ARC PBT-707 Manuel utilisateur

Version 2.

pecification:

Function: 3 sets On / Off / Dimmer

1 set of Group On/Off

Frequency: 433.92MHz

Battery: 3V CR2032 lithium cell battery

verview:

Control your lighting with a single touch and take control under your own hands.

Slim 8 button remote control with 3 sets of ON/OFF button and 1 set of group ON/OFF function.

airing:

Pairing using LEARNING MODE:

1. First choose the desired receiver(s) that you wish to control.

2. Press the ‘Learn’ button once (LED will flash), this will now enter learning mode.

3. On the remote control press the ‘ON’ button intended to be paired; the load will flash twice to

confirm that the remote control is now paired.

※Once pairing is complete, the receiver device(s) will automatically store under the Group

Wireless Remote Control

PBT-707

Version 2.

ON/OFF function.

NOTE: Learning mode lasts for 12 seconds; if no signal is given to the receiver then it will

automatically exit learning mode without pairing the device.

To exit learning mode manually, simply press the ‘Learn’ button again.

！If, during learning mode the load does not flash to confirm, this means that the receiver’s memory

is FULL and no further remote control may be paired unless one of the existing remote control is

first unpaired (see below).

NOTE: Learning mode lasts for 12 seconds; if no signal is given to the receiver then it will

automatically exit learning mode without pairing the device.

To exit learning mode manually, simply press the ‘Learn’ button again.

！If, during learning mode the load does not flash to confirm, this means the receiver’s memory is

FULL and no further remote control may be paired unless one of the existing remote control is first

unpaired (see below).

n-pairing:

Removing single device:

1. With the receiver that you intent to un-pair press the ‘Learn’ button once (LED will flash), this

will now enter learning mode.

2. On the remote control press the ‘OFF’ button; the load will flash twice to confirm that the remote

control is now unpaired.

Removing all devices: (applicable to PBR/PER/PCR series only)

1. Plug the receiver(s) into wall socket (LED will slow flash for 5 secs), this will now enter learning

mode.

2. On the remote control press the ‘G / OFF’ button; the load(s) will flash twice to confirm that

memories originally stored in the remote control is now deleted.

Version 2.

peration:

ON/OFF Function:

Press ‘On’button to turn On the load.

Press ‘Off’button to turn Off the load.

Group ON/OFF Function:

Press the ‘Group ON’button on remote control, the group of lights you first set up will gradually

illuminate.

Press the ‘Group OFF’button on remote control, the group of lights you first set up will gradually

turn OFF.

Dimming Function: (not available under ‘Group’button)

1. Make sure the load is switched ON.

2. On the remote control press the ON button again, the loads will start to dim.

3. To stop at the desired brightness level, press the ON button again.

※Dimming level dims in cycle, during the cycle if no signal is given, after 4 cycles it will stop at

100% brightness.

！After setting a dim level using the remote control the light is then switched OFF, the next time that

the light is switched back ON again the load will return to the previous stipulated brightness.

attery replacement:

3V CR2032 lithium battery is included.

When the battery voltage is low, the transmission range will be reduced accordingly.

Slide down battery cover and with a screw driver push out the battery.

Version 2.

Replace with a new battery then slide up the battery cover.

roubleshoot:

Problem: The LED on remote control does not light up.

Solution:Please check if the battery is inserted correctly or replace a new battery.

Problem:I cannot pair my remote control with the receiver.

Solution:The memory on receiver is full, please delete one or more memory and try pairing again.
