MODEL MARQUIS AGDVT-38/AGDV-38

DIRECT VENTED BUILT-IN

GAS FIREPLACE

FOR USE WITH NATURAL GAS AND PROPANE

INSTALLATION AND OPERATING INSTRUCTIONS

FOR YOUR SAFETY

DO NOT store or use gasoline or any other flammable vapors or liquids in the vicinity

of this or any other appliance

IF YOU SMELL GAS:

- Do not try to light any appliance.

- Open windows.

- Do not touch electrical switches.

- Extinguish any open flame.

- Immediately call your gas supplier from a neighbor's phone. Follow the gas supplier’s

instructions.

- If you cannot reach the gas supplier, call the fire department.

PLEASE READ INSTRUCTIONS CAREFULLY BEFORE INSTALLING AND

OPERATING THE APPLIANCE

WARNING: Improper installation, adjustment, alteration, service or maintenance voids

all the manufacturer’s warranties and may cause property damage, personal injury or

loss of life.

Installation and service must be performed by a qualified installer, service agency or the

gas supplier.

Installer, please leave this manual with the appliance owner for future reference.

WARNOCK HERSEY

CERTIFIED FOR CANADA AND USA

NOT FOR USE WITH SOLID FUEL

200-0044

24MAY01

fire-parts.com

CONTENTS

Introduction 2

General Information 3

Appliance Description and Dimensions 4

Installation Instructions 5 - 13

Operation Instructions 14 - 15

Maintenance 16

Trouble Shooting Instructions 17 - 18

Servicing 19 - 20

Important Information Form 21

Warranty 22

Replacement Parts 23

Allowed Termination Location 24

Warranty Registration Form 25

Page

Manufactured by Archgard Industries Ltd, British Columbia, Canada.

Patents Pending

fire-parts.com

INTRODUCTION

Thank you for purchasing the Marquis DV-38 Direct Vent Built-in Gas Fireplace.

The Marquis DV-38 is one of the most advanced gas fireplaces on the market. It is designed

using the latest technology and manufactured to the highest quality.

Some of the many features are:

* Realistic Fire The Marquis DV-38 has a glowing ember bed in front and soft

flowing flames at the back. A realistic split log set complements the

flames.

∗ Solid Construction The Marquis DV-38 is constructed mainly of satin coated and

galvanized steel for long life and durability.

Please read the manual carefully prior to installation and operation of the appliance.

Proper installation, operation and maintenance of the appliance will provide you with

many years of enjoyment.

CAUTION

Due to high temperatures, the appliance should be located out of traffic and away from

furniture and draperies.

Children and adults should be alerted to the hazards of high surface temperature and

stay away to avoid burns or clothing ignition.

Young children should be carefully supervised when they are in the same room as the

appliance.

Clothing or other flammable material should not be placed on or near the appliance.

Any parts removed or opened for servicing of the appliance must be properly replaced

prior to operating the appliance.

The appliance must be inspected before use and at least annually by a qualified service

person. More frequent cleaning maybe required due to excessive lint from carpeting,

bedding material, etc. It is imperative that the control compartments, burners and

circulating air passageways for the appliance be kept clean.

fire-parts.com

GENERAL INFORMATION

This appliance is listed by Warnock Hersey for use in both the United States and Canada. It is

tested and certified to the following US and Canadian gas appliance standards.

- ANSI Z21.50-1996 / CGA 2.22-M96, Vented Gas Fireplace and Heaters

- CAN/CGA-2.17-M91, Gas-Fired Appliances for Use at High Altitudes.

Please contact Archgard Industries Ltd. if you have any questions regarding the certification of

this appliance.

APPLIANCE CERTIFICATION

INSTALLATION CODES

This appliance must be installed by a qualified gas appliance installer.

The installation must conform with the local codes or, in the absence of local codes, with the

current National Fuel Gas Code, ANSI Z223.1/ NFPA 54, in the US or Installation Code,

CAN/CGA-B149, in Canada.

Electrical connections and grounding must conform with local code, or current National

Electrical code, ANSI/NFPA No. 70-1987, in the US and in Canada, the current Canadian

Electrical Code, CSA C22.1.

HIGH ALTITUDE INSTALLATION

When installing this appliance beyond 4500 ft. (1372 m) above sea level. The appliance must be

properly de-rated and installed according to local codes. In the absence of local codes, with the

current National Fuel Gas Code, ANSI Z223.1/ NFPA 54, in the US or Installation Code,

CAN/CGA-B149, in Canada.

Natural Gas (NG) Propane (LP)

Manifold Pressure 3.5 in. w.c. ( 0.9 kPa) 10.0 in. w.c. ( 2.5 kPa)

Min. Supply Pressure for Purpose

of Input Adjustment

4.5 in. w.c. (1.2 kPa) 11.0 in. w.c. (2.8 kPa)

Orifice Size #48 DMS ( 1.93 mm dia.) #56 DMS ( 1.18 mm dia.)

Nominal Input Rating 16,000 BTU/hr (4.6 kW) 16,000 BTU/hr ( 4.6 kW)

Altitude 0 - 4,500 ft. (0 - 1372 m) 0 - 4,500 ft. (0 - 1372 m)

Primary Air Opening 1/4 in. (6.4 mm) 1/2 in. (12.7 mm)

SPECIFICATIONS

fire-parts.com

APPLIANCE DESCRIPTION & DIMENSIONS

GAS VALVE

CONVECTION FAN

SPEED CONTROL

(Optional)

TOP LOUVERS

GLASS DOOR

APPLIANCE DIMENSIONS

FRONT VIEW

38”

23-1/2”

39-3/4”

TOP VIEW SIDE VIEW

FRONT VIEW

3”

* Except for the vent connector locations, the rear vented DV-38 and top vented DVT-38, have the

same physical dimensions.

6”

1/4”

32”

29-3/4”

21-1/4”

31-1/16”

16-1/4”

fire-parts.com

ACross Corner

BFlush with Wall

CFlat on Wall Corner

DFlat on Wall

EIsland

FRoom Divider

15 ft Max.

INSTALLATION INSTRUCTIONS

PRECAUTIONS

•This appliance must be installed by a qualified gas installer and the installation conform to the

installation codes.

•Provide adequate clearance around air openings of the appliance. Never obstruct front openings.

•Provide adequate clearances for proper operation and servicing of the appliance.

•This appliance must be properly connected to a venting system.

LOCATING GAS FIREPLACE

This appliance must be installed in any location that is free of plumbing, electrical wiring and heating or

air conditioning ducts. Select a location that is accessible for venting. See PAGE 24 “ALLOWABLE

TERMINATION LOCATIONS”.

VENT TERMINATION

1. See “ALLOWABLE TERMINATION LOCATIONS” diagram (page 24) to establish a suitable vent

termination location.

2. In heavy snowfall areas make sure vent termination is located where it can not be blocked by snow

from snow removal equipment.

3. Locate vent termination away from plants, bushes or any other object on or near the vent termination

that will interfere or obstruct the air flow around it.

4. DO NOT recess vent termination into walls, sidings or planters.

5. Vent terminations located below 7ft from grade level or anywhere it can be a burn hazard to the public,

such as patios and balconies, must be protected with an Archgard approved termination cage.

6. Always ensure bottom of Vent Terminal is a minimum of 12” above grade.

*NOTE: Rear vented gas fireplace DV-38 can only be located in positions A, B, C and D.

fire-parts.com

INSTALLATION INSTRUCTIONS Cont...

FRAMING DIMENSIONS

38”

16-1/4”

38-1/2”

26-1/4”

38”

54”

38”

*32-1/4”

16-1/4”

* If more rigidity is required. A stud may be added to the back of the top nailing flange

after the fireplace is installed.

TERMINATION

FRAMING

11”

10”

fire-parts.com

INSTALLATION INSTRUCTIONS Cont...

VENTING

The appliance will not function without being connected to a proper venting system.

This appliance may use 4” and 7” gas flex vents with DV-38 listed vent components, or Simpson Duravent

4 x 6-5/8 direct vent systems with Simpson Duravent Adaptor (SDA-1). 7” dia. rigid vent may directly replace

7” dia. flex vent in all applications.

For best venting performance using gas flex vent, here are some general venting rules that we recommend:

1. Use only 4”and 7” diameter 2-ply certified gas flex vent in a co-axial configuration.

2. Maintain a minimum clearance of 1” to the sides and bottom and 2” to the top outside surface of the vent

pipe and combustible material.

3. Observe any local code restrictions, if any, regarding the installation of this type of gas appliance.

4. Observe the venting chart given in this manual.

5. Use a vent spacer between the inside and outside flex vents at every 3 ft intervals.

6. Never slope horizontal running vents downwards.

7. VERY IMPORTANT: Maintain at least an upward slope of 1” for every 1 ft of horizontal run on the

rear vented models.

8. Terminate the vent with a vent termination supplied by Archgard Industries Ltd.

9. Support horizontal running vents every 3 ft to prevent it from sagging.

10.Wall terminal must be installed a minimum of 12” above grade measured from bottom of terminal.

CLEARANCES TO COMBUSTIBLES

Combustible mantle allowed in shaded area. Mantle

extension maybe increased 1” (25mm) for each

additional 1” (25mm) increase in clearance height.

6” (152 mm)

Minimum Height From Top Surround: 6”

Minimum Height From Bottom of Appliance: 37”

BACK 0” to stand-offs

SIDES 0” to stand-offs

TOP 0” to stand-offs

BOTTOM 0”

ADJACENT SIDE WALL 1” to side of faceplate

MANTLE see diagram

VENT 1” to outside side and bottom surface,

2” to outside top surface.

fire-parts.com

INSTALLATION INSTRUCTIONS Cont...

RESTRICTOR PLACEMENT “FOR ABOVE 7 FOOT VERTICAL RISE VENTED

APPLICATIONS ONLY”

Vertical Venting Between

Seven Feet (7’) and Ten Feet (10’)

must use Restrictor # 1. Vertical

Venting Between Ten Feet (10’)

and Twenty-four Feet (24’) for

Rooftop Terminations must use

Restrictor #2 . See Venting Chart

on page 9.

Simpson Duravent Archgard System

Archgard System

In the Archgard system the restrictors are placed on the exhaust outlet on the appliance.

Simpson Duravent

With Simpson Duravent locate the restrictor in the exhaust section fitting into the formed lip.

Restrictor Placement

WARNING: These restrictors are only to be installed in the vent system if the vent exceeds 7’

in vertical height, *Restrictor Number 1 below is required. Installing them

under any other circumstances may cause hazardous venting conditions

and may result in personal injury, property damage or death.

“NOT FOR USE IN SIDEWALL VENTED APPLICATIONS”

NOTE: Vent restrictors are designed to reduce vertical stack action for above 7 feet, which will reduce the

velocity of incoming combustion air and not adversely affect the standing pilot or the flame of the

appliance.

Restrictor #1

Restrictor #2

fire-parts.com

INSTALLATION INSTRUCTIONS Cont...

VENTING Cont...

•Chart is for one 90° bend, with 1/4” vertical raise minimum per foot of horizontal length.

•For each additional 90° or two 45°, add 1ft of vertical height.

•Maximum two 90º bends, or equivalent.

•Minimum 2 ft straight length between bends.

Maintain a minimum of 1” clearance to combustibles on sides and bottom and 2” from top surface

of the vent.

The gas fireplace is designed and optimized for majority of the installations with short vents. With

taller vents the flame characteristics will change.

NOTE: Maximum vent lengths subject to local codes.

VENTING CHART (FOR TOP VENTED APPLIANCES ONLY)

10 ft

37”

3 ft1 ft 15 ft

HORIZONTAL LENGTH

(from center of flue outlet to base of termination)

VERTICAL HEIGHT

(from bottom of appliance to center of termination)

7 ft

Venting in this area may require a vent restrictor plate #1.

5 ft 7 ft 9 ft 11 ft 13 ft

31”

Heater

Vertical Venting

between 10 and 24 ft

Rooftop Termina-

tion requires a vent

restrictor plate #2.

VERTICAL VENTING (THROUGH THE ROOF) FOR ROOFTOP VENTED APPLIANCES

•Use only Simpson Duravent 4 x 6-5/8” direct vent systems and Simpson Duravent venting

components.

•Maximum vertical height of 24 feet.

•Vertical height of the vent system must have at least 3 ft or more per 900elbow in the vent

system.

•Vertical height of the vent system must also be increased 1 ft for every 2 ft of horizontal

length added to the vent system.

Example: A vertical venting system with a 900elbow, a horizontal offset of 4 ft and another 900

elbow. Vertical vent height of the vent system must be 3ft + 2ft + 3ft = 8 ft or higher to a maxi-

mum of 24 feet.

Maximum Horizon-

tal run for Rear

Vent is 20” from

back of the unit to

termination or 16”

with a 450elbow.

fire-parts.com

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Archgard Cheminée intérieure

Archgard

Archgard 27-DVIE22N-2 Manuel utilisateur

Archgard

Archgard 31-DVIM33C-2 Manuel utilisateur

Archgard

Archgard marquis AGDV-38D Manuel utilisateur

Archgard

Archgard OPTIMA 30 - 1 Manuel du propriétaire

Archgard

Archgard Pele 345-DVTE31LN-1 Manuel utilisateur

Archgard

Archgard 45-DVFE28LN-1 Manuel utilisateur

Archgard

Archgard NORTHFIRE 3400 3400-DVTR20N-2 SN 8605 Manuel utilisateur

Archgard

Archgard Chalet 1800I Manuel du propriétaire

Archgard

Archgard 72-DVTE30P-2 Manuel utilisateur

Archgard

Archgard Marquis DVR-38 Manuel du propriétaire

Archgard

Archgard 37-DVTE30LN-1 Manuel utilisateur

Archgard

Archgard Optima 34 34-DVI34N Manuel du propriétaire

Archgard

Archgard Optima 34 Manuel utilisateur

Archgard

Archgard Harmonia 22 Manuel utilisateur

Archgard

Archgard Optima 72 Manuel utilisateur

Archgard

Archgard Kojin 50 Manuel utilisateur

Archgard

Archgard Northfire 42-dvt40n Manuel d'instructions

Archgard

Archgard 27-DVIM22N-2 Manuel utilisateur

Archgard

Archgard EURO 25-1 Manuel utilisateur

Archgard

Archgard OPTIMA 30 Manuel utilisateur

Archgard

Archgard SALZBURG XL Manuel utilisateur

Archgard

Archgard OPTIMA 30 - 1 Manuel du propriétaire

Archgard

Archgard 40-dvi40n Optima 40 - SB Manuel utilisateur

Archgard

Archgard Optima 32-1 Manuel du propriétaire

Manuels Cheminée intérieure populaires d'autres marques

Brigantia

Brigantia 35-DVRS31N-2 Manuel du propriétaire

Nordpeis

Nordpeis Bergen Manuel utilisateur

Superior

Superior BCT2536TMN Manuel utilisateur

Quadra-Fire

Quadra-Fire 5100I-GD-B Manuel utilisateur

Renaissance

Renaissance RUMFORD 1000 Manuel utilisateur

Lacunza

Lacunza IV-800 Manuel utilisateur

Baxi

Baxi 940 Instructions d'utilisation

Dru

Dru Maestro 60/2 Tall RCH Manuel utilisateur

Diamond Fireglass

Diamond Fireglass SS-O22 Manuel utilisateur

HearthStone

HearthStone Windsor Bay 8830 Manuel de programmation

Napoleon

Napoleon ASCENT B42 Manuel utilisateur

Enviro

Enviro E33GI Manuel utilisateur

Smeg

Smeg L30 FABE Instructions de montage

KEDDY

KEDDY K700 Manuel utilisateur

Godin

Godin 3451 Manuel utilisateur

Jøtul

Jøtul Jotul GI 535 DV IPI New Harbor Manuel utilisateur

Austro Flamm

Austro Flamm Heidi Back 2.0 945048 Manuel utilisateur

Desa

Desa CCFPDFT Manuel d'utilisation
