Archos 53 Titanium Manuel utilisateur

Table of contents

For more information, please consult the FAQs on www.archos.com.

Make sure to read them before considering any product return. As we

are often updating and improving our products, your device’s software

may have a slightly dierent appearance or modied functionality than

presented in this Quick Start Guide.

Package contents..........................................................................................................

Description of the phone...........................................................................................

Assembling......................................................................................................................

Getting started...............................................................................................................

3G & WiFi connection...................................................................................................

Google account & Contacts........................................................................................

Hints & tips with AndroidTM................................................................................

Troubleshooting.............................................................................................................

Package Contents

Check your product box for the following items:

-ARCHOS 53 Titanium

-Battery

-Headset

-Micro SIM adaptor

-USB cable

-Charger

-Quick start guide

-Warranty Legal & Safety notices

The items supplied with your device and available accessories may vary

depending on your region or service provider.

The supplied items are designed only for your device and may not be

compatible with other devices.

Unapproved accessories may cause your device to malfunction.

24-07-2013

last modification:

AC53TI

CONFIDENTIAL

DRAWING

Rev

scale 1:1 mm

24-07-2013

last modification:

AC53TI

CONFIDENTIAL

DRAWING

Rev

scale 1:1 mm

1 2

1Micro-USB port

Headset jack

Webcam

Phone speaker

Volume buttons

ON/OFF button

Microphone

Description of the phone

24-07-2013

last modification:

AC53TI

CONFIDENTIAL

DRAWING

Rev

scale 1:1 mm

Description of the phone

8Camera

Loudspeaker

Flashlight

11 12 13

Menu: open the list of options available on the current screen.

Home/Recent apps: short press to return to the Home screen; long

press to open the list of recent applications.

Back: return to the previous screen.

Home/Recent apps

Back

Assembling

Opening

1. Use the notch to remove the back cover.

Do not bend or twist the back cover excessively. Doing so may damage

the cover.

2. Remove the battery.

Inserting SIM cards

For your 3G SIM card, slide it facing downwards in the 2G/3G slot (slot 1).

For your standard SIM card, slide it facing downwards in the 2G slot (slot 2).

Inserting a Memory card

Slide it facing downwards in the slot 3.

Closing

1. Align the battery’s 4 contact points with those of the phone and gently

press the battery down into place.

2. Replace the back cover clicking it back into position.

Tip:

Before using your device for the first time, charge completely its battery.

Picture to show how to removed the bottom casing Picture to show how to insert the battery pack Picture to show the scards position

Slot1

Slot2

Slot3

Assembling

Slot1 2G/3G SIM card

Slot2 2G micro-SIM card

Slot3 Memory card up to 64 GB

Lift the back cover

using the notch

Turn ON

1. Press and hold the ON/OFF button to turn on the device.

When you turn on your device, a PIN code may be requested.

2. Type the PIN code supplied with your SIM card.

Beware of typing a wrong PIN code.

3. Select‘OK’.

Turn OFF

To turn o your device, press and hold the ON/OFF button, and then

select Power o > OK.

Sound & Notication proles

Getting started

Tip:

Your device goes in standby mode when you do not use it for a specified

period of time. To wake up your device, press the ON/OFF button.

To set the duration, go to Settings > Display > Sleep.

1. When the device is turned on, press

and hold the ON/OFF button.

2. Select an option.

Silent Vibrate Sound

Through the wizard

The rst time you start up your ARCHOS, the installation wizard will help

you set up your device:

-Location consent

-Language

-Google account

-Location service options

-Date & time

Touch screen actions:

Tap: touch once to select or launch a menu, option, or application.

Tap and hold: tap an item and hold it for more than 2 seconds.

Drag: tap an item and move it to a new location.

Double-tap: tap an item twice quickly.

Flick: briskly scroll up, down, left, or right to move through lists or screens.

Pinch: place two of your ngers far apart, and then pinch them together.

3G connection

With your 3G SIM card, you should be connected to the Internet without

any further setup. The ARCHOS will only have signal if you are in an area

covered by your 3G provider’s 3G or EDGE network. When connected to

the 3G network, the 3G icon is displayed in the status bar.

Activating the mobile data

3G & WiFi connection

To be able to access Internet, the mobile data icon must be activated.

1. Touch and hold the time & battery icons

to reveal the status bar.

2. Pull the blue line down to display the

status dashboard.

3. Touch the status dashboard icon .

4. Touch the mobile data icon to activate it.

Tip:

When you encounter connection problem’s, see the FAQs on www.

archos.com or contact your 3G network connection provider.
