arf HandyKing EP Manuel utilisateur
GM055PO26641106
It is designed for maximum performance. Please seek advice if one is not familiar with this kind
of electric powered precision model. Operating this model without prior preparation may cause
injuries. Remember, safety is the most important thing. Always keep this instruction manual at
hand for quick reference.
Warning ! This model is not a toy.
THE WINGS MAKER
FACTORY PRE-FABRICATED
ALMOST-READY-TO-FLY (ARF) SERIES
MADE IN CHINA
* Specifications are subject to change without notice.*
www thewingsmaker com. .
SpecificationsSpecifications
Before commencing assembly please read these instructions thoroughly, .
INSTRUCTION MANUAL
Wing Span: 46.5 in / 1180 mm
Wing Area: 565 sq in / 36.4 sq dm
Flying Weight: 53 oz / 1500 g
Fuselage Length: 52 in / 1320 mm
Requires: 4-channel radio w/ 4 mini servos. Outrunner
Motor KM0374810 w/ Propeller Adaptor HW2340102
40A Brushless ESC,11x8E Propeller, 4 cells 14.8V
3200 mAh Li-Po battery & charger.
HandyKing EP(40)
GM055PO26641106
Check all parts. If you find any defective or missing parts contact your local dealer. Please
DRY FIT and check for defects for all parts that will require CA or Epoxy for final assembly.
Any parts you find to be defective after the gluing process may be difficult to remove for
warranty replacement. The manufacturer will replace any defective parts, but will not extend
to the parts that are good before gluing to defective parts during assembly. Warranty will
not cover any parts modified by customer. For pre-assembled kits, please check proper
functions of all servos on the ground before flying. Servo gears could be damaged when
control surfaces are hit during transportation of models. The manufacturer will replace any
servos due to manufacturer`s defect, but will not cover plane crashes due to damaged
servos not detected before flying.
Symbols used throughout this instruction manual comprise of the following :-
Read through the manual before you begin, so you will have an overall idea of what to do.
1
2
3
INDEX
BEFORE YOU BEGIN
BEFORE YOU BEGIN
PARTS LIST
ASSEMBLY
SAFETY PRECAUTIONS
P.1
P.2
P.3-P.9
P.9
P.1
Cut off shaded portion.
Ensure smooth non-binding
movement while assembling.
Apply instant glue
(C.A.glue, super glue.)
Assemble left and right
sides the same way.
Peel off shaded portion
covering film.
Pay close attention here!
Apply epoxy glue.
Must be purchased separately !
Drill holes with the specified
diameter (here: 3mm). Pierce the shaded portion
covering film.
3mm
Do not overlook this symbol !
Warning!
Apply thread locker
HandyKing EP(40)
GM055PO26641106
P.2
Parts List
1.MAIN WING -- 1 pair
CLEVIS PL4112103 -- 2 pcs
STRAPER PL4112102 -- 2 pcs
FUEL TUBE D2.5xD6x5mm -- 4 pcs
HORN PL4113103 -- 2 pcs
PUSHROD Ø1.8x55mm w/ Threads (ForAileron) -- 2 pcs
SERVO MOUNTING PANEL PL5310030 -- 1 pair
SCREW PA1.7x8mm -- 8 pcs
FIBRE TAPE 17x540mm -- 2 pcs
PLYWOOD 50x50x2mm -- 2 pcs
2.FUSELAGE -- 1 set
STABILIZER & ELEVATOR -- 1 set
FIBRE TAPE 17x380mm -- 1 pc.
3.VERTICAL FIN & RUDDER -- 1 set
FIBRE TAPE 17x250mm -- 1 pc.
PLYWOOD 50x50x2mm -- 1 pc.
4.TAIL LANDING GEAR PL3410031 --1 set
SCREW PA2.6x10mm -- 2 pcs
COLLAR Ø2.1mm w/ Set Screw -- 1 set
PLYWOOD 50x50x2mm -- 1 pc.
5.MAIN LANDING GEAR -- 1 set
COLLAR Ø3.1mm w/ Set Screw -- 2 sets
MAIN WHEEL Ø62mm PL3111620 -- 2 pcs
SCREW PA2.6x10mm -- 1 pc.
PLYWOOD 46x33x3.4mm (For Main Landing Gear) -- 1 pc.
MAIN LANDING GEAR COVER -- 1 pair
6.SCREW PA1.7x8mm -- 4 pcs
FUEL TUBE d2.5xD6x5mm -- 2 pcs
CLEVIS PL4112103 --1 pc.
STRAPER PL4112102 -- 1 pc.
SERVO MOUNTING PANEL PL5310030(R) -- 1 pc.
HORN PL4113103 -- 1 pc.
PUSHROD Ø1.8x146mm w/ Threads (For Elevator) -- 1 pc.
7.SCREW PA1.7x8mm -- 4 pcs
FUEL TUBE d2.5xD6x5mm -- 2 pcs
CLEVIS PL4112103 --1 pc.
STRAPER PL4112102 -- 1 pc.
HORN PL4113103 -- 1 pc.
SERVO MOUNTING PANEL PL5310030(L) -- 1 pc.
PUSHROD Ø1.4x150mm w/ Threads (For Rudder) -- 1 pc.
8.SOCKET HEAD SCREW M3x10mm -- 4 pcs
WASHER d3xD7mm -- 4 pcs
SPINNER Ø52mm -- 1 set
9.WING TUBE Ø8x500mm -- 1 pc.
RUBBER BAND D4x30mm -- 2 pcs
HOOK Ø1.6x178mm -- 1 pc.
10.BATTERY COVER -- 1 pc.
BATTERY TIE 200mm-- 2 pcs
SPONGE 10x50x150mm -- 2 pcs
DOUBLE-SIDED TAPE 30x35mm (For Brushless ESC) -- 1 pc.
11.DECALS: GM055 DEC -- 1 set
GM055PO26641106
P.3
Bottom View Bottom View
Bottom View
Aileron Servo
1
Fibre Tape 17x540 mm
Aileron Servo Lead
Fibre Tape
Bottom
Plywood
50x50x2 mm
PA1.7x8mm Screw
8
TWM PL8210010
CLEVIS WRENCH
Clevis Pushrod
Ø1.8x55mm
FuelTube
d2.5xD6x5mm
Horn
Straper
Fuel Tube
d2.5xD6x5mm
PA1.7x8mm
GM055PO26641106
P.4
0
Vertical Fin & Rudder
3
Completed
0
Tail Landing Gear
4
Bottom View
PA2.6x10mm Screw 2.1mm Collar
22
Fibre Tape
17x250 mm
Fibre Tape
Wheel Ø23mm
PA2.6x10mm
1.2mm
M3x3mm Set Screw
2.1mm Collar
Bottom View
Stabilizer & Elevator
2
Fibre Tape
17x380 mm
Fibre Tape
Bottom
Joining surfaces should
be clean and dry. Slightly
roughen surfaces with
sandpaper for best results.
Joining surfaces should be clean and dry. Slightly roughen
surfaces with sandpaper for best results.
Plywood
50x50x2 mm
Plywood
50x50x2 mm
GM055PO26641106
Main Landing Gear
Elevator Pushrod
5
6
Bottom View
Bottom View
P.5
M3x3mm Set Screw
3.1mm Collar
Bottom View
Bottom View Bottom View
Wheel Ø62mm
Main Landing Gear Cover
PA2.6x10mm Screw
1
PA2.6x10mm
Plywood
Landing Gear
46x33x3.4mm
3.1mm Collar
2
PA1.7x8mm Screw
4
Straper Fuel Tube
d2.5xD6x5mm
PA1.7x8mm
100
Landing Gear
Fuselage
TWM PL8210010
CLEVIS WRENCH
Clevis
Pushrod
Ø1.8x146mm
FuelTube
d2.5xD6x5mm Horn
GM055PO26641106
Rudder Pushrod
7
Outrunner Motor / Spinner
8
P.6
PA1.7x8mm Screw
4
4
d3xD7mm Washer
4
Make sure rotating motor casing is not in contact
with wirings or anything.
Enlargeopening for better
coolingif necessary .
Optional Parts
2
Brushless ESC
EZ Connector
SolderSolder
TWM
KP0011310
ESC Motor
3 4
M5 Nut
d6xD15mm Washer
Ø52mm Spinner
PA3x12mm
TWM HW3111700
PROPELLERADAPTORWRENCH Completed
d3xD7mm Washer
M3x10mm
Don't over-tighten the M3 screws, too much
stress on the screws could split the firewall.
1
Straper Fuel Tube
d2.5xD6x5mm
PA1.7x8mm
Outrunner Motor 37/ 48 Deluxe
KM0374810
PropellerAdaptor
HW2340102
11x8E Propeller PL6211108
11x8E Propeller
PL6211108
Clevis
Pushrod
Ø1.8x150mm
Fuel Tube
d2.5xD6x5mm
Horn
TWM PL8210010
CLEVIS WRENCH
M3x10mm
Socket Head Screw
Bottom View
GM055PO26641106
P.7
Main Wing
9
Rubber Band
Aileron Servo Lead
Wing Tube
Ø8x500mm
Radio Equipment
10
Battery
Install and arrange the equipment as shown in the picture.
Outrunner Motor
Battery Tie Sponge
Sponge
Receiver
Front
Brushless
ESC
Double Sided Tape
Completed
Fuselage Bottom
Battery Cover
Completed
Hook
GM055PO26641106
P.8
Control Throws
12
Elevator
Rudder
Ailerons
Adjust the control throws as shown in
the diagram. These throws are good for
general flying. You can adjust according
to your personal preference.
40mm
40mm
50mm
50mm
60mm
60mm
Decals
11
FL01
FL06
FL03F08 FL04
FL05
FL02
FL07
WL01 WL02
WL03
WL04 WL05
WL06
WL07
SL01
SL02
SR03
SR01
SR02
SR04SL04
SL03
WR01
WR02
WR03
WR04
WR05
WR06
WR07
GM055PO26641106
P.9
Important Safety Precautions
# First time flyer should never fly by himself / herself. Assistance from experienced flyer
is absolutely necessary.
# Pre-flight adjustment must be done before flying, it is very dangerous to fly a badly
pre-adjusted aircraft.
# is specially designed to be powered by KM0374810 Outrunner Motor.
# Make sure the air field is spacious, never fly the plane too close to people and never get
too close to a running propeller. Extreme caution should be exercised when working with
electric powered models. Make sure the propeller is cleared of all objects, especially your
hands before connecting the battery to the model. Make sure you understand the
operation of the ESC (Electronic Speed Control) by studying the ESC manual. Once you
plug in the battery for electric powered model, always treat the propeller as a rotating one,
as accidental movement of the throttle stick will spin the propeller and could cause injuries.
# Check and re-tighten up all factory assembled screws, use thread locker if necessary.
Warning!
HandyKing EP(40)
C.G.
13
The ideal C.G. position is 130mm (5.1 in.) behind the leading edge
measured at where the wing meets the fuselage. In order to obtain
the C.G. specified, add weight to the fuselage or move the battery
position. Check the C.G. before flying.
130mm
5.1 in.
C.G.
