Quick Installation Guide

Version 1.0

P1215

12.1" Slim-Size Intel Low Voltage

PIII / Celeron Panel PC

2P1215 Quick Installation

The information in this document is subject to change without prior notice in

order to improve the reliability, design and function. It does not represent a

commitment on the part of the manufacturer.

Under no circumstances will the manufacturer be liable for any direct, indirect,

special, incidental, or consequen-tial damages arising from the use or inability to

use the product or documentation, even if advised of the possibility of such

damages.

This document contains proprietary information protected by copyright. All rights

are reserved. No part of this manual may be reproduced by any mechanical,

electronic, or other means in any form without prior written permission of the

manufacturer.

About this installation guide

This manual provides general information and installation instructions about the

product. This Quick Installation is intended for experienced users and integrators

with hardware knowledge of personal computers. If you are not sure about any

description in this Quick Installation, please consult your vendor before further

handling.

P1215 Quick Installation

Warning

Panel PC and their components contain very delicate Integrated Circuits

(IC). To protect the Panel PC and its components against damage from

static electricity, you should always follow the following precautions

when handling it :

1. Disconnect your Panel PC from the power source when you want to work on

the inside

2. Hold the board by the edges and try not to touch the IC chips, leads or

circuitry

3. Use a grounded wrist strap when handling computer components.

4. Place components on a grounded antistatic pad or on the bag that came with

the Single Board Computer, whenever components are separated from the

system

5. It possibly needs BIOS support in the case of using special backplane,

otherwise, it might be not able to function completely.

6. Please make sure the power connector is tightly plugged into the power

socket before power on.

4P1215 Quick Installation

Getting Started

This section will help you have your P1215 up and running

smoothly.

Before up and running, please make sure the package contains

all of above accessories.

If any of the above items is damaged or missing, contact your

vendor immediately.

P1215

PACKING LIST

1 x DC-DC Adapter

4 x Screws

4 x LCD Hook

1 x Grounding Cable

1 x IDE Cable

1 x Print Cable

1 x Y Cable

1 x Driver CD

P1215 Quick Installation

Model Name

CPU Intel Low Voltage Celeron 400~733MHz CPU

FSB100/133MHz

Cache 2nd Level 256K

Memory default 256MB SDRAM on board, up to 512MB

(1 x 144 pin SO-DIMM Socket)

VRAM SMI722 G8 Lynx 3D+ engine 8MB Video RAM on chip

Chipset Intel 815E + Intel CH2

ATA / IDE Ultra DMA 33, support 2 IDE device

Watchdog Timer 127-level Reset

System Fan 1 x 4cm x 4cm / 8 CFM

Serial Port 3 x RS-232 ports (COM1/2/3)

USB Port 2 x USB 1.1 compliant

KB / MS 1 x PS2 K/B and Mouse

LAN RJ45

Size / Type 12.1" TFT Color LCD

Max. Resolution 800 x 600, SVGA

Pixel Pitch 0.3075mm x 0.3075mm

Touch Screen 12.1" Resistive (Com 4)

Viewing Angle 160° (V), 160° (H)

Luminance (cd/m2)300

Back Light MTBF 50,000 hours

HDD / Type 1 x built-in 2.5" vibration Resistant HDD bay

Flash Disk 1 x Type II Compact Flash Disk Socket (Internal)

Output rating 150W

Input voltage DC 18 ~ 32V or AC 90 ~ 260V (optional)

Operating Temp. 0° C ~ 50° C

Storage Humidity 5% ~ 95%, non condensing

Vibration 17~500 Hz, 1G PTP

Shock 10G/peak (11m sec)

Construction Heavy-duty steel & Aluminum (Front bezel)

Weight 3.5kg (7.7 lb)

Dimension (L x H x D) 329 x 254 x 63.8mm

Storage

Power Supply

Mechanical &

Environmental

Specification

System

I/O

LCD Display

Panel PC P1215

6P1215 Quick Installation

Mounting

Wall Mounting

P1215 Quick Installation

8P1215 Quick Installation

Dimension

Unit: mm

P1215 Quick Installation

Location of I/O Ports

Before starting to install software on your new Panel PC please spend some

time to find out the exact location of connectors and HDD (if pre-installed). The

front panel does not contain any indicators, switches, connectors or drive

access. All these are to be found on the left and right side and on the rear of the

system.

Default I/O

10 P1215 Quick Installation

Connecting Peripherals

The user can use the I/O interfaces located at the backside of the chassis to

connect external peripheral devices, such as a mouse, a keyboard, a monitor,

serial devices or parallel printer etc. Before connection, make sure that the

computer and the peripheral devices are turned off.

Connecting an exter-

nal CRT

P1215 has a 15-pin analog RGB

interface connector located at

the rear side of the chassis for

connection a secondary display. The system can support simultaneous display

on both its LCD display and on the external CRT display. Note that the

preferred resolution is 1024 x 768 because this is what the LCD Panel needs

to operate full screen.

External Serial Ports (RS-232/COM2/3)

The P1215 logic board

supports three onboard serial

ports, all COM ports supports

RS-232.

The external RS-232, COM2, COM3 are all D-SUB 9-pin connectors. To

connect any serial device, follow the following instructions:

1. Turn off the Panel PC system and the serial devices.

2. Attach the interface cable of the serial device to the 9-pin D-SUB serial

connector. Be sure to fasten the retaining screws.

3. Turn on the computer and the attached serial devices.

4. Refer to the serial device's manual for instruction to configure the operation

environment to recognize the new attached devices.

5. If the serial device needs specified IRQ or address, you may need to run the

CMOS setup to change the hardware device setup.
