o . c o m 3

6344C

Running-in period

We recommend a running-in time of your new Argon 6344C

loudspeaker of approximately 15-20 hours at normal

listening level before you decide on the final positioning of the

loudspeakers. During the running-in time the drive units will

settle in and perform as intended.

Care and cleaning

We don’t recommend use of any solvents or cleaners on the

Argon 6344C cabinet, the cabinet surface usually only

requires dusting or cleaning with a damp soft cloth (only

use cold clean water).

The grille fabric may be cleaned with a normal clothes brush or

vacuumed carefully with the grille detached from the cabinet.

Avoid touching the drive units, especially the tweeter, as

damage may result.

Environmental information

Argon 6344C loudspeaker comply with international directives

on the Restriction of Hazardous Substances (RoHS) in

electrical and electronic equipment and the disposal of Waste

Electrical and Electronic Equipment (WEEE) - the crossed bin

symbol indicates compliance and that the products must be

appropriately recycled or processed in accordance with these

directives.

w w w . a r g o n a u d i o . c o m 4

6344C

Specifications:

2 Way Loader Speaker 3 – Drivers

3/4” Neo Dynamium Tweeter Speaker

2x 4” Woofer Speaker

Frequency Response (-3db): 80Hz-20KHz

Sensitivity:(at 1W/1m): 85dB +/- 2db

Impedance: 4ΩPower:

Handling: 50W at 4Ω

Power handling 100W at 4Ω

Magnetic shielded

Dear Customer,

Quality has always been our driving force and

founding Argon Audio

is a natural extension of this philosophy.

We have 20 years’ experience in creating and

specifying high quality

products, manufacturing them and selling

them on to end users with Value-for-Money as the

primary aim.

And Argon Audio is a brand fully compliant with these

values.

Design, features and quality standards are all

specified in Denmark

and manufacturing takes place in the Far East,

where quality vendors are highly competitive - and as

a result supply

outstanding Value-for-Money products

– to the delight of both ourselves and our customers!
