Aquavision 10.4" Manuel utilisateur

Television

Operation & LCD

Installation Instructions

For screen sizes 10.4”, 15.1” & 17” Widescreen

Rev 2.1

www.aquavision.tv

WARNING:

Caution:

Do not attempt to modify this product in any way without written authorisation from the manufacturer.

Power

This set operates on a DC supply provided by the AC-DC adaptor, the voltage is as indicated on the label

on the back cover. Use only the AC-DC adaptor supplied with your AQUAVISION® and never apply an

AC mains supply to the set directly. The AC-DC adaptor operates on an AC mains supply, the voltage is

as indicated on the label of the AC-DC adaptor.

Service

Never remove the front or back cover of the TV; this can expose you to high Voltage and other hazards. If

the TV is faulty in any way, switch it off and call your dealer. After any maintenance, you will need to

remove and clean off the original silicon and re seal the front joints as stated overleaf.

Location

Position your TV so that no bright light or sunlight will shine directly onto the screen.

Cleaning

When cleaning AQUAVISION®, never use an abrasive cleaner. The front of the screen is glass and

therefore should be cleaned with a soft damp cloth and a mild, non-abrasive glass/tile cleaning agent.

Earth

The unit must be earthed to the main earth system of the building and must conform to the latest

electrical safety regulations.

Installation

It is the installer’s responsibility to ensure that the AQUAVISION® unit is installed and sealed correctly as

stated in these instructions. Your guarantee will be void if any problems are caused through installation

faults or poor sealing. After any maintenance, you will need to completely clean the old silicon off and re-

seal as stated above.

Please note: The installation of your AQUAVISION® unit should be carried out by a technically competent

person and must conform to all the relevant regulations. If in doubt, please refer to your supplying dealer.

CONTENTS:

Before operating the set, please read this manual carefully.

Warnings.........................................................................................................................................2

Contents .........................................................................................................................................3

Supplied Accessories......................................................................................................................4

Speaker Connection........................................................................................................................5

LCD Connection..............................................................................................................................5

Input/Output Connectors ................................................................................................................6-7

Remote Controller ...........................................................................................................................8-10

Standard Remote Controller Battery Installation..............................................................................9

Waterproof Remote Controller ..................................................................................................... 10

Waterproof Remote Controller Battery Installation ....................................................................... 10

Basic Operation............................................................................................................................ 11

Turning this TV On and Off........................................................................................................... 11

Program Selection........................................................................................................................ 11

Volume Adjustment ...................................................................................................................... 11

Quick View ................................................................................................................................... 11

Sound Mute Function................................................................................................................... 11

On screen Language Selection .................................................................................................... 11

On Screen Menus and Displays ................................................................................................... 12

Setting up TV Program................................................................................................................. 13-15

Auto Program............................................................................................................................... 13

Manual Program........................................................................................................................... 14

Program Edit ................................................................................................................................ 15

Picture Control ............................................................................................................................. 16

Manual Picture Control................................................................................................................. 16

Auto Picture Control..................................................................................................................... 16

Sound Control.............................................................................................................................. 17

Other functions............................................................................................................................. 18-19

TV, SCART, VIDEO and S-VIDEO Modes .................................................................................... 18

Auto Sleep ................................................................................................................................... 18

Blue Back..................................................................................................................................... 18

Sleep Timer .................................................................................................................................. 19

Sound Output Selection............................................................................................................... 19

Teletext ........................................................................................................................................ 20-21

Text On/Off .................................................................................................................................. 20

TOP Text...................................................................................................................................... 20

FLOF Text .................................................................................................................................... 20

Special Teletext Functions............................................................................................................ 21

External Equipment Connection................................................................................................... 22

Antenna Connection..................................................................................................................... 22

SCART Jack................................................................................................................................. 22

A/V Inputs .................................................................................................................................... 22

S-VIDEO Input.............................................................................................................................. 22

Connecting PC as Monitor ........................................................................................................... 23-24

Product Specifications ................................................................................................................. 25-26

Warranty....................................................................................................................................... 26

Pixel Errors................................................................................................................................... 26

Troubleshooting ........................................................................................................................... 27

Supplied Accessories

Make sure the following accessories are provided with your AQUAVISION®.

1. Remote Controller 2. Batteries (type AAA)

3. Operating Manual 4. Waterproof Remote Control

5. LCD Panel

Connections

Speaker Connection.

Connect each speaker cable into its respective terminal on the connecter block at

the rear of the LCD unit making sure you observe polarity. Only one speaker should

ever be connected to each speaker lead on your AQUAVISION®®. Failure to

observe this will cause serious damage to your unit that will not be covered under

your guarantee.

NOTE: In areas of weak signal or if you have connected other televisions to your

aerial, a TV distribution amplifier may be required. These are available from all good

dealers.

LCD Connection.

Connect all cables as per the schematic shown on the rear of the television, taking

care not to damage the small circuit board on the bottom.

Once you are happy that all connections are made, put the LCD television into the

aperture and insert the 4 screws (already mounted within the bezel) to the LCD back

cover.

The LCD panel is now ready for a final clean before the installation of the glass.

(Glass installation instructions can be found within the glass component packaging)

NOTE: Once the glass has been installed please ensure that any maintenance of

the AQUAVISION® unit involves the use of a glass sucker to remove the glass

panel.

Connectors

Input/Output Connectors For AQUAVISION® 10.4” TV

1. Ant. (Antenna input)

2. DC12V adaptor input

3. SCART

4. HEADPHONE out STEREO out

Connect a headphone to this socket or use as output for multiroom system

5. S-VIDEO Input

Connect the output of an S -VIDEO VCR/DVD to the S-VIDEO input and the audio to the AV-IN audio.

6. A/V-IN Inputs

Connect the Audio/Video outputs of external equipment to these inputs.

7. Speaker connections

When installing on the AQUAVISION® 10.4” screen, there is a power switch located on the side of the

plastic chassis attached to the front plate. Make sure this is set to “ON” before fitting the front panel.

Input/Output Connectors For AQUAVISION® 15” TV

1. PC/DTV Audio input

2. DC12V adaptor input

3. PC/DTV Screen Input

4. SCART. Fully wired.

5. HEADPHONE out STEREO out

Connect a headphone to this socket or use as output for multiroom system.

6. S-VIDEO Input

Connect the output of an S -VIDEO VCR/DVD to the S-VIDEO input and the audio to the AV-IN audio

7. A/V-IN Inputs

Connect the Audio/Video outputs of external equipment to these inputs.

8. Ant. (Antenna input)

9. Speaker connections

Connectors

Input/Output Connectors For AQUAVISION® 17” Widescreen TV

1. PC/DTV Audio input

2. DC12V adaptor input

3. PC/DTV Screen Input

4. SCART. Fully wired.

5. HEADPHONE out STEREO out

Connect a headphone to this socket or use as output for multiroom system.

6. S-VIDEO Input

Connect the output of an S -VIDEO VCR/DVD to the S-VIDEO input and the audio to the AV-IN audio

7. A/V-IN Inputs

Connect the Audio/Video outputs of external equipment to these inputs.

8. Ant. (Antenna input)

9. Speaker connections

Remote Controller

All functions can be controlled with the remote controller.

Remote Controller

Before you use the remote controller, please install the batteries.

1. POWER

Turns the TV on from standby mode and off to standby mode.

2. MUTE

Turns the sound on and off.

3. NUMBER buttons

Select program numbers.

4. PSM (Picture Status Memory)

Recalls your preferred picture setting

5. SSM (Sound Status Memory)

Recalls your preferred sound setting

6. TV/AV

Selects TV, SCART, VIDEO, S-VIDEO or PC mode.

Clears the menu from the screen.

7. MENU

Displays a main menu.

8. l/ll

Selects the language during dual language broadcast.

Selects the sound output.

9. Q.VIEW

Returns to the previously viewed program.

Remote Controller

10. PR__ (Program Up/Down)

Selects previous or next program or a menu item.

11. OK

Accepts your selection or displays your current mode.

12. VOL__ (Volume Up/Down)

Adjusts the sound level, and adjusts menu settings.

13. SLEEP

Sets the sleep timer. Note: In Teletext mode,

The SLEEP button is used for Teletext function.

14. TELETEXT buttons

These buttons are used for Teletext.

See the 'Teletext' section on page 22-23.

15. ARC

Selects a screen mode 16:9 or 4:3 (wide or normal)

16. SCART

Selects the SCART input mode

17. VIDEO

Selects the Video input mode

18. S-VIDEO

Selects the S-Video input mode

19. PC

Selects the PC input mode

Battery Installation

•Inserting batteries

1. Remove the battery cover by pulling it upward in the direction shown by the arrow.

2. Insert the batteries with correct polarity ("+" to "+", and "-" to "-").

3. Replace the battery compartment cover.

Install two high-quality 1.5V "AAA" alkaline batteries. Do not mix old batteries with

new batteries. Remove batteries when the remote controller will not be in use for a long period of time.

Liquid leakage from old batteries may cause operation failure.

Waterproof Remote Controller

Standard operating features are available with this remote controller. The unit is also waterproof and so

can be dropped in the bath where you will easily be able to find it as it will float!

Mute

Turns the sound on and off.

TV/AV

Selects TV, SCART, VIDEO, S-VIDEO or PC mode.

POWER

Turns the TV on from standby mode and off to standby mode.

0-9 NUMBER buttons

Select program numbers.

PR__ (Program Up/Down)

Selects next or previous program.

Displays your current mode on screen.

VOL + - (Volume Up/Down)

Adjusts the volume level.

Replacing the battery

Your Waterproof Remote Controller comes as standard with a coin cell battery installed. Should this need

replacing at any time, simply twist open the battery compartment on the rear of the remote control by

turning it with a coin, and remove the discharged battery. Replace with a CR2032 Lithium Battery making

sure you observe polarity. Replace battery cover and twist to close.

Notes for using remote controller

• Make sure there are no objects between the remote controller and its sensor.

• Do not place the main remote control near a heater.

• Strong impact to the remote control may cause operation failure.

• Signal from the remote control may be disturbed by sunlight or other bright light. In this case,

darken the room.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Aquavision TV

Aquavision

Aquavision DB100 Manuel utilisateur

Aquavision

Aquavision AVF-10.4-4 Manuel utilisateur

Aquavision

Aquavision AVF17W-4FK Manuel utilisateur

Manuels TV populaires d'autres marques

Philips

Philips Colour Television Manuel utilisateur

Toshiba

Toshiba 27A10 Manuel utilisateur

Philips

Philips 42PF9630A/37 Manuel utilisateur

Hitachi

Hitachi 32FX48B Manuel utilisateur

DAEWOO ELECTRONICS

DAEWOO ELECTRONICS DTQ-14V1FC Manuel utilisateur

Changhong Electric

Changhong Electric uhd55b6000is Manuel utilisateur

Philips

Philips Matchline 21CE7551 Manuel utilisateur

Panasonic

Panasonic Genus TX-G10 Manuel utilisateur

Toshiba

Toshiba 19A20 Manuel utilisateur

Philips

Philips 25PT4523-16 Manuel utilisateur

Sony

Sony XBR-100Z9D Manuel utilisateur

Philips

Philips PR0930X3 Manuel utilisateur

Philips

Philips Brilliance 231P4QPY Manuel utilisateur

Samsung

Samsung 55S9 B Series Manuel utilisateur

Philips

Philips 32HF9385D Guide de dépannage

Sharp

Sharp LC-40FI5012E Manuel utilisateur

Loewe

Loewe Table Stand Reference 55 Manuel utilisateur

Philips

Philips 32PFH5300 Manuel utilisateur
