ENGLISH

P/N:109940

NEED HELP?

As we are often updating and improving our products, your device’s software may have

a slightly different appearance or modified functionality than presented in this Quick Start Guide.

On our Website:See the Frequently Asked Questions

section on http://arnovatech.com/faq

Contact our Technical Support Team: Visit http://

arnovatech.com/support for e-mail support.

Please register your product before contacting

Technical Support (see

Thank you for choosing this ARNOVA product. We hope that you will enjoy using it and that it will give you satisfaction for many

years to come. Once you unpack your ARNOVA product, we recommend that you take a few minutes to register it

(http://arnovatech.com/register).This will allow you to get access to ARNOVA technical support (http://arnovatech.com/support).

ÄOn the web at http://arnovatech.com/register

SOFTWARE UPDATE

The ARNOVA operating system (the system that runs

your device) is periodically updated to bring new features,

improvements and bug fixes.

ÄOn the web at www.arnovatech.com

> support&account > Downloads = firmware

ENGLISH

DESCRIPTION OF THE DEVICE

Power Button: press and hold to switch on.

- To switch off, when you press and hold on the Power button, a window appears with a list

of options. Touch “Power Off” > “Ok” to fully shut down your ARNOVA.

-To put your device in standby, press the Power button once.

Volume buttons

Built-in microphone

Micro-SD card slot: a Micro-SD card should be inserted in the device. It allows the

device to be identified as a removable storage when connected to a PC.

SIM card slot: Any standard SIM card can be inserted.

Loudspeaker

Headphone jack

Micro-USB port: to connect your ARNOVA to your computer, using the included USB cable

(to transfer files via USB 2.0 or higher) .

Power connector: to connect the supplied power cable.

Reset button:Your device is frozen.You can turn it off. Press the reset button.

Menu - gives menu options according to the current

screen.

Home - Short press: return to the Home screen.

Hold: jump to one of the recent applications.

Search - allows you to search for an item on the device or on

the Internet.

Back - returns to the previous screen.

▲

EUR

ENGLISH

STARTING UP

Before using your ARNOVA for the rst time, completely charge the battery!

Charging the Battery

Connect the supplied power cable to the ARNOVA Power connector and to a wall outlet.

The ARNOVA device will start charging.

IMPORTANT: The device should not be charged via a USB port.

Power Button: press and hold to switch on.

- To switch off, when you press and hold on the Power button, a window appears with a list

of options. Touch “Power Off” > “Ok” to fully shut down your ARNOVA.

-To put your device in standby, press the Power button once.

Volume buttons

Built-in microphone

Micro-SD card slot: a Micro-SD card should be inserted in the device. It allows the

device to be identified as a removable storage when connected to a PC.

SIM card slot: Any standard SIM card can be inserted.

Loudspeaker

Headphone jack

Micro-USB port: to connect your ARNOVA to your computer, using the included USB cable

(to transfer files via USB 2.0 or higher) .

Power connector: to connect the supplied power cable.

Reset button:Your device is frozen.You can turn it off. Press the reset button.

www

ENGLISH

CONNECTING TO A WIFI NETWORK

For this procedure to work, you need to be in a WiFi zone that will allow you to connect to it. Every time the ARNOVA is

in range of a network that you have already configured once, it will attempt to make a connection.

* For free access WiFi points, there is no need to enter any special information. For secured networks, you will need either a key (a series of numbers and/or letters)

of the type WEP, WPA, or WPA2. To obtain the exact connection parameters required, contact the Internet service provider.

To configure a new WiFi network, go on the Home screen, tap on the Menu icon , then

select Settings .

In the Settings screen, select Wireless & networks.

If the WiFi is off, tap on the Wi-Fi line to turn it on.Then select Wi-Fi settings.

The ARNOVA will scan for available WiFi networks and display them at the bottom of

the screen.

Tap on the network you want to connect to, enter the required network information* and then

tap on Connect.Your ARNOVA will now attempt to establish a connection to that WiFi hot spot

with the network parameters you entered.

CONNECTING TO A 3G NETWORK

Chip

ENGLISH

To configure a new WiFi network, go on the Home screen, tap on the Menu icon , then

select Settings .

In the Settings screen, select Wireless & networks.

If the WiFi is off, tap on the Wi-Fi line to turn it on.Then select Wi-Fi settings.

The ARNOVA will scan for available WiFi networks and display them at the bottom of

the screen.

Tap on the network you want to connect to, enter the required network information* and then

tap on Connect.Your ARNOVA will now attempt to establish a connection to that WiFi hot spot

with the network parameters you entered.

CONNECTING TO A 3G NETWORK

Inserting your SIM card

IMPORTANT: Before inserting a SIM card, you must turn off the device.

Switch off the device.

Insert the SIM card in the SIM card slot.

Make sure to have the chip side up when you insert it.

Turn on the device.

A Pin number may be requested. Enter the SIM card pin number.

Your device will attempt to connect to the 3G network of your provider.

Your Arnova 7c G2 is equipped with a SIM card slot. Any standard SIM card can be inserted. There is no provider restriction.

Note that the Arnova 7c G2 will only have signal if you are in an area covered by your 3G provider’s 3G or EDGE network.

NOTE: If your device does not connect to

your 3G provider’s network:

1. Contact your 3G provider to obtain the

connection parameters.

2. On your device, tap the Menu icon, then

settings.

3. Select Wireless & networks > Mobile

networks.

-In Network operators, select your operator.

-In Access Point Names, select the correct

access point name and enter the exact con-

nection parameters.

ENGLISH

Customizing the Home screen items

-To add a Home screen item (shortcuts, widgets, etc.), hold your finger on the screen at an empty location, then choose from

the list.You can also tap on the Menu icon and select Add , at the bottom of the screen.

-To move a Home screen item, hold your finger onto it until it gets larger, then drag it to the desired location, and release

your finger.

-To remove a Home screen item, hold your finger onto it, drag it onto the recycle bin (while you’re holding an item, the

Applications tab, on the right side of the screen, turns into a recycle bin) and release your finger.

CUSTOMIZING YOUR PRODUCT

Changing the Settings:From the Home screen, tap on the Menu icon , tap on Settings

and choose a category: Wireless controls, Sound & display, Date & time, etc.

Adding more applications with APPSLIB :With the ARNOVA connected to the Internet, tap on the AppsLib icon .This online

library of free and purchasable applications has thousands of fun games and useful applications to download and use.

ENGLISH

THE ARNOVA INTERFACE

Your ARNOVA device is equipped with a capacitive touchscreen. Use your finger pulp to navigate.

These are the default

Android™ shortcuts (Web

Browser, EMail, etc.). Tap on an

icon to open the correspond-

ing application.You can

customize the Home screen

by adding/removing shortcuts

and widgets, changing the

wallpaper, etc. See next page.

Home Screen

Application button

Tap on this icon to reveal all the An-

droid™ applications installed on your

ARNOVA (games, various tools, etc.).

You can copy them onto the Home

screen.You can get more Android™

applications from AppsLib .

The extended Home screen

Slide your finger horizontally on

the screen to go to the left or right

side of the extended Home screen.

USB

ENGLISH

TRANSFERRING MEDIA TO YOUR ARNOVA

Connect the supplied USB cable to the ARNOVA and to a running computer via USB 2.0 or higher.

The ARNOVA will ask you if you want to connect it.Tap on Turn on USB storage to connect it and press OK to conrm.

Within a few seconds the Micro-SD card will appear as an icon on your computer.

You can transfer your media files to the Micro-SD card either by copy/pasting them into the respective folders using

Windows® Explorer (or the Finder on a Mac®), or by using Windows Media® Player. Open Windows Media Player® and

then use the Sync tab to synchronize your music, videos, and photos onto your Micro-SD card. See Windows Media

Player®’s Help to learn more about this.

Once all your file transfers are finished, close Windows® Explorer and any other program that may have read or written

to the Micro-SD card. Click on the ‘safely remove’ icon in the system tray, next to the clock.You can now unplug the USB

cable.

IMPORTANT: A Micro-SD card should be inserted in the device. It works as your device storage. If there is no Micro-SD card, you can’t

transfer les to your device.

www

FRANÇAIS

ENREGISTREZ VOTRE PRODUIT !

ÄSur Internet : http://arnovatech.com/register

Merci d’avoir choisi ce produit ARNOVA. Nous espérons que vous aurez plaisir à l’utiliser et qu’il vous donnera satisfaction pendant de

nombreuses années. Après avoir déballé votre produit ARNOVA, nous vous conseillons de prendre quelques minutes pour l’enregistrer

(http://arnovatech.com/register). Cela vous permettra d’avoir accès au support technique ARNOVA (http://arnovatech.com/support).

BESOIN D’AIDE ?

Comme nous mettons à jour et améliorons régulièrement nos produits, le logiciel de votre appareil peut présenter une

interface ou des fonctionnalités légèrement différentes de celles décrites dans ce guide.

Sur notre site Web:Consultez la Foire Aux Questions

(FAQ) sur http://arnovatech.com/faq

Contactez notre équipe d’assistance technique: Allez

sur http://arnovatech.com/support pour une assistance

par e-mail.

Veuillez enregistrer votre produit avant de contacter

notre équipe d’assistance technique (voir

Enregistrez

votre Produit

METTRE À JOUR LE LOGICIEL

Le système d’exploitation ARCHOS (le système qui permet à

votre ARCHOS de fonctionner) est périodiquement mis à jour

pour apporter de nouvelles fonctions, des améliorations et des

corrections d’erreurs.

ÄSur Internet : www.arnovatech.com

> support&comptes > Téléchargements = firmware

FRANÇAIS

DESCRIPTION DE L’APPAREIL

Bouton ON/OFF : maintenez appuyé pour allumer l’appareil.

- Pour éteindre l’appareil, lorsque vous maintenez le bouton enfoncé, une fenêtre apparaît avec

une liste d’options. Appuyez sur « Eteindre » > « Ok » pour éteindre votre ARNOVA complètement.

- Pour mettre en veille votre appareil, appuyez sur le bouton une fois.

Boutons de volume

Microphone intégré

Emplacement pour carte Micro-SD: une carte Micro-SD doit être insérée dans l’appareil.

Elle sert de mémoire interne à l’appareil.

Emplacement pour carte SIM

Haut-parleur

Prise casque

Port micro-USB :permet de connecter votre ARNOVA à un ordinateur à l’aide du câble USB fourni

et de transférer des fichiers via USB 2.0 ou plus

Connecteur d’alimentation :pour connecter le câble d’alimentation fourni.

Bouton de réinitialisation (reset) Votre produit ne réagit plus.Vous pouvez l’arrêter en utilisant le bouton de

réinitialisation (reset).

Menu - vous donne accès aux options de menu

disponibles.

Accueil - Appui court : Retour à l’écran d’accueil.

Appui long : basculer vers l’une des applications récentes.

Recherche - Vous permet de rechercher un élément sur l’appa-

reil ou sur Internet.

Retour - Retour à l’écran précédent.
